HP Pavilion Media Center TV PC

Quick Setup

Your PC may look different from the ones shown here.
Component, connector location, type, and number vary by model.
Copyright © 2004–2006 Hewlett-Packard Development Company, L.P.
Printed in
www.hp.com
3

Speaker System

Refer to the instructions that came with your
speakers. Speakers may be sold separately.
5

TV Out

(TV connections are optional)
TV signal from computer to TV
TV
VIDEO IN
See the user documentation for TV display setup.
1

Keyboard and Mouse

4

TV In

If you use a cable or satellite set-top box,
Connect TV signal to computer
Cable or antenna
or
Signal
Signal
TV cable
6

Remote Sensor

Connect remote control receiver to computer.
Wireless option
Refer to the installation instructions included
with your keyboard and mouse.
or
hp
Search
Club
Internet
E-mail
pass the signal through the box.
S-video-type
cable or satellite set-top box
IN
S-VIDEO OUT
L
R
Signal
If you use a cable or satellite set-top box,
pass the signal through the remote sensor control cable.
or
2

Monitor

Refer to setup instructions that came with your monitor.
Monitors may be sold separately.
Composite-type
cable or satellite set-top box
or
IN
COMP VID
OUT
L
R
Signal
Signal
Cable or satellite set-top box
2
Remove tape
Adhere
to IR window
3
1
Remote sensor
control cable
4
