Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL H2SM-(9+9)H03/R2(DB) H2SM-(9+12)H03/R2(DB) Please read this operation manual before using the air conditioner. - Page 2 Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
- Page 3 Cautions Do not obstruct or cover the ventilation grille of the air conditoner.Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner.In no case should children be allowed to sit on the outdoor unit.
-
Page 4: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. - Page 5 Cautions When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION Do not start or stop the operation by disconnecting the power supply cord and so on.
-
Page 6: Parts And Functions
Parts and Functions Indoor unit Inlet grille Air filter Vertical flap Power indicator Use remote controller to Lights up when unit starts. adjust up and down air flow. (Don't adjust it manually.) For multi-split type, the power plug is on the outdoor unit Outdoor unit OUTLET INLET... - Page 7 Parts and Functions 1. SWING button Used to select up or down air sending direction. 2. HOUR button Used to set clock and timer setting. 3. MODE button Used to select operation mode. AUTO, COOL,DRY, FAN,HEAT. 4. HEALTH button Used to set healthy operation. 5.
- Page 8 Parts and Functions Clock Set When unit is started for the first time and after replacing batteries in remote controller, clock should be adjusted as follows: 1. Press CLOCK button,"AM" or "PM" flashes. 2. Press to set correct time. Each press will increase or decrease 1 min.
-
Page 9: Health Operation
Remote controller BRIEF INTRODUCTION TO HEALTH OPERATION The anion generator in the air conditioner can generate a lot of anion to effectively balance the quantity of position and anion in the air and also to kill bacteria and speed up the dust sediment in the room and finally clean the air in the room. -
Page 10: Auto Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under displayed wind speed When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. 5.Unit stop Press ON/OFF button, the unit stops. -
Page 11: Cool Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under displayed wind speed When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. 5.Unit stop Press ON/OFF button, the unit stops. -
Page 12: Dry Operation
Press FAN button. For each press, fan speed changes as follows: Remote controller: Air conditioner is running under displayed wind speed In DRY mode, when room temperature becomes 2 higher than temp.setting,unit will run intermittently at LOW speed regardless of FAN setting. -
Page 13: Fan Operation
Operation Fan Operation Remote controller 1. Unit start Link with electronic power. Press ON/OFF on the remote controller, unit starts. The liquid crystal will display the working state of last time (Except Timer, Sleep, Power/Soft and Health airflow). 2.Select operation mode Press MODE button. -
Page 14: Heat Operation
Air conditioner is running under displayed wind speed IN HEAT mode, warm air will blow out after a short period of the time due to cold-draft prevention function. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. -
Page 15: Air Flow Direction Adjustment
Operation (5)Air flow direction adjustment After operation mode is selected, vertical flap will open automatically according to the mode. Referring to the Fig. COOL About 10 Up and down (Use remote controller) Press SWING button, vertical flap will move within the range shown in the Fig. -
Page 16: Sleep Operation
Operation Sleep Operation Before going to bed, you can simply press the SLEEP button and unit will operate in SLEEP mode and bring you a sound sleep. Use of SLEEP function After the unit starts, set the operation status, then press SLEEP button before which the clock must be adjusted and time being set. -
Page 17: Timer On/Off Operation
Operation Timer On/Off Operation Set clock correctly before starting TIMER operation. Remote Controller 1. After unit starts, select your desired operation mode 2. Timer mode selection 3.Time setting 4.Confirming your setting 5.Cancel TIMER mode Hints: After replacing batteries or a power failure happens, time setting should be reset. Remote controller possesses memory function, when use TIMER mode next time,just press SET button after mode selecting if time setting is the same as previous one. -
Page 18: Remote Controller
Operation Timer On-Off Operation Remote Controller Set clock correctly before starting TIMER operation. 1. After unit starts, select your desired operation mode Operation mode will be displayed on LCD. 2. Timer mode selection Press TIMER button to change TIMER mode. Every time the button is pressed, display changes as follows: Remote controller: TIMER ON... -
Page 19: Power Operation
Operation POWER/SOFT Operation POWER Operation When you need rapid heating or cooling, you can use this funciton. Selecting of POWER operation Press POWER/SOFT button. Every time the button is pressed,display changes as follows: Stop the display at In POWER operation status: In HEAT or COOL mode, fan speed automatically runs in AUTO mode for 15 min then returns to original status setting. -
Page 20: Emergency And Test Operation
Operation Emergency and Test Operation Emergency operation: Use this operation only when the remote controller is defective or lost. When the emergency operation switch is pressed,the" Pi "sound is heard once, which means the start of this operation. In this operation, the system automatically selects the operation modes, cooling or heating, according to the room temperature. -
Page 21: Maintenance
Maintenance For Smart Use of The Air Conditioner Setting of proper room temperature Close doors and windows during operation If the unit is not to be used for a long time, turn off the power supply main switch. Do not block the air inlet... -
Page 22: Air Filter Cleaning
Close the inlet grille. Indoor Body Wipe the air conditioner by using a soft and dry cloth.For serious stains,use a neutral detergent diluted with water.Wring the water out of the cloth before wiping.then wipe off the detergent completely. -
Page 23: Replacement Of Air Purifying Filter
Maintenance Replacement of Air Purifying Filter 1.Open the lnlet Grille Open the inlet grille by pushing each ends of the inlet grille upward.(use thumbs to push 2.Detach the standard air filter Slide the knob slightly upward to release the filter, then withdraw it. 3.Detach the Air Purifying Filter Replace the old filter with new one into the frame. -
Page 24: Cleaning The Body
Maintenance To Keep Your Air conditioner in Good Condition after Season. Operate in cooling mode for 2-3 hours. To prevent breeding mold or bad smell, be sure to operate at the designated temperature or 30 mode and High speed fan mode for 2-3 hours. -
Page 25: Cleaning The Standard Air Filter
Maintenance Before Setting in High season Cleaning the standard air filter. Operation without filter may cause troubles.Be sure to attach both right and left filters prior to the operation. Each of them are of different shapes. Connecting the earthing cable. Incomplete earthing may cause an electric shock. -
Page 26: Troubleshooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
