Biostar Hi-Fi P61S2 Setup Manual
Hide thumbs Also See for Hi-Fi P61S2:

Advertisement

Quick Links

FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
Hi-Fi P61S2 Setup Manual
Dichiarazione di conformità
sintetica
Ai sensi dell'art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hi-Fi P61S2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar Hi-Fi P61S2

  • Page 1 Hi-Fi P61S2 Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction.......... 1 Before You Start..................1 Package Checklist ..................1 Motherboard Features................2 Rear Panel Connectors................3 Motherboard Layout.................4 Chapter 2: Hardware Installation ......5 Installing Central Processing Unit (CPU) ..........5 Install a Heatsink ..................7 Fan Headers ....................8 Installing System Memory ................9 Connectors and Slots................10 Chapter 3: Headers &...
  • Page 3: Chapter 1: Introduction

    Hi-Fi P61S2 CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation.
  • Page 4: Motherboard Features

    Realtek RTL8111F Half / Full duplex capability Sound 5.1 channels audio out ALC662 Codec High Definition Audio, Biostar Hi-Fi Supports PCI-E Gen2/3 x16 expansion card PCI-E Gen3 x16 slot Slots (depending on CPU) PCI-E Gen2 x1 slot Supports PCI-E Gen2 x1 expansion card...
  • Page 5: Rear Panel Connectors

    Audio Jack Provide Audio-In/Out and Mic. connection Board Size 210 (W) x 295 (L) mm Biostar reserves the right to add or remove support OS Support Windows XP / Vista / 7 / 8 for any OS with or without notice...
  • Page 6: Motherboard Layout

    Motherboard Manual OTHERBOARD AYOUT Note: ■ represents the 1st pin.
  • Page 7: Chapter 2: Hardware Installation

    Hi-Fi P61S2 CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Step 1: Locate the CPU socket on the motherboard Note1: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged.
  • Page 8 Motherboard Manual Step 4: Hold processor with your thumb and index fingers, oriented as shown. Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket. Note: The CPU fits only in one correct orientation. Do not force the CPU into the socket to prevent damaging the CPU.
  • Page 9: Install A Heatsink

    Hi-Fi P61S2 NSTALL A EATSINK Step 1: Place the CPU fan assembly on top of the installed CPU and make sure that the four fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest to the CPU fan connector.
  • Page 10: Fan Headers

    Motherboard Manual EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. CPU_FAN1: CPU Fan Header Assignment Ground +12V...
  • Page 11: Installing System Memory

    Hi-Fi P61S2 NSTALLING YSTEM EMORY A. Memory Modules Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. Step 2: Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 12: Connectors And Slots

    Motherboard Manual B. Memory Capacity DIMM Socket Total Memory DDR3 Module Location Size DDR3_A1 512MB/1GB/2GB/4GB/8GB Max is 16GB. DDR3_B1 512MB/1GB/2GB/4GB/8GB C. Dual Channel Memory Installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table. DDR3_A1 Dual Channel Status DDR3_B1...
  • Page 13 Hi-Fi P61S2 ATXPWR2: ATX Power Source Connector This connector provides +12V to CPU power circuit. Assignment +12V +12V Ground Ground ATXPWR1: ATX Power Source Connector This connector allows users to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V...
  • Page 14 Motherboard Manual PEX16_1: PCI-Express Gen3 x16 Slot PCI-Express 3.0 compliant. Maximum theoretical realized bandwidth of 16GB/s simultaneously per direction, for an aggregate of 32GB/s totally. PCI-E 3.0 is supported by Core i7-3xxx / i5-3xxx CPU. PEX1_1 ~ PEX1_5: PCI-Express Gen2 x1 Slots PCI-Express 2.0 compliant.
  • Page 15: Chapter 3: Headers & Jumpers Setup

    Hi-Fi P61S2 CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 16 Motherboard Manual F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel These headers allow users to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused) +5V (fused) USB- USB-...
  • Page 17 Hi-Fi P61S2 F_AUDIO1: Front Panel Audio Header This header allows users to connect the front audio output cable with the PC front panel. HD Audio AC’97 Assignment Assignment Mic Left in Mic In Ground Ground Mic Right in Mic Power...
  • Page 18 Motherboard Manual J_PRINT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3 Ground Ground Data 4...
  • Page 19: Chapter 4: Useful Help

