Introduction
It describes the basic prerequisites and procedures for installing the HP VISUALIZE
fxe (HP product number A4982A) graphics card into the supported workstations.
The HP VISUALIZE fxe 2D/3D graphics accelerator card is an entry-level graphics
card. It installs in a PCI 2X(64 bits wide 33Mhz/66Mhz) slot in an HP-UX
workstation backplane. It uses a standard 15-pin miniature D-Sub receptacle
connector to connect to a video monitor cable. It supports resolutions of:
Table 1-1.
Type Resolution
1 1280x1024
2 1024x768
3 1600x1200
4 1600x1024
See your workstation Owner's Guide for specific installation instructions for your
particular workstation.
6
Frequency
75Hz VESA
75Hz VESA
75Hz VESA
76Hz VESA
Chapter 1
