Haier AB422BCBAA User Manual

Haier network air conditioner two by one room air conditioner

Advertisement

Quick Links

Two by One Room Air Conditioner
AB422BCBAA
*
N o .
0010571740
Please read this manual carefully before using
Please keep this manual for future use
CONTENTS
Before Use
************* 3-5
************** 8
************* 11
Maintenance
*************15-19
Installation of Indoor Unit
*********** 1-2
********** 6-7
************ 9
************ 10
******** 12
******** 13
************ 14
*********** 20-21
****** 22
****** 24*34
**** 35
*
23

Advertisement

Table of Contents
loading

Summary of Contents for Haier AB422BCBAA

  • Page 1: Table Of Contents

    Two by One Room Air Conditioner AB422BCBAA N o . 0010571740 Please read this manual carefully before using Please keep this manual for future use CONTENTS Before Use Operation Points *********** 1-2 Name of Parts ************* 3-5 Safety Precautions ********** 6-7...
  • Page 2 There is a pre-set far distance control communication interface on the control panel of indoor unit. After installing the peripheral equipment according to the manual attached with the Haier made far distance control detector, the computer management or other place monitoring can be achieved to the air conditioner.
  • Page 3: Operation Points

    There is a pre-set far distance control communication interface on the control panel of indoor unit. After installing the peripheral equipment according to the manual attached with the Haier made far distance co- ntrol detector, the computer management or other place monitoring can...
  • Page 4 ON/OFF button to turn off the unit after power failure resumes.
  • Page 5: Name Of Parts

    Name of Parts Indoor Unit Air outlet Air filter (inside of air inlet grille) Wire Controller (inside of air outlet) Remote control signal receiving window Drain Timer Operation Power MODE AUTO TEMP CLOCK TIMER ROOM HEAT ON/OFF Drainpipe Louver Connection pipes and electric wire Air inlet grille SWING...
  • Page 6: Name Of Parts

    Name of Parts AUTO 1.ON/OFF button Used to turn on/off unit 2.Temperature display 3.Clock display 4.Timer ON/OFF display 5.Humidity display 6.Air filter cleaning display When there is too much dust collected on the air inlet, the wire controller will show this display to remind the user to clean the air inlet.
  • Page 7: Safety Precautions

    The following safety precautions must be observed. This safety precautions should keep in hand for reference. When transfer the air conditioner to a new user, this manual should also be given to the new user together with the unit. If abnormal conditions (sear smell)
  • Page 8: Safety Precautions

    If the drain hose is not arranged properly, the leaked drain water may damage the furniture or other articles alike. Do not install the air conditioner in a place where the inflammable gas maybe exists. The inflammable gas around the air conditioner may cause fire accident.
  • Page 9: Operation Instruction Fan Operation

    RESET ON/OFF About FAN operation: FAN operation refers the air conditioner does not perform COOLING and HEATING operation, but FAN operation. In this mode, the air conditioner cannot perform AUOT FAN operation, and does show the temperature value on the wire controller.
  • Page 10: Auto/Cooling/Dehumidifying/Heating Operation

    The wire controller can memorize the working condition of each time. When start the unit for the second time, just need to press ON/OFF button, the air conditioner will work according to the previous working mode. (except for Timer, Sleep and Swing)
  • Page 11: Swing Operation

    î, the louver of the air conditioner begins automatic swing and air sending. Fixed air sending direction When the Auto SWING of the air conditioner swings to an appropriate angle, press SWING button, the display ì î on the LCD of the remote controller will disappear, the air sending direction is fixed.
  • Page 12: Sleep Function

    Operation instruction Before going to bed, you can press the SLEEP button, the air conditioner will operate in comfort sleep mode to make you have a sound sleep. Before using this function, you should calibrate the clock first, otherwise, the SLEEP function will be out of order.
  • Page 13: Timer On/Off Function

    Operation instruction MODE SWING TEMP CLOCK TIMER SLEEP HEAT FILTER RESET RESET ON/OFF Set time Press the time adjusting button Each press, the set time increases 10 minutes. If depress the button, the time will increase rapidly. Each press, the set time decreases 10 minutes. If depress the button, the time will decrease rapidly.
  • Page 14: Timer On-Off Function

    Operation instruction Before using TIMER function, calibrate the clock first. MODE SWING TEMP CLOCK TIMER SLEEP FILTER RESET HEAT RESET ON/OFF Set the TIMER ON time Press the time adjusting button Each press, the set time increases 10 minutes. If depress the button, the time will increase rapidly.
  • Page 15: Usersí Attention

    The air conditioner can only be used in air conditioning. It can not be used in other purpose. Do not use the air conditioner in some specific purpose, such as storage or protect food, animals, plants, precise instrument and...
  • Page 16: Maintenance

