Berkshire 220
Thank you for choosing a Berkshire 220 telephone. You have selected
a carefully designed telephone that incorporates the very latest
technology, offering a stylish instrument and providing many years of
excellent service. This booklet will ensure you obtain the best use of
your telephone.
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Berkshire 220 and is the answer not in the manual?

Questions and answers

Related Manuals for ATL Berkshire 220

Summary of Contents for ATL Berkshire 220

  • Page 1 Berkshire 220 Thank you for choosing a Berkshire 220 telephone. You have selected a carefully designed telephone that incorporates the very latest technology, offering a stylish instrument and providing many years of excellent service. This booklet will ensure you obtain the best use of your telephone.

  • Page 2: Locations And Functions

    LOCATIONS AND FUNCTIONS MUTE Press to turn microphone off, for both handset and headset. TRANSFER To use for line transfer or intercom behind PBX system. REDIAL Press to dial the last dialed number. HEADSET AND A. LED will light up when the unit is in use. B.
  • Page 3 LOCATIONS AND FUNCTIONS HEADSET SOCKET Connect headset. HANDSET SOCKET Connect handset. LINE CORD SOCKET Connect telephone to wall jack. Ringer volume HIGH - LOW - OFF Handset / headset volume HIGH - MEDIUM - LOW SLOT FOR STAND STAND – 3 –...
  • Page 4 HI / LOW / OFF HANDSET / HEADSET VOLUME The base of the Berkshire 220 is fitted with a three position slide switch so that the volume of the handset / headset can be adjusted, the options are HI / MEDIUM / LOW...
  • Page 5 STAND INSTALLATION AND SETUP The Berkshire 220 can support two different tilt angles of 49° and 30°, see below ATTACHING THE STAND TO THE TELEPHONE This paragraph below illustrates an example of 49° angle installation with the stand. There are two sets of “bolt” on the top of the stand (A and B) and there are two sets of notches on the back of the phone.
  • Page 6 The procedure for attaching the stand to the telephone is as follows: Place the main body of the Berkshire 220 face down on a “soft” surface so as to not scratch the telephone. Slide the “A” bolt into the notch hole.
  • Page 7 – 7 –...

  • Page 8: Wall Mounting

    WALL MOUNTING The Berkshire 220 can be wall mounted if required, without the use of an additional bracket. When wall mounting you will have to change the position of the handset hook and fix the base unit to the wall, please follow the steps below.

  • Page 9: Receiving Calls

    For hearing aid users, an inductive coupler has been installed in the handset to improve audible efficiency. TRANSFER KEY (RECALL) Berkshire 220 telephones are provided with a ‘TRANSFER’ key, required by modern public and private exchanges, in order to gain access to various features such as ‘transferring a call’.
  • Page 10 MESSAGE WAITING & RINGING INDICATOR There are three versions of message waiting (MW) indication supported within the Berkshire 220 telephone (MW 3, 8 and 10). The telephone will automatically detect what type of MW you require so no user input is required.

  • Page 11: Compliance Notes

    4. The liability of ATL Telecom Limited will be limited to the cost of repair or complete replacement of the same defective instrument, at the discretion of the company.

  • Page 12: Manufacturer's Declaration

    MANUFACTURER’S DECLARATION ATL Telecom Limited declares that this product is in conformity with the Directive 2014/30/EU, a copy of the Declaration of Conformity is available upon request from ATL Telecom Limited.
