Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7527F/Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Wrench easy and 5 being difficult).
Page 2
LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
Page 3
Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 6pcs Headboard Bolt Ø5/16" x 1-1/2" #2 x 2pcs #B x 6pcs Headboard Leg L/R Lock Washer Ø5/16"...
Page 4
Exploded View Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). # A x 6pcs #B x 6pcs # C x 6pcs Page 4 of 6...
Page 5
Attach threaded studs (#F) to the headboard (#1) and footboard (#3), then align side rails (#4) to the threaded studs. Secure by using half moon washers (#G) and hex nuts (#H). #F x 8pcs # G x 8pcs #H x 8pcs Attach support legs (#6) to the slats (#5).
Page 6
Align slats (#5) to the side rails (#4), then secure by using screws (#E). #E x 6pcs ASSEMBLY IS COMPLETED Page 6 of 6...
