Wooden Clamp-on Mouse Pad
Instruction Manual
SKU: MOUNT-MS01B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-ms01b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-MS01B
Summary of Contents for Vivo MOUNT-MS01B
- Page 1 Wooden Clamp-on Mouse Pad Instruction Manual SKU: MOUNT-MS01B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-ms01b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 ASSEMBLY STEPS STEP 1 Insert Lower Clamp (B) with 14.5mm Washer (S-C) and 14.5mm Plastic Washer (S-D) into Mouse Pad (A). STEP 2 Place 10.2mm Washer (S-F) and 10.2mm Plastic Washer (S-E) onto Clamp Screw (D).
- Page 4 STEP 3 Insert Clamp Screw (D) into Mouse Pad (A). STEP 4 Place 6.5mm Washer (S-H), Clamp Plate (E), and 5.2mm Washer (S-G) onto Clamp Screw (D) and secure using M5x12 Screw (S-B) and a phillips screwdriver.
- Page 5 STEP 5 Secure Upper Clamp (C) to clamp assembly using M6x7 Screws (S-A) and a phillips screwdriver.
- Page 6 STEP 6 After the clamp is attached, tighten the thumb nut against the bottom of Mouse Pad (A). NOTE: Adjusting the tightness of the thumb nut will change the resistance when rotating the mouse pad. Thumb Nut...
- Page 7 STEP 7 When not in use, Mouse Pad (A) can be rotated under the desktop for storage.
