Siemens SIMATIC NET RUGGEDCOM RSL910 Installation Manual page 12

1
2
3
4
5
1
2
3
4
5
6
7
8
9
10
Figure 1.1
POWER LED
ALARM LED
Console Ports
Communication Ports
Failsafe Alarm Relay
Power Supply Terminal Blocks
RUGGEDCOM RSL910
Installation Manual, 04/2022, C79000-G8976-1305-13
POWER LED
ALARM LED
USB Console Port
[Optional] SFP (100/1000Base-TX/FX/SX/LX) Ethernet Ports
Copper (10/100Base-TX) Ethernet Ports
Universal EoVDSL Terminal
RS232 Console Port (Serial)
Failsafe Alarm Relay
Chassis Ground Connection
Power Supply Terminal Block
RUGGEDCOM RSL910
6
7
8
Illuminates green during boot up and when power is supplied to the
device.
Illuminates red when an alarm condition exists.
The console ports (serial and USB Type-B) are for interfacing directly
with the device and accessing initial management functions. For
information about connecting to the device via the serial console
port, refer to "Connecting to the Device (Page
Communication ports in general receive and transmit data, as
well as provide access to the RUGGEDCOM ROS Web interface.
For more information about the various ports available, refer to
"Communication Ports (Page
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 13)"
• "Failsafe Alarm Relay Specifications (Page 32)"
Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to
13)" and "Power Supply Specifications (Page
Introduction
1.2 Description
9
10
19)".
23)".
"Connecting Power (Page
31)".
3
