ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
CM7529T
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev: 19-04-10
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7529T
Summary of Contents for Furniture of America CM7529T
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7529T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Headboard Leg (Left) Bolt ɸ1/4" x 3-1/8" #2 x 1pc #B x 8pcs Headboard Leg (Right) Barrel Nut ɸ1/4"...
- Page 4 #9 x 2pcs #11 x 1set Side Rail Twin Slat Kit (10pcs) #10 x 2pcs Support Leg Page 4 of 8...
- Page 5 Attach dowels (#F) on each end of the bar beds (#5,6), then align bar beds (#5,6) to the headboard legs (#1,2). Secure by using screws (#C). #C x 6pcs #F x 12pcs Insert dowels (#F) to each ends of the footboard panel (#7), then align footboard panel (#7) to footboard legs (#3,4).
- Page 6 Align side rails (#8,9) to the headboard (#1,2), then insert barrel nuts (#B) to the inner side holes of the side rails (#8,9). Secure by tightening bolts (#A) onto barrel nuts (#B). #A x 4pcs #B x 4pcs Align support legs (#10) to the side rails (#8,9), then #D x 4pcs secure by tightening bolts (#D) to hex caps (#E).
- Page 7 Insert dowels (#F) onto side rails (#8,9), then align side rails (#8,9) to each other as shown in the diagram. #F x 2pcs Secure side rails (#8,9) to support legs (#10) by tightening bolts (#D) onto hex caps (#E). #D x 4pcs #E x 4pcs Page 7 of 8...
- Page 8 Align footboard (#7) to the side rails (#8,9), then insert barrel nuts (#B) to the side holes of the side rails (#8,9). Secure by tightening bolts (#A) onto barrel nuts (#B). #A x 4pcs #B x 4pcs Align slats (#11) onto side rails, then secure by using screws (#G).
