VX7AI

VULCAN

Mobile DVR User Manual

Contact

Mail

IVS, Inc. dba AngelTrax

119 South Woodburn Drive

Dothan, Alabama 36305

Telephone

1.800.673.1788

Fax

334.692.4606

Online

www.angeltrax.com

03/2020 - SPECIFICATIONS, FEATURES AND APPLICATIONS OF USE ARE SUBJECT TO CHANGE WITHOUT NOTICE.

SERIES

™

Notice

The information in this manual is subject

to change without notice. AngelTrax

reserves the right to develop and update

current and future products, instructions

and materials. Updates to instructions

and materials will be available for

AngelTrax customers at

www.angeltrax.com/support.

The purpose of this manual is to aid the

user in the operation of a Vulcan Series

MDVR. The user should have a basic

understanding of computer operation

and basic knowledge of how to connect

peripherals and configure settings.

Under copyright laws, the content

of this manual may not be copied,

photocopied, reproduced, translated

or reduced to any electronic medium

or machine-readable form, in whole

or in part, without prior written

consent of IVS, Inc. dba AngelTrax,

Need help?

Do you have a question about the VULCAN Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AngelTrax VULCAN Series

Page 1 AngelTrax customers at copyright 2020. www.angeltrax.com/support. The purpose of this manual is to aid the 334.692.4606 user in the operation of a Vulcan Series Online MDVR. The user should have a basic www.angeltrax.com understanding of computer operation and basic knowledge of how to connect peripherals and configure settings.
Page 2 MOBILE DVR USER MANUAL The following instructions should be included in your Vulcan Series MDVR packaging. Please follow these instructions carefully when configuring camera settings for your MDVR. ATTENTION: Required Menu Settings NOTE: The CP4 extension cable must be installed, and all cameras must be installed and connected prior to entering menu settings.
Page 3 30 . . Surveillance 37 . . Collection 40 . . Alarm 46 . . Maintenance 48 . . External G Sensor Setup 03/2020 - Specifications, features and applications of use are subject to change without notice. 1.800.673.1788 | www.angeltrax.com |...
Page 4 THIS PAGE INTENTIONALLY LEFT BLANK...
Page 5 WARNING: Vulcan Series hard drives and SD cards by unauthorized modifications. must not be formatted with your computer. To ensure compatibility with the unit and FlexPlay Pro 8 playback software, Vulcan Series hard drives and SD cards must be formatted through your Vulcan Series MDVR. Abbreviations Term...
Page 6 Storage can be The compact, economical Vulcan™ Series VX7AI MDVR backed up to an optional fireproof box. is tested and proven to represent the AngelTrax name for quality, reliability and performance. MULTIPLE CAMERA TYPES DELAY-OFF SETTING...
Page 7 6) Designed for convenient operation and enhanced voltage, short circuit and over current. with optional components: Vulcan Series CP4 3) Capable of recording up to two (2) solid-state Touchscreen backing and firmware control SD cards, available in 128GB up to 512GB...
Page 8 • 6 channels D1, WD1, 720P, or up to 1080P • 6 AHD channels 1080P @15fps • 1 channel IP up to 1080P • 6 AHD channels 720P @30fps • Compatible with Vulcan Series CP7AI • 1 IP channel 1080P @30fps Dual Windshield Camera DRIVER ACTION DETECTION...
Page 9 • Headway Monitoring Warnings (HMW) Operating humidity • Blind Spot Detection (BSD) • 10%~90% humidity • Driver Status Monitor (DSM): Fatigue/phone use/ smoking/distraction • Facial recognition sign-in/sign-out 03/2020 - Specifications, features and applications of use are subject to change without notice. 1.800.673.1788 www.angeltrax.com...
Page 10 • Vulcan Series Uninterruptible Power Supply Extension Cable 16.4' • Serial I/O Cable for VX7AI • VULRS232 4 Pin to 10 Pin Adapter Cable • Camera Cable Pigtail for VX7AI for CP4 Monitor from Vulcan Series V5SD or VX7AI MDVR...
Page 11 VX7AI VULCAN™ Series Vulcan Series VX7AI ™ Page 2 of 3 03/2020 - Specifications, features and applications of use are subject to change without notice. 1.800.673.1788 www.angeltrax.com...
Page 12 MOBILE DVR USER MANUAL Vulcan Series VX7AI ™ Page 3 of 3...
Page 13 THIS PAGE INTENTIONALLY LEFT BLANK 03/2020 - Specifications, features and applications of use are subject to change without notice. 1.800.673.1788 | www.angeltrax.com |...
Page 14 MOBILE DVR USER MANUAL FIRMWARE OVERVIEW Local Management The Vulcan Series MDVR protocol supports three types of local setting methods: 1) Monitor Connect the monitor to the mobile DVR and make sure it can play real-time output image. Then connect the mouse to the USB interface at the front panel to set MDVR parameters.
Page 15 The entered contents will not be written to the been entered. edit box. . Press Enter or left click 6) Move cursor to mouse to delete the previous input contents. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 15 1.800.673.1788 www.angeltrax.com...
