Page 1: Operation Manual
CASSETTE AIR CONDITIONER OPERATION MANUAL AB242ACBCA AU242AHBBA (HBU-24HE03/R1) AB282ACBCA AU282AHBDA (HBU-28HD03/R1) AB36NACBCA AU36NAIBBA (HBU-36HC03/R1) AB42NACBCA AU42NAIBBA (HBU-42HD03/R1) Please read this operation manual before using the air conditioner. No.0010572002... -
Page 2: Table Of Contents
CONTENTS Cautions Introduction to spare parts Guide to operation Maintenance Trouble shooting 9-15 16-19... -
Page 3: Cautions
Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide. - Page 4 Do not obstruct or cover the ventilation grille of the air conditioner. Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner.
-
Page 5: Safety Cautions
CAUTIONS Safety cautions Carefully read the following information in order to operate the airconditioner correctly. Below are listed three kinds of Safety Cautions and Suggestions. WARNING! Incorrect operations may result in severe consequences of death or serious injuries. CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may cause serious consequences. - Page 6 CAUTIONS Conditioner should not be used for any other purpose other than airconditioning. Don't use air-conditioner for any other special purposes, e.g. the preservation and protection of food, animals, plants, pecision apparatus as well as work of art, otherwise the qualities of these stuffs may be damaged.
-
Page 7: Cautions
CAUTIONS Installation Please ask the dealer or specialist to install, never try by the users themselves. After the installation please Please call dealer to install the air-conditioner. Incorrect installation may cause water leaking, shock and fire hazard. Air-conditioner can't be installed in the envi- ronment with inflammable gases because the inflammable gases near to air-conditioner may cause fire hazard. -
Page 8: Introduction To Spare Parts
INTRODUCTION TO SPARE PARTS Operation CLOCK Used to set correct time. TIMER Used to select TIMER ON, TIMER OFF, TIMER ON/OFF. TIME Used to set clock and timer setting. Power ON/OFF Used for unit start and stop. Cautions: On cooling only unit, heating mode is not available. - Page 9 INTRODUCTION TO SPARE PARTS Operation Buttons and display of the wire controller. COOL Remote control HEAT AUTO SLEEP FAN SPEED OPERATING LAMP TIMER ON FAN OPERATION TIMER OFF TEMP. CLOCK Clock set When unit is started for the first time, clock should be adjusted as follows: Press CLOCK button, "AM"or "PM"...
-
Page 10: Introduction To Spare Parts
INTRODUCTION TO SPARE PARTS INDOOR UNIT Discharge unit (built in) In cooling operation,to discharge the water from inside the room. Outlet Air filter (located in the suction grill) OUTDOOR UNIT Air inlet Air outlet Compressor (Inside of unit) For series 36, 42 Suction grill Air inlet Air outlet... -
Page 11: Guide To Operation
GUIDE TO OPERATION The air conditioner has the function of POWER FAILURE RESUME. Fan operation Enjoy yourself by just a gentle press. (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display. (Not Timer setting) Power indicator lights up. - Page 12 GUIDE TO OPERATION AUTO RUN, COOL,HEAT and DRY operation Recommendations (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display (Not Timer setting). Power indicator lights up. (2) Select operation mode Press MODE button. For each press, operation mode changes as follows: AUTO COOL Unit will run in operation mode displayed on LCD.
-
Page 13: Timer Operation
GUIDE TO OPERATION TIMER operation Set Clock correctly before starting Timer operation. You can let unit start or stop automatically at following time: Before you wake up in the morning, or get back from outside or after you fall asleep at night. TIMER ON/OFF (1)After unit start, select your desired operation mode. -
Page 14: Timer Mode
TIMER ON-OFF (1)After unit start, select your desired operation mode Operation mode will be displayed on LCD. Power indicator lights up. (2) Press TIMER button to change TIMER mode Every time the button is pressed, display changes as follows: Select (3)Time setting for TIMER ON Press TIME button. - Page 15 Press SLEEP button once to make the air conditioner have the previous-set sleep time (first power- on is "1h"), the sleep symbol will appear. Press time button hours. Each press of setting part, "OFF"...
- Page 16 GUIDE TO OPERATION Adjusting up/down air flow direction Up/down direction can be adjusted by using the SWING button on the remote controller. Each time pressing this button, the mode changes in the following sequence. Change to the AIRFLOW mode. SWING Louver moves in upward and downward directions continuously.
- Page 17 Notes: When a power failure suddenly occurs during the air conditioner is working after the power failure compensation is set, if the air conditioner will not be used for a long time, please cut off the power supply to prevent its operation from being resumed after the power is supplied again, or press the "Switch On/Off"...
-
Page 18: Maintenance
MAINTENANCE Appropriate room temperature setting Don't be too low or too high, to make everybody in the room feel comfortable. Cooling 26-28 Don't open the doors and windows. Otherwise reduce the efficiency of the air- conditioner. Don't place any goods around inlet and outlet. These obstacles may lower the efficiency of air-conditioner or stop it. -
Page 19: Clean Air Filter
MAINTENANCE [ Clean air filter ] 3. Dismantle air filter Drag the knob of the grill back lift the filter and take Air filter down. 4. Clean CAUTION! Don't wash with water over 50 ,to prevent discoloring or deforming. Don't dry over fire. Filter maybe burn. (A) Use vacuum suction or (B) wash with water to remove dust. - Page 20 MAINTENANCE [Clean inlet grill] 3. Take of inlet grill Open the inlet grill by an angle of 45 , lift up. 4. Clean CAUTION! Don't wash with water over 50 C,to prevent decoloring or deforming. Use soft brush, water and neutrul detergent, then swing off the water.
-
Page 21: Maintenance
MAINTENANCE [Dismantle and install swing plate ] 3. Install swing plate Lightly rotate swing plate to insert the ridge at both ends of the outlet into the groove and then screw up. NOTE For detailed information consult dealer. Maintenance at the beginning and closing of the applying seasons 1. -
Page 22: Trouble Shooting
TROUBLE SHOOTING The following symptoms are not faults Symptom When stop machine then continue operation. Conditioner doesn't work When press temp setting key and release at once. When power turns on. When humidity too high in the cooling White fog is operation (high content of oil or just in blown out room).
