Air-Operated 1:1 Oil Pump
With Extension Kit – 4.8 GPM
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #58252
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ironton 58252
Summary of Contents for Ironton 58252
- Page 1 With Extension Kit – 4.8 GPM Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #58252 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Pump ..........................8 Assembly Instructions .......................... 9 Parts List .............................. 10 Parts List .............................. 12 Before Each Use .......................... -
Page 4: Intended Use
Intended Use The Ironton Air-Operated 1:1 Oil Pump can be used to transfer lubrication oil, waste oil, and antifreeze liquids. Packaging Contents Part# Description Quantity 1701001 Air-operated pump ET10000 Extension tube Technical Specifications Property Specification Compression ratio Operating pressure (psi) 70-115 Max. - Page 5 ⚠WARNING This product may contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm. Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm.
-
Page 6: Specific Operation Warnings
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Air vents on the tool often cover moving parts and should be avoided. Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety goggles (not safety glasses) with side shields, or when needed, a face shield. - Page 7 Wear ANSI Z87.1 compliant goggles and other protective gear while operating. Do not exceed the maximum working air pressure of 115 PSI. Never point the dispenser at people or animals. Do not use the pump near open flames. Do not smoke during this operation. ...
-
Page 8: Main Parts Of Pump
Main Parts of Pump Page 8 of 19... -
Page 9: Assembly Instructions
Assembly Instructions DIRECTLY FIT PUMP INTO DRUM • Insert the suction tube of pump into the drum and secure with ring nut. Suitable for commercial drums with 57 diameter hole and threading 2'' BSP. • Fit an oil delivery tube for oil outlet of the air operated pump using only high quality tubes (normally 1/2'' or 3/4'', according to DIN-SAE norms), by means of 1/2'' BSP threading fitting. -
Page 10: Parts List
Parts List Part# Description Quantity Part# Description Quantity Oil pump Rigid suction tube Wall bracket Spring circlip Pump Ball adapter Flexible Valve seat suction hose Suction hose Filter adapter Bung adapter Page 10 of 19... - Page 11 1. Secure the bracket to the wall using the dowels at about 1200mm height appropriate for the tank's dimensions. Make sure that the wall is solid and thick enough for the dowels. Do not interfere with hydraulic tubes or electric lines. 2.
-
Page 12: Parts List
CONNECT THE PUMP WITH OTHER ACCESSORIES: Parts List Part# Description Oil pump Bung adapter Oil pistol Hose with fitting Air hose with quick coupling Drum 7 (7-1, 7-2, 7-3) Filter, pressure regulator, and lubricator Page 12 of 19... -
Page 13: Before Each Use
Before Each Use ⚠WARNING Inspect before each use; check that all connections are tight and secure. Never use if parts are damaged or broken; replace damaged or broken parts before operating. Disconnect air hose and relieve air pressure before servicing. Operating Instructions ⚠WARNING ... -
Page 14: Maintenance
• Handling and storage of the new pump do not require any special procedures. However after the pump has been used, empty the used oil in the suction tube into an appropriate container. This is done by over-turning the pump. •... -
Page 15: Parts Diagram
Parts Diagram Page 15 of 19... -
Page 16: Parts List
Parts List Part# Description Qty. Part# Description Qty. Air motor cover Piston shaft Piston Washer Air motor shell inside Spring shell Air motor shell outside Spring Bracket Spring seat Air control center Trip shoe guide Slider Press piece Gasket Soft gasket Outlet Securing washer Ball... -
Page 17: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 18: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of 90 days date of purchase. - Page 19 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 19 of 19...
