Getting Started

This device features a browser-based web application, which controls audio and network
properties. Upon completing this basic setup process, you will be able to:
• Access the web application to customize audio settings, signal routing, and network
properties
• Use Dante™ Controller software to connect with other Dante devices and pass audio
• Access additional configuration information

Step 1: Connect to a Network

1. Use an Ethernet cable (CAT5e or higher) to connect the ANIUSB-MATRIX to a network
switch.
Note: The network switch must provide Power over Ethernet (PoE). Make sure to
connect to a PoE port, since many switches do not supply power on all ports.
2. Connect a computer to the network switch with an Ethernet cable
sig/clip line in line out usb
in power
out
network
network audio
usb encryption
reset
Step 2: Access the Web Application
1. Download and install the Shure Device Discovery application (http://www.shure.com)
2. Open the Shure Device Discovery application
3. Double-click the device to open the web application.
Tip: If setting up multiple Shure devices, use the Identify button in the application to
flash the lights on the device.
Select the device
PoE
4
Identify
