Summary of Contents for HyQuest Solutions OSS-B1

Page 1 OSS-B1 User Manual...
Page 2: Table Of Contents
Table of Contents Disclaimer Scope of Delivery Safety Instructions Introduction Part I Installation Part II Unpacking your OSS-B1 Current Meter ....................7 Operation Part III Maintenance Part IV Service and Recalibration ........................... 11 Troubleshooting Part V Repair Part VI Replacement of Cable Ends ........................14 Part List ................................
Page 3: I Disclaimer
HyQuest Solutions or KISTERS AG. Other product documentation and the information contained in it, names used may or may not be the trademarks of even if HyQuest Solutions has been advised of the their respective owners. possibility of such damages.
Page 4: Scope Of Delivery
3 m connecting lead, tools, oil, spare bearings, spare reed switch assembly § Rod: 1.8 m (3 × 0.6 m), 20 mm diameter, in canvas carry bag with point and base plate § Carry case (durable waterproof Pelican Case) © 2022 HyQuest Solutions © 2022 HyQuest Solutions...
Page 5: Safety Instructions
Before starting to work, you have to check the functioning and integrity of the system. § Check for visible defects on the OSS-B1, this may or may not include any or all of the following mounting facilities, connectors and connections, mechanical parts, internal or external communication devices, power supplies or power supply lines, etc.
Page 6: Part I Introduction
0.025 m/s to 10 m/s. One of the great features of the OSS-B1 is it can be used with 20 mm diameter wading rod and relocating device, streamlined suspension tube, portable winches and permanent cableway installations, with streamlined or ground feeling weights.
Page 7: Part Ii Installation
Installation Installation This chapter contains the following subsections: § Unpacking your OSS-B1 Current Meter Unpacking your OSS-B1 Current Meter This package should contain: § OSS-B1 Body § OSS-B1 Lead § Body Key § Fan type A (Fan type 1,2 and 4 are accessories) §...
Page 8: Part Iii Operation
Fan assembly. The capillary oil passage between the stainless steel axle (5) and Fan carrier (6), prevents entry of water to the bearings. A locknut on the shaft locates the bearings and sets the end float of the assembly. Figure 1 © 2022 HyQuest Solutions...
Page 10: Part Iv Maintenance
Maintenance Maintenance The maintenance of the OSS-B1 current meter can be divided in three sections as stated below. Section 1: Prior to discharge measurements Initial set up § Open the case and pick up the Fan assembly. § Undo the fan carrier.
Page 11: Service And Recalibration
§ Office service is required for the OSS-B1 current meter about once a month if it is used on a daily basis (i.e. Fully dismantle shaft assembly, fan carrier and fan; Clean each item using hot soapy water and then rinse with white spirit).
Page 12: Part V Troubleshooting
Check damaged O-rings (Figure No 9 and10) replace. Apply silicon grease before fitting. § Check damage spigot through reed switch assembly. Return to factory for repairs. © 2022 HyQuest Solutions...
Page 13 § § Faulty earth contact (12) (Figure Check spring compression. Remove Reed switch operating but signal not assembly and wipe clean contact passing to body. surfaces with silicon grease and re- assemble. © 2022 HyQuest Solutions...
Page 14: Part Vi Repair
In rare cases, a product may not be delivered in accordance with your order. In such cases HyQuest Solutions’ return and repair policy applies. For you as a customer, this means the following: 1. Contact HyQuest Solutions using the Repair Request Form made available online: https://www.hyquestsolutions.eu/fileadmin/Form/Telemetry_Solution_app.jpg.pdf...
Page 15 Position heat shrink sleeve centrally over grey cable insulation and fix in place Note: Repair to either plug end individually can be made also, by only cutting away the damaged end and following steps b, d & e. Figure 5 © 2022 HyQuest Solutions...
Page 16 2 and 7. However, the shortened ends of the cable might be difficult to assemble conveniently onto the current meter, and it is usually preferable to reconstruct the cable as detailed in figure 6. Figure 6 © 2022 HyQuest Solutions...
Page 22 2 - 3 metre Point WR04-01 Foot Plate WR04-02 Canvas Carrying Bag WR11L Fixing Screw SAN20-04 Screwdriver SC002-06 METER RELOCATING DEVICE, STAINLESS STEEL, TWO X 1 METRE SECTIONS Bottom Section RD01 Top Section RD02 Locking Tool RD03 © 2022 HyQuest Solutions...
Page 25: Part Vii Technical Data
Technical Data Technical Data Accuracy ±1 % § Each current meter individually calibrated in HyQuest Solutions’ calibration tank Calibration § Compliant with ISO 3455:1976 and ISO 2537:1988 § Calibration certificate delivered with each current meter Propeller The choice of fan / propeller depends on the specifics of the site such as discharge and the Specifications geometry of the riverbed or channel.
Page 26: Part Viii Obligations Of The Operator And Disposal
Instead, these old appliances must be collected separately and disposed of via the local collection and return systems. Integrated or provided batteries and accumulators must be separated from the appliances and disposed of at the designated collection point. © 2022 HyQuest Solutions...
Page 27 Obligations of the Operator and Disposal EU WEEE Directive As players in the environmental market, KISTERS AG and HyQuest Solutions are committed to supporting efforts to avoid and recycle waste. Please consider: Avoidance before recycling! Recycling before disposal! This symbol indicates that the scrapping of the unit must be carried out in accordance with Directive 2012/19/EU.
Page 28 Contact Data Europe | HyQuest Solutions (KISTERS AG) +49 2408 9385 0 info@hyquestsolutions.eu Australia | HyQuest Solutions Pty Ltd +612 9601 2022 sales@hyquestsolutions.com.au New Zealand | HyQuest Solutions NZ Ltd +64 7 857 0810 sales@hyquestsolutions.co.nz Latin America | HyQuest Solutions (KISTERS LATAM) +57 350 575 4079 sales-latam@hyquestsolutions.com...