    Hi-Fi P61S2 CHAPTER 4: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD The setup guide will auto detect your motherboard and operating system.
  • Page 20: Software

    Motherboard Manual OFTWARE Installing Software Insert the Setup DVD to the optical drive. The driver installation program would appear if the Autorun function has been enabled. Select Software Installation, and then click on the respective software title. Follow the on-screen instructions to complete the installation. Note1: All the information and content about following software are subject to be changed without notice.
  • Page 21 Hi-Fi P61S2 After filling up this information, click “Send” to send the mail out. A warning dialog would appear asking for your confirmation; click “Send” to confirm or “Do Not Send” to cancel. If you want to save this information to a .txt file, click “Save As…” and then you will see a saving dialog appears asking you to enter file name.
  • Page 22 Exit Button: Exit the application Note: 1. Smart EAR is only supported by Windows 7/8 and BIOSTAR Hi-Fi series motherboards. 2. High/Low Gain Switch is only for “Front Panel Audio Header”, please make sure you are connecting your headphone to the front panel I/O.
  • Page 23: Bios Update

    BIOS U PDATE There are three ways to update the BIOS: BIOS Update Utility, BIOS Online Update Utility and BIOSTAR BIOS Flasher. Note: The programming procedure may take minutes, please do not make any operation during the programming process. 1. BIOS Update Utility 1.
  • Page 24 Motherboard Manual 7. While the system boots up and the full screen logo shows up, please press <Delete> key to enter BIOS setup. After entering the BIOS setup, please go to the Save & Exit, using the Restore Defaults function to load Optimized Defaults, and select Save Changes and Reset to restart the computer.
  • Page 25 Hi-Fi P61S2 5. If there is a new BIOS version, the utility will ask you to download it. Click Yes to proceed. 6. After the download is completed, you will be asked to program (update) the BIOS or not. Click Yes to proceed.
  • Page 26 Note2: Shutting down or resetting the system while updating the BIOS will lead to system boot failure. The BIOSTAR BIOS Flasher is built in the BIOS ROM. To enter the utility, press <F12> during the Power-On Self Tests (POST) procedure while booting up.
  • Page 27: Ami Bios Beep Code

    Hi-Fi P61S2 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the [Y] key to restart system. 8. While the system boots up and the full screen logo shows up, press <Delete> key to enter BIOS setup.
  • Page 28: Troubleshooting

    Motherboard Manual ROUBLESHOOTING Probable Solution There is no power in the system. Make sure power cable is Power LED does not shine; the fan securely plugged in. of the power supply does not work Replace cable. Indicator light on keyboard does not Contact technical support.
  • Page 29 Hi-Fi P61S2 CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 30: Appendix: Spec In Other Languages

    Konform mit der SATA-Spezifikation Version 2.0 10 / 100 / 1000 Mb/s Auto-Negotiation Realtek RTL8111F Halb-/ Vollduplex-Funktion Unterstützt High-Definition Audio Audio-Unters ALC662 5.1-Kanal-Audioausgabe, Biostar Hi-Fi tützung PCI-E Gen3 x 16 @ x16 Steckplatz x1 (je nach CPU) Steckplätze PCI-E Gen2 x1-Steckplatz Onboard-Ans SATA2-Anschluss x4 Jeder Anschluss unterstützt 1 SATA2-Laufwerk...
  • Page 31 Rückseiten-E LAN-Anschluss USB2.0-Anschluss Audioanschluss Platinengröße 210 mm (B) X 295 mm (L) Biostar behält sich das Recht vor , ohne Ankündigung OS-Unterstüt Windows XP / Vista / 7 / 8 die Unterstützung für ein Betriebssystem zung hinzuzufügen oder zu entfernen.
  • Page 32: French

