New Package and Front Panel
Front view
Cover lock
Front view with cover
removed
Main memory
Processor
System board switches
Heat-pipe and Heat-sink
Rear view
(All icons shown here are for information, and do not necessarily appear on the
PC).
New Package and Front Panel
4
Parallel
Serial
USB
On/off button
Pause button
Status light
Activity light
Activity light
Hard disk drive
Display
Keyboard
Mouse
