Installation of this product requires detailed knowledge of automotive systems and
repair procedures. We recommend that this installation be carried out by a qualified
automotive technician.
Installation of this product requires handling of diesel. Ensure you are working in a well
ventilated area with an approved fire extinguisher nearby. Extinguish all open flames, prohibit
smoking and eliminate all sources of ignition in the area of the vehicle before proceeding with
the installation.
When installing this product, wear eye goggles and other safety apparel as needed to
protect yourself from debris and sprayed diesel
Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.
This kit contains the following parts:
1 ea Fuel Pump Assembly (130gph)
2-20psi spring installed
Regulator Adjustment Pressure Range:
Flow Output @ 13.5V:
Filter Micron Rating:
Coolant Ports:
Inlet Port:
Outlet/Return Port:
Filter Threads:
Factory Pressure setting:
Gauge Port
:
WARNING: DO NOT REVERSE POLARITY ON PUMP. PUMP DAMAGE AND FAILURE WILL
OCCUR!
DESIRED LINE SIZE
INLET -
-
-
OUTLET – 12AN
RETURN – 12AN
2-60psi
130gph @ 10psi
2 Micron (CATERPILLAR 1R-0750)
AN-08 ORB
AN-12 ORB
AN-10 ORB
1"-14
10 psi
1/8" NPT
12AN
-
10AN
½" J2044 (male)
5/8" J2044 (male)
- 10AN
- 8AN
- ½"J2044 (male)
-10AN
- 8AN
- ½" J2044 (male)
AEROMOTIVE
Part # 11802
Diesel Lift Pump 130 gph
CAUTION:
.
1 ea Spring, 20-40psi
1 ea Spring, 30-60psi
PUMP SPECS:
AEROMOTIVE PORT FITTING PART #
15612
15613
15131
15130
15642
15608
15610
15129
15642
15608
15610
15129