Page 16 MOBILE DVR USER MANUAL Live Preview Interface Enter the Live Preview interface and click anywhere in the video window. User can hide or display the menu. • Select Single, Quad or 9-Split display option. • Click to switch to the playback interface and play the last two minutes of recording.
Page 17 • Select Read old or Read new SMS messages. An SMS message can be sent by business platform but cannot be edited or sent automatically. 03/2020 - Specifications, features and applications of use are subject to change without notice. 1.800.673.1788 www.angeltrax.com...
Page 18 MOBILE DVR USER MANUAL System System to display the following information: Click Version Info • Software/hardware version, device serial number, MAC address Modules • 3G/4G communication module (running status, SIM, dial status, signal strength) • Wi-Fi module (signal strength, ESSID, IP address, module status) •...
Page 19 User name and password are required for access if user (User management can be set in Setup interface.) has clicked to log out. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 19 1.800.673.1788 www.angeltrax.com...
Page 20 MOBILE DVR USER MANUAL Recording Search RECORDING (REC) SEARCH Recording: main recording or sub recording (Mirror recording is not available.) Select the date of the recording to be reviewed. Search condition is assorted by recording type, not by storage means. •...
Page 21 • AVI data refers to .avi mode, which can be played in any player. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 21 1.800.673.1788 www.angeltrax.com...
Page 22 MOBILE DVR USER MANUAL RECORDING PLAYBACK Playback. Click Play video by dragging the time bar. Click to switch to different channels. Select play, pause, fast forward (x2, x4, x8, x16), fast reverse (x2, x4, x8, x16), slow play (1/2, 1/4, 1/8, 1/16) or frame play.
Page 23 After selecting Alarm log, user can play the log if it is linked with recording. Alarm Log with video can be played or exported. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 23 1.800.673.1788 www.angeltrax.com...
Page 24 MOBILE DVR USER MANUAL Basic Setup REGISTRATION INFORMATION Device Info • Not Applicable. Vehicle Info • Vehicle Number: Will be displayed when the HDD is connected to the playback station equipped with FlexPlay Pro 8 playback software. • Vehicle L P: Input manually. •...
Page 25 If these settings are selected, the MDVR will shut down only when Ignition is off and the Timer end time is reached. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 25 1.800.673.1788 www.angeltrax.com...
Page 26 • CAUTION: The admin password can be edited. Save the new password in a secure location. If the password is lost or forgotten, the unit must be reset by AngelTrax. Normal users may add, edit or delete normal users and query parameters but not set permissions.
Page 27 Password: Manually input the password. Scroll down for the following field: Static IP: Select to use static IP, or MDVR will get dynamic IP. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 27 1.800.673.1788 www.angeltrax.com...
Page 28 MOBILE DVR USER MANUAL COMMUNICATION Module: Select the module type and set dialing parameters. When entering the dialing setup interface, the system will automatically search the wireless module type. If no module is available, No Service will be displayed. Server Type: Displayed but non-selectable Network Type: Default is Mix.
Page 29 MDVR coupled with MotoTrax, AngelTrax technicians will establish the connection to the MDVR prior to shipment. To connect an existing MDVR to MotoTrax, provide the API key listed on this menu to AngelTrax Technical Support by calling 1.800.673.1788. APPLICATION FTP Enable: Click to enable FTP.
Page 30 MOBILE DVR USER MANUAL Surveillance LIVE VIEW Preview: Live Preview allows the audio captured by the cameras to be heard on the CP4 monitor. This option needs to be OFF if the CP4 is permanently mounted in the vehicle as it can result in feedback if left on. Image Setup: Select one of the two buttons in the upper right corner to allow the camera view to be flipped vertically or horizontally (Supports IP cameras with N9M...
Page 31 Select the camera channel number for each channel to be displayed. Select the display duration in seconds. Live OSD: Select data to be displayed live on the CP4. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 31 1.800.673.1788 www.angeltrax.com...
Page 32 MOBILE DVR USER MANUAL RECORD - GENERAL Overwrite 1) By Capacity: The SD cards will begin overwriting the oldest data once the cards have less than 2GB of free space. Each overwrite will delete a 256MB file. 2) By Day: The MDVR will save data for the number of days selected, if the data does not exceed the amount of storage space available on the SD cards.