    When not for cleaning, do not dismantle the air filter, otherwise it may cause trouble. When the air conditioner is used in a dusty environment, the air filter should be cleaned more often (generally once every two weeks). 1.Open air inlet grille Pull the two handles at the same time, slowly draw them out.
  • Page 17 Maintenance Clean the air filter 2.Dismantle the air filter Pull the two side handles at the back of the air inlet grille, lift the air filter to dismantle it. 3. Clean Do not use the hot water over 50* to clean to avoid discoloration or deformation.
  • Page 18 Maintenance Clean the air inlet grille 1.Open air inlet grille Pull the two handles at the same time, slowly draw them out. (when closing it, the procedure is reversed.) 2.Remove air filter Referring to ìClean the air filterî. 3.Remove the air inlet grille Open the air inlet grille for 45o, the lift it up.
  • Page 19 Use soft dry cloth to clean. If cannot remove the dust, use water or neutral detergent. If the louver of the air conditioner is too dirty, it may be dismantled (as the following described) for cleaning. Dismantle and install louver 1.Fix the louver at the lowest position.
  • Page 20 Maintenance Maintenance before and after the using season. Check the following items: If the air inlet and outlet of indoor and outdoor unit are blocked. If the earth wire is proper. If the wire connection is proper. If there is abnormal phenomenon, please ask the after-sale service staffs for help.
  • Page 21: Troubleshooting

    The smells or the cigarette smell absorbed in indoor unit are blown out. In DEHUMIDIFYING operation, when the room temperature is 2* higher than the set temperature, despite of the set FAN SPEED the air conditioner will operate in LOW FAN SPEED.
  • Page 22: When Troubles Occur

    When Troubles Occur Before contacting the commissioned repair center for after-sales service, please check your air conditioner according to the following items. Symptom The unit does not The fuse is blown out or the breaker operate. is open. Once the unit operates, it The air inlet or air outlet of indoor stops immediately.
  • Page 23: Installation Instruction

    Install the air conditioner to a place where can definitely stand its weight. The air conditioner can not be installed on a nonmetal bracket (such as theft guard net). Places not firm enough will cause drop down of unit resulting in body hurt.
  • Page 24 Installation instruction This manual can not include all kinds of conditions, if you have new requirements and questions, please contact with local Haier Sales Center. Before installing the unit, please read this manual carefully. Improper installation may cause accidents and make unit damage or death.
  • Page 25: Installation Procedure ****** 24*34

    Installation procedure 1. Before installation [Before finishing installation, do not throw the attached parts installation needs] Confirm the way to move the unit to the installation place. Before moving the unit to the installation place, do not remove their packages. When have to remove the package, use a soft material or protection board with rope to lift the unit assembly to avoid unit damage or bumping a scrape.
  • Page 26 Installation procedure 3.Preparation before installation (1) The position relation among ceiling opening and hoisting screws (unit: mm) 1070 (The distance between hoisting screws) 840 (Indoor unit assembly) 1280*(Ceiling opening) 1340 (Decorative panel) (2) If necessary, cut the opening installation needed in the ceiling. (For the condition of having ceiling) For the dimension of the ceiling opening, please refer to the installation paper panel.
  • Page 27 Installation procedure 4.Installation of indoor unit In the new ceiling circumstance (1)Temporarily install the indoor unit Attach the hoisting foot on the hoisting screw. The screw nut and washer must be used at the top and bottom two ends of the hoisting foot to make the hoisting foot firm.
  • Page 28 Installation procedure 5.Refrigerant pipe [The proper thermal insulation must be treated to gas pipe and liquid pipe. If not, it may cause water leakage.] The outdoor unit is not charged with refrigerant. When connecting the pipes to unit or dismantling the pipes from the unit, do proceed as the figure shown, use spanner and torque pincers together.
  • Page 29: Install Indoor Unit

    Installation procedure The drain hose should be as short as possible. The droop slant degree at least should be 1/100 to avoid forming of gas bag. If cannot make the drain hose have an enough slant degree, a drainage enhancing hose should be equipped. In order not to let the drain hose bend, a 1~1.5m distance should be kept between suspending frame.
  • Page 30 Installation procedure Test of drainage system (a)After finishing the electric work, perform the test to the drainage system. (b)During test, confirm the water flow properly passes the hose and there is no leakage at the joint. (c)If the house is new, perform test before installing ceiling. (d)Even if installing in the season needing to make heating, the test also must be performed.
  • Page 31 Installation procedure Install indoor unit < The wiring method of the connection of the unit > Connect the unit Remove the electric box cover (1), draw the wire in the rubber lining, use wire clamp A to clamp it together with other wires, and connect the wire of the relative polarity to the inner power terminal block.
  • Page 32 When the corner cover can slide, dismantle the corner cover (referring to Figure Note: When the air conditioner is under use, the fixing adhesive tape can be removed, not use any longer. 2.The installation of the decorative panel on the indoor unit.
  • Page 33 Installation procedure Louver motor (1)Install decorative panel Temporarily hang the hoisting ring opposite to the louver motor of the decorative panel on the hoisting ring fixing piece (2 pieces) of the indoor unit. Temporarily hang the other 2 hoisting rings on the hoisting ring fixing pieces at the side of the indoor unit (be careful not to stick to wire of the louver motor into the sealing material).
  • Page 34 Installation procedure (3)The circuit of the decorative panel Connect the wire end of the louver motor installed on the decorative panel (referring to Figure 7). Connect the remote control receiving terminals installed on the decorative panel. Side of indoor unit 3.Installation of air inlet grille and corner cover (1)Install the air inlet grille The reversed procedure to the ìthe preparation of decorative panelî...
  • Page 35 Installation procedure 1. Connection of pipe The max length of connection pipe is 50m, the max fall is 30m. The attentive matters in connection of pipe In order to guarantee the efficiency, the pipe should be as short as possible. Do not make the connection pipe distorted and deformed.
  • Page 36: Other Instruction And Test Run

    Incorrect wiring easily damage the controller of the air conditioner, or the unit cannot work normally. Electric wiring The wiring method of orbicular terminal...
