- Page 1 Product Information Manual PEDO Bench Includes Models: PB4000 & PB4001 PB4000 PB4001 12900 44th Street North Clearwater, Florida 33762 800-255-2693 * 727-561-9292 FAX: 727-561-9393 SALES PBM-001 FAX: 727-573-1682 SERVICE Rev 2 www.boydindustries.com...
-
Page 2: Table Of Contents
Table of Contents Title Page Table of Contents Introduction Application of Product Warranty Statement Safety Precautions About Your Product Description of Product Line General Product Information Product Specifications Feature Operation Drawer Removal / Installation and Adjustment Unpacking and Installation Procedure Light Post Installation (Optional) General Maintenance and Care Cleaning Information... -
Page 3: Introduction
This product is designed to allow dental procedures to be performed in a horizontal position with an adjustable back rest and head rest. The PEDO bench has built in storage for non-flammable items. The delivery system (PB4000 only) is located close to the head of the bench (either left or right hand are available) to allow for easy access. -
Page 4: Safety Precautions
Heed warnings: Adhere to all warnings and cautions on the equipment and in the manual. Accessories: Do not use any accessories not recommended by Boyd as they may cause hazards. Cleaning: See General Maintenance and Care section ... -
Page 5: Description Of Product Line
Note: Do not sit on back of seat section. This section is not designed to support the full weight of patient. Do not lift or slide bench using back section or seat upholstery. Warning: Do not modify this equipment without authorization from Boyd Industries, Inc. PBM-001 Rev 2... -
Page 6: Product Specifications
About Your PEDO Bench (Continued) Product Specifications PB4000 & PB4001 76.00 21.50 18.00 25.00 46.00 Note: Headrest height is adjustable TOP VIEW approximately 6”. 27.00 6.50 SIDE VIEW PBM-001 Rev 2... -
Page 7: Feature Operation
About Your PEDO Bench (Continued) Feature Operation Headrest: The headrest will adjust in and out to comfortably accommodate the patient. Foot protector: The foot protector snaps on and off for ease of cleaning and replacement. Backrest: Activate the release lever on the bottom of the back to position the back section. Note: Refer to Delivery Unit Product Manual (DSM- 001) for handpiece instrumentation package. -
Page 8: Drawer Removal/Installation And Adjustment
About Your PEDO Bench (Continued) Drawer Removal/Installation and Adjustment Drawer Removal: Pull drawer all the way out. Press and hold release levers (2) on bottom front of drawer and lift drawer upward in front until it is free from slider. Discontinue holding release levers. - Page 9 Unpacking Procedure Preassembly Check: Open shipping cartons carefully and check to see that all parts are received and have not been damaged during shipping. Unpacking PEDO Bench: Remove the plastic banding from the carton. Remove the carton top section. ...
-
Page 10: Light Post Installation (Optional)
The light post installs in the location shown below on either side of the bench for units manufactured after January 2012. Call Boyd Industries for information on attaching a light post on units manufactured prior to this date. Benches ordered with the light post option will arrive with the T-nuts installed and holes cleared in the cabinet to attach the light post in the location requested. -
Page 11: General Maintenance And Care
Use only cleaners and disinfectants approved for cleaning vinyl. Do not use strong or harsh cleaners as they may cause the vinyl color to fade. Apply the cleaner to a towel, not directly to the vinyl. Refer to vinyl manufacturer’s data on Boyd’s website for cleaning products. - Page 12 Boyd Industries, Inc 12900 44th Street N Clearwater, FL 33762 U.S.A PBM-001 Rev 2...
