Portable Air Compressor
600H, 750, 750H, 750HH,
SAFETY WARNING
Users are required to read the
entire User Manual before han-
dling or using the product.
USER MANUAL
825, 900, 900H, 1050
Tier 3
Caterpillar
WARRANTY NOTICE
Failure to follow the instructions
and procedures in this manual,
or misuse of this equipment, will
void its warranty.
Subject to EAR, ECCN EAR99 and related export control restrictions.
PART NUMBER:
02250197-981 R01
The information in this manual is current as of its
publication date and applies to compressors with
serial number:
201509010000
and all subsequent serial numbers.
Publication date: 10/14/2015
Copyright © 2013 – 2015 Sullair, LLC. All rights reserved.
