- Page 1 ELECTRIC OVEN INSTRUCTION MANUAL Read this manual carefully before operation Note: Pictures in this manual are for reference only. OV6200 Electronic controls - 60cm electric oven...
-
Page 2: Table Of Contents
Contents Contents..............User Instructions............Specification............Installing the appliance ..........Display panel............Maintenance............Useful Notes for Cooking........Disassembling / assembling the oven door..... Side rack installation instructions......Fitting on a power supply cable....... 19 Warranty & Service..........20... -
Page 3: User Instructions
User Instructions GENERAL WARNINGS Please carefully read all the instructions contained in this booklet. It provides you with important information regarding the safe installation, use and maintenance of the appliance as well as useful advice for getting the best out of your oven. - Page 4 The following items are potentially dangerous, and therefore, appropriate measures must be taken to prevent children and the disabled from coming into contact with them: Controls and the appliance in general. • Packaging (bags, polystyrene, nails, etc.). • The appliance immediately after use of the oven or grill due to the heat •...
-
Page 5: Specification
Service Centers authorised by Cardini must be contacted in the following cases: • If in doubt about the soundness of the appliance after removing it from the packaging; • If the power supply cord has been damaged or needs to be replaced;... -
Page 6: Installing The Appliance
INDICATOR LIGHTS The indicator lights situated above the control panel go on and off when the heating elements are energised or de-energised. During the thermostatic functioning of the oven, the neon light remains on until the pre-chosen temperature is reached and it goes off when the temperature has been reached. When the oven cools, the thermostat determines the re-energisation of the heating elements with consequent re-lighting of the indicator lights. - Page 7 IMPORTANT • During use the appliance becomes hot, care should be taken to avoid touching heating elements inside the oven. • Accessible parts may become hot during use. Young children should be kept away. • Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass as they can scratch the surface which may result in shattering of the glass.
- Page 8 WARNING: THIS APPLIANCE MUST BE EARTHED • Check that the power rating of the mains supply and circuit breaker are suitable for the maximum power of the appliance as indicated on the specification plate. • The cabling should not be accessible after installation. The oven must be earthed.
- Page 9 550 min SURFACE MOUNT Fig.1 Refer to page 6 for ventilation requirements Fitting Dimensions: General tolerances for fitting dimensions: 30 min Width: 560 +/- 1.5mm Heights: 589 +/- 2.5mm no back 23 min FLUSH MOUNT Fig.2 NOTE: Cabinetmaker shall verify all dimensions prior to manufacture of cabinets. NOTE: Building-in for Gas Hobs Mod.
-
Page 10: Display Panel
Display Panel Touch Button Description Display Description 1 Power 10 Function 2 Function 11 Time 3 Timer 12 Actual Temperature/Time 4 Temperature 13 Set Temperature 5 Light 14 Current Time 6 Plus/Minus 15 Safety Lock 16 Rapid Heat-up 7 OK 8 Rapid Heat-up 17 Cooking Duration Time 18 Rotisserie... - Page 11 Operation 1. Power button . To turn on/off the display panel. 2. Function button . Touch it to shift to a different function. When you shift to a new function, the current function will stop and cooking time must be reset. The function list is as follows: Note: These symbols will individually appear...
- Page 12 4. Time button a/ Press the time button for 3seconds in order to set current time. Adjust the time by pressing . And press to confirm setting. b/ Alarm setting. Press switch until keeps flashing. Display will show ”0:00”. Adjust time number by pressing and press to confirm setting.
- Page 13 Fig.7 Fig.6 Using the turnspit (optional - may not be included in all models) In the “CONVECTIONAL OVEN” models, the turnspit can be used in combination with the grill. After fitting the food on to the spit S, block it with the two forks F. then proceed as follows: −...
-
Page 14: Maintenance
Maintenance This appliance is for indoor use only, don’t use it outdoors. Important: Isolate your oven before cleaning or performing maintenance. To extend the life of your oven, it must be cleaned frequently and observe the following: • Do not use steam equipment to clean the oven. •... -
Page 15: Useful Notes For Cooking
WARNING: Ensure that the appliance is electrically isolated before replacing the lamp to avoid the possibility of electric shock. Useful Notes for Cooking The following table provides some hints for cooking issues: FAULTS CAUSES REMEDIES The upper crust is dark Not enough heat from the Use the natural convection and the lower part too... -
Page 16: Disassembling / Assembling The Oven Door
Disassembling / assembling the oven door To make it easier to clean the inside of your oven, the oven door can be removed, by proceeding as follows (fig. 11) • Open the door completely and lift the 2 levers “B” (fig.11-1); •... - Page 17 Clean the glass panes and other parts with a damp microfibre cloth and glass cleaner fluid as required. Wipe dry using a soft cloth. Fig.1 Fig.2 Fig.4 Fig.3 This product must not be disposed together with the domestic waste. This product has to be disposed at an authorized place for recycling of electrical and electronic appliances.
-
Page 18: Side Rack Installation Instructions
Side rack installation instructions 1. Right side rack, hook 1a is put into fixing position 2, then lift right side rack a little. 2. Press right side hook 1b into fixing position B. 3. Shelves and tray can be inserted into the side rack positions only. 4. -
Page 19: Fitting On A Power Supply Cable
Fitting on a power supply cable Opening the terminal board: • Using a screwdriver, prise on the side tabs of the terminal board cover • Pull open the cover of the terminal board To install the cable, proceed as follows: •... -
Page 20: Warranty & Service
Warranty & Service For warranty information, please visit the Cardini website: www.cardini.com.au For any service issues, please email our customer care team: service@cardini.com.au Rev A...
