Wooden Arm Rest and Mouse Pad
Instruction Manual
SKU: MOUNT-MS02D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-ms02d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-MS02D
Summary of Contents for Vivo MOUNT-MS02D
- Page 1 Wooden Arm Rest and Mouse Pad Instruction Manual SKU: MOUNT-MS02D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-ms02d GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 STEP 2 Loosely assemble the Support Plate Set (D) with the rubber padding facing outwards using M4x10 Screws (S-A). Make sure the Adjustment Plate (C) is still able to slide freely. STEP 3 Place the loose assembly on a chair arm rest while sitting in the chair. Make adjustments by sliding the Mouse Pad and Arm Rest (A,B) along the Adjustment Plate (C).
- Page 4 STEP 4 Flip the assembly over. Loosely assemble the Adjustment Plate (C) with the closest mounting holes to the Mouse Pad and Arm Rest (A,B) using M4x10 Screws (S-A). NOTE: If you do not see the mounting point slide the Adjustment Plate until it shows through one of the holes.
- Page 5 STEP 5 Place the assembly back on the arm rest and check for what strap locations will work for your chairs armrest. If a strap is not being used where it is currently located, remove the strap and move it onto the Adjustment Plate (C) using the available slots.
- Page 6 STEP 6 Go back and fully tighten all eight M4x10 Screws (S-A) previously inserted, securing the Adjustment Plate and Support Plate Set (C,D). STEP 7 If you want to use the wrist pad, remove protective film from adhesive on the bottom of the Wrist Pad (E) and place at desired location.
- Page 7 STEP 8 Place the Mouse Pad and Arm Rest back onto your chair arm and secure it by tightening the velcro straps. NOTE: The velcro straps may be cut after the product is fully secured to your armrest in the desired position.