Page 33 Files recorded without alarms are set at I frame only. Alarm Quality: The alarm image is different from the normal recording image. Encode Mode: Select VBR or CBR mode. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 33 1.800.673.1788 www.angeltrax.com...
Page 34 MOBILE DVR USER MANUAL Dual Stream Record • Record Storage: Select Internal (built-in) SD card or External SD card. • Record Mode: • Loop-record - The unit records SD card 1 to full capacity, then proceeds to record to SD card 2.
Page 35 Found IPC's will show here Network Setup • To change the channel’s IPC link, enter the desired IP address in the IP address field. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 35 1.800.673.1788 www.angeltrax.com...
Page 36 MOBILE DVR USER MANUAL SURVEILLANCE – PTZ SETTING PTZ (Pan-Tilt-Zoom) Advanced settings for PTZ capable IP cameras which allows the user to remotely control the camera's movements in real time. Channel: Indicates channel number, includes IP and non-IP channels. Enable: Click box to enable the channel to operate and test a PTZ camera.
Page 37 Copy to: Select from the drop down whether the configuration is to be applied to other sensors. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 37 1.800.673.1788 www.angeltrax.com...
Page 38 MOBILE DVR USER MANUAL Serial Port 232-1 and 232-2: Select three axis sensor, expansion, 485 bus or GPS data. 485-1 and 485-2: Select PTZ, control panel, 485 bus or GPS data. Select Baud Rate for each: 2400-115200 (9 classes available for selection). Speed Unit: Select KM/H or MPH.
Page 39 Windows system. ® 2) Select Server to connect to the playback station and view video. Collection - ECO-Driving (Currently not available) 03/2020 - Specifications, features and applications of use are subject to change without notice. | 39 1.800.673.1788 www.angeltrax.com...
Page 40 MOBILE DVR USER MANUAL Alarm ALARM - BASE Speed Alarm Name: The current name is Overspeed. Enable: Click to enable or leave empty to disable. Alarm type: Select Important or General. Trigger: Click Setup to display the following screen. Early Difference: Enter the difference in speed to be reached when video begins recording pre-alarm data.
Page 41 Effective Time: Set the duration of alarm overlap time. This will keep alerts in this time frame from triggering separate alarms. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 41 1.800.673.1788 www.angeltrax.com...
Page 42 MOBILE DVR USER MANUAL Channel: Link to recording channel, optional. Post Recording: Select the time frame to be recorded after the alarm has been removed. Lock: Click to link recording lock when there is alarm. 3G Network: When set as sensor trigger dial mode, it enables 3G network as it triggers alarm.
Page 43 NOTE: Only one alarm type will be recognized as valid during an activated alarm. If more than one alarm type is triggered simultaneously, only one alarm will be recorded. 03/2020 - Specifications, features and applications of use are subject to change without notice. | 43 1.800.673.1788 www.angeltrax.com...
Page 44 MOBILE DVR USER MANUAL Alarm Linkage Channel: Select channels to be recorded when alarm is triggered. Selected channels will display alarm data. Post Recording: Use the drop down to set the amount of time to record after the alarm is canceled. Lock: Select to lock alarm files.
Page 45 • Lane Departure Warnings (LDW) • Forward Collison Warnings (FCW) • Headway Monitoring Warnings (HMW) • Yawns • Pedestrian Collision Warning (PCW) 03/2020 - Specifications, features and applications of use are subject to change without notice. | 45 1.800.673.1788 www.angeltrax.com...
Page 46 MOBILE DVR USER MANUAL Maintenance After login, click Setup and click Maintenance. CONFIGURATION In the configuration page, user can export and import the configuration file. Insert flash drive to export the configuration file. Insert flash drive to import configuration file into the MDVR.
Page 47 MDVR. If a drive must be formatted, it has to be done in the MDVR. If you need assistance, please contact the AngelTrax Technical Support Department by phone at 1.800.673.1788 or through the Contact Us form on the AngelTrax website: www.angeltrax.com/contact.
Page 48 MOBILE DVR USER MANUAL EXTERNAL G SENSOR SETUP NOTICE: The SCCM3 cable is needed to connect the VX7AI to the GFACC external G Force sensor. INITIAL SETUP Setup > Collection > Serial Port > General • On RS485-2, select 3Axis ACC with a port of 19200. •...
Page 49 To ensure • Change the previous file folder name “dvrupgrade” to compatibility with the unit and FlexPlay Pro 8 playback software, Vulcan Series hard drives and SD cards must “upgrade.” Change the file name be formatted through your Vulcan Series MDVR.
Page 50 NOTES 03/2020 - Specifications, features and applications of use are subject to change without notice.
Page 51 NOTES 1.800.673.1788 www.angeltrax.com...