    Half / Full duplex capability Prise en Prise en charge de l'audio haute définition charge ALC662 Sortie audio à 5.1 voies, Biostar Hi-Fi audio HD Fente PCI-E Gen3 x 16 @ x16 (en fonction du CPU) Fentes Fente PCI-E Gen2 x1 Connecteur Chaque connecteur prend en charge 1 périphérique...
  • Page 33 Fiche audio Dimensions 210 mm (l) X 295 mm (H) de la carte Biostar se réserve le droit d'ajouter ou de supprimer Support SE Windows XP / Vista / 7 / 8 le support de SE avec ou sans préavis...
  • Page 34: Italian

    Negoziazione automatica 10 / 100 / 1000 Mb/s Realtek RTL8111F Capacità Half / Full Duplex Supporto audio High-Definition (HD) Supporto ALC662 audio HD Uscita audio 5.1 canali, Biostar Hi-Fi (a seconda del CPU) Alloggio PCI-E Gen3 x16 @ x16 Alloggi Alloggio PCI-E Gen2 x1 Connettori Connettore SATA2 Ciascun connettore supporta 1 unità...
  • Page 35 Porta USB2.0 Connettore audio Dimension 210 mm (larghezza) x 295 mm (altezza) i scheda Biostar si riserva il diritto di aggiungere o Sistemi operativi Windows XP / Vista / 7 rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.
  • Page 36: Spanish

    Funciones Half / Full dúplex Soporte de Soporte de sonido de Alta Definición ALC662 sonido HD Salida de sonido de 5.1 canales, Biostar Hi-Fi Ranura PCI-E Gen3 x16 @ x16 (dependiendo de la CPU) Ranuras Ranura PCI-E Gen2 x 1...
  • Page 37 Tamaño de 210 mm. (A) X 295 Mm. (H) la placa Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows XP / Vista / 7 / 8 soporte de cualquier SO con o sin aviso previo.
  • Page 38: Portuguese

    Realtek RTL8111F Capacidade semi/full-duplex Suporte para áudio Suporta a especificação High-Definition Audio ALC662 de alta Saída de áudio de 5.1 canais, Biostar Hi-Fi definição Ranhura PCI-E Gen3 x16 @ x16 (dependendo da CPU) Ranhuras Ranhura PCI-E Gen2 x 1 Conector SATA2...
  • Page 39 Tomada de áudio Tamanho 210 mm (L) X 295 mm (A) da placa Sistemas A Biostar reserva-se o direito de adicionar ou operativos Windows XP / Vista / 7 / 8 remover suporte para qualquer sistema operativo suportados com ou sem aviso prévio.
  • Page 40: Polish

    Działanie w trybie połowicznego / pełnego dupleksu Obsługa Obsługa High-Definition Audio ALC662 audio HD 5.1 kanałowe wyjście audio, Biostar Hi-Fi Gniazdo PCI-E Gen3 x16 @ x16 (w zależności od procesora) Gniazda Gniazdo PCI-E Gen2 x 1 Złącza Złącze SATA2 Każde złącze obsługuje 1 urządzenie SATA2...
  • Page 41 Back Panel Port LAN Port USB2.0 Gniazdo audio Wymiary 210 mm (S) X 295 mm (W) płyty Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows XP / Vista / 7 / 8 odwoływania obsługi dowolnego systemu operacyjne operacyjnego bez powiadomienia.
  • Page 42: Russian

    сеть Частичная / полная дуплексная способность Звуковая поддержка Звуковая поддержка High-Definition ALC662 жесткого 5.1канальный звуковой выход, Biostar Hi-Fi диска Слот PCI-E Gen3 x16 @ x16 (в зависимости от процессора) Слоты Слот PCI-E Gen2 x 1 Встроенны Каждый разъём поддерживает 1 устройство...
  • Page 43 Гнездо для подключения ода наушников Размер 210 мм (Ш) X 295 мм (В) панели Biostar сохраняет за собой право добавлять или Поддержка Windows XP / Vista / 7 / 8 удалять средства обеспечения для OS с или без предварительного уведомления.
  • Page 44: Arabic

