Alan HP108/408 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Index
Main indicators/controls .............................................................................................................................................................................................................................4
Accessory installation ................................................................................................................................................................................................................................7
Recharge of the battery pack ....................................................................................................................................................................................................................8
Care and maintenance ..............................................................................................................................................................................................................................9
Base functions ...........................................................................................................................................................................................................................................9
HP108/408 modes .....................................................................................................................................................................................................................................9
Functions of the menu key ........................................................................................................................................................................................................................9
Technical specifications ...........................................................................................................................................................................................................................15
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HP108/408 and is the answer not in the manual?

Questions and answers

Related Manuals for Alan HP108/408

Summary of Contents for Alan HP108/408

  • Page 1: Table Of Contents

    Index Main indicators/controls .............................................4 Accessory installation ..............................................7 Recharge of the battery pack ............................................8 Care and maintenance ..............................................9 Base functions ................................................9 HP108/408 modes ..............................................9 Functions of the menu key ............................................9 Technical specifications ............................................15...
  • Page 3 › desktop charger communications are needed. › adaptor HP108/408 is supplied with many functions, such as ‘Busy Channel Lock Out’, › 1 belt clip 180 memory channels, tx power selectable to 5W (high); some of its features › user manual are programmable to customize the equipment according to your needs.

  • Page 4: Main Indicators/Controls

    MAIN INDICATORS / CONTROLS HP 08 1. ANTENNA 2. ON/OFF/VOLUME KNOB: to turn on/off the radio and adjust the volume. 3. LED: lights red during the transmission and green in reception. 4. DISPLAY LCD: shows the operating status of the radio. 5. LOUDSPEAKER 6. ALPHANUMERICAL KEYPAD 7.
  • Page 5 HP 08 14. PTT: push it to transmit (led lights red) and release it to receive (green led). 15. BACKLIGHT BUTTON: push it to activate the display scan and keypad Backlight. If the selective call is enabled, push the button to send it; if a tone is enabled, push this step button to send the tone.
  • Page 6 LCD DISPLAY The LCD display continuously shows information on the operating status of the radio. ICON FUNCTION OPERATION Press F Keypad lock (hold it down for 2 seconds) Stored channels Push V/M Press F , 9 sel and select menu Automatic switch off Press F , 9 sel and select menu Keypad beep...

  • Page 7: Accessory Installation

    ACCESSORY INSTALLATION Installing Unscrew the belt clip (A), match the two guides of the battery pack into the grooves of the radio (B) and hook the battery pack with the battery holder (C). Installing/removing the battery pack Screw the belt clip. To remove it, unscrew the belt clip, unhook the battery holder and remove the battery pack.

  • Page 8: Recharge Of The Battery Pack

    Recharge of the battery pack: 1. Connect the jack of the wall adaptor into the desktop charger plug. HP108/408 is supplied with a Li-Ion battery pack, 7,4V 1600mAh. 2. Connect the socket of the wall adaptor to a mains power socket. Before its first use, the battery pack is not completely charged.

  • Page 9: Care And Maintenance

    CARE AND MAINTENANCE HP108/408 MODES 1) Memory channel mode (CH) - Channel name displayed Clean the radio with a soft cloth. Do not use alcohol or abrasive substances! With CH mode, you can access the stored channels: select the stored When you do not use the equipment, cover the MIC-SP connector.
  • Page 10 (to activate one of these modes, follow the general procedure described in par. LOCK (Keypad lock) K+S /PTT/KEY/ALL ‘General use of the menu’ at page 9). MSGSET (Message edit) Programmable Channel groups NAME (Channel name displayed) FREQ/ALPHA NM SET (Channel name edit) Programmable When this function is enabled, the stored channels belong to groups of chan- nels.
  • Page 11 Keypad tone (BEEP) › PTT: Lock of PTT button to avoid accidental transmissions › KEY: Keypad lock to avoid accidental pressures. When you press any key, a beep is heard. › ALL: Lock of all the keys. To activate/deactivate this tone, enter the menu 06 (BEEP) and follow the To confirm and exit push 9 sel.
  • Page 12 Welcome message (OPNMSG) tion mode. To activate/deactivate the TOT, enter menu 21 and use the ▲/▼ buttons for With this function you can set what will be displayed when you turn on the the selection (from 6 sec to 7 min). radio. TXSTOP (menu 22): if enabled, it is not possible to transmit. . Select menu 15 and choose amongst these options: ›...
  • Page 13 233.6 communicate only with the other users set on the same frequency and on 88.5 136.5 183.5 241.8 the same CTCSS/DCS tone. HP108/408 has 50 CTCSS tones and 107 DCS 91.5 141.3 186.2 250.3 codes available (I/N Inverted – Normal).
  • Page 14 Note: in this case, PRI disappears from the display. All the channels that do not show PRI on the display are excluded from the HP108/408 can scan the previously set channels for activity. scanning. There are three types of scanning: ›...

  • Page 15: Technical Specifications

    TECHNICAL SPECIFICATIONS General Characteristics Units Value/Measurements Frequency HP108: from 136 to 174; HP408L: from 400 to 470; HP408H (export version): from 465 to 520 Number of Programmable Channels Channel Spacing 12.5 Rated Power Supply Battery Capacity Li-Ion 1.600 5% on TX at the maximum power Duty Cycle hours 5% on RX at 60 % of the maximum rated A.F.
  • Page 16 Squelch Sensitivity (SINAD) Selectivity (Adjacent Channel) At least -65 / -75 Spurious Response Rejection > 70 Intermodulation > 65 Hum & Noise Suppression < -45 / < -40 Audio Output (1 KHz at 5% T.H.D.) Mechanical Specifications Size (Battery Pack Included) 97 x 53 x 33 (HxLxD) Weight (Battery Pack Included) Battery...
