Operation & Maintenance Manual
This manual contains important safety information.
Do not destroy this manual.
This manual must be available to the personnel who operate and maintain this machine.
P.O. Box 868 - 501 Sanford Ave
Mocksville, N.C. 27028
Book 22560825 (2/05)
Revised (09-12)
Compressor Models
XHP700WCAT
MHP825WCAT VHP750WCAT
SHP750WCAT
CODE:
CODE: B
CODE: D
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