    ‫اﻟﻜﺎﻣﻞ‬ ‫اﻟﻤﺰدوج‬ ‫ﻞ‬ ‫اﻟﻨﻘ‬ ‫إﻣﻜﺎﻧﻴﺔ‬ ‫ﻣﻦ‬ ‫اﻟﺘﻌﺮﻳﻒ‬ ‫ﻋﺎﻟﻲ‬ ‫اﻟﺼﻮت‬ ‫ﺗﻘﻨﻴﺔ‬ ‫ﺗﺪﻋﻢ‬ ‫ﻋﺎﻟﻲ‬ ‫اﻟﺼﻮت‬ ‫دﻋﻢ‬ ALC662 , Biostar Hi-Fi ‫اﻟﺼﻮت‬ ‫ﻟﺨﺮج‬ ‫ﻗﻨﻮات‬ ‫اﻟﺘﻌﺮﻳﻒ‬ ‫اﻟﻤﺮآﺰﻳﺔ‬ ‫اﻟﻤﻌﺎﻟﺠﺔ‬ ‫وﺣﺪة‬ ‫ﻋﻠﻰ‬ ‫اﻋﺘﻤﺎدا‬ ‫ﻋﺪد‬ PCI-E Gen3 x16 @ x16 ‫ﻓﺘﺤﺔ‬ ‫اﻟﻔﺘﺤﺎت‬ ‫ﻋﺪد‬ PCI-E Gen2 x 1 ‫ﻓﺘﺤﺔ‬...
  • Page 45 Hi-Fi P61S2 ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻋﺪد‬ CMOS ‫وﺻﻠﺔ ﻣﺴﺢ‬ ‫ﺑﺎﻟﻠﻮﺣﺔ اﻷﻣﺎﻣﻴﺔ‬ USB2.0 ‫ﻳﺪﻋﻢ آﻞ ﻣﻨﻔﺬ ﻓﺘﺤﺘﻲ‬ ‫ﻋﺪد‬ USB2.0 ‫ﻣﻨﻔﺬ‬ ‫ﻋﺪد‬ ‫اﻷﺣﻤﺮ‬ ‫ﺗﺤﺖ‬ ‫ﻣﺴﺘﻬﻠﻜﺔ‬ ‫ﻣﻨﻔﺬ‬ ‫ﻳﺪﻋﻢ وﻇﻴﻔﺔ ﺧﺮج اﻟﺼﻮت اﻟﺮﻗﻤﻲ‬ ‫ﺪد‬ ‫ﻋ‬ S/PDIF ‫ﻣﻨﻔﺬ ﺧﺮج‬ ‫ﻋﺪد‬ ‫ﻣﻨﻔﺬ ﻃﺎﺑﻌﺔ‬ ‫ﻋﺪد‬ ‫دﺑﻮس‬ ‫ﻣﻨﻔﺬ ﺗﻮﺻﻴﻞ اﻟﻄﺎﻗﺔ‬...
  • Page 46: Japanese

    低ピンカウントインターフェイス 最高3.0 Gb/秒のデータ転送速度 SATA 2 統合シリアルATAコントローラ SATAバージョン2.0仕様に準拠 10 / 100 / 1000 Mb/秒のオートネゴシエーション Realtek RTL8111F 半/全二重機能 HDオーディ ALC662 ハイデフィニションオーディオのサポート 5.1 チャンネルオーディオアウト, Biostar Hi-Fi オのサポート PCI-E Gen3 x16 @ x16スロット (CPUに依存) スロット PCI-E Gen2 x 1スロット SATA2コネクタ オンボードコ 各コネクタは1つのSATA2デバイスをサポートします ネクタ フロントパネルコネクタ...
  • Page 47 Hi-Fi P61S2 仕様 各コネクタは2つのフロントパネルUSB2.0ポートをサポ USB2.0コネクタ ートします 消費者IRコネクタ S/PDIFアウトコネクタ デジタルオーディオアウト機能をサポートします プリンタポートコネクタ 各コネクタは1つのプリンタポートをサポートします 電源コネクタ(24ピン) 電源コネクタ(4ピン) PS/2キーボード / マウス シリアルポート 背面パネル LANポート USB2.0ポート オーディオジャック ボードサイズ 210 mm (幅) X 295 mm (高さ) Biostarは事前のサポートなしにOSサポートを追加または OSサポート Windows XP / Vista / 7 / 8 削除する権利を留保します。...
