Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5 INTRODUCTION 5...
Page 6: Vehicle Identification Number
This number also ap- pears on the Automobile Information Disclosure Label affixed to a window on your vehicle. Save this label as a convenient record of your vehicle identification number and optional equipment.
Page 7: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....9 Ignition Key Removal ....9 Automatic Transaxle Ignition Interlock System .
Page 8 8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information ....18 Transmitter Battery Service ....19 Vehicle Theft Alarm .
Page 9: Things To Know Before Starting Your Vehicle 7
A WORD ABOUT YOUR KEYS CAUTION! An unlocked car is an invitation to thieves. Always remove the key from the ignition, lock the doors, and close the windows when leaving the vehicle unat- tended. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9 Ignition Key Removal Ignition Key Positions Place the shift lever in PARK and make sure that the...
Page 10: Automatic Transaxle Ignition Interlock System
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If you try to remove the key before you place the lever in PARK, the key may become trapped tempo- rarily in the key cylinder. If this occurs, rotate the key clockwise slightly, then remove the key as described.
Page 11: Replacement Keys
• Additional Sentry Keys or Mobil Speed Pass™ devices held too close to the ignition key when starting the vehicle may cause problems when attempting to start the vehicle. These devices cannot damage the Sentry Key System, but can cause a momentary problem when attempting to start the engine.
Page 12: General Information
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Turn the ignition Off and remove the first key. 2. Insert the second valid key and switch the ignition On within 15 seconds. After ten seconds a chime will sound and the Theft Alarm Light will begin to flash. Turn the ignition Off and remove the second key.
Page 13: Power Door Locks
WARNING! When leaving the vehicle always remove the key from the ignition lock, and lock your vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe personal inju- ries and death.
Page 14: Central Locking-If Equipped
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the door lock switch while the keys are in the ignition switch, and the driver’s door is open, the doors will not lock. Door Lock Plunger If the door lock plunger is down when you shut the door, the door will lock.
Page 15: Automatic Unlock On Exit-Only Available If Automatic Door Locks Are Enabled
The Automatic Door Locks can be disabled or re-enabled by performing the following procedure: 1. Close all doors and place the key in the ignition. 2. Cycle the ignition switch between OFF and ON/RUN and back to OFF 4 times ending up in the OFF position. Ignition Key Positions 3.
Page 16: Remote Keyless Entry - If Equipped
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Close all doors and place the key in the ignition. 2. Cycle the ignition switch between OFF and ON/RUN and back to OFF 4 times ending up in the OFF position. 3.
Page 17: To Lock The Doors
1. Press and hold the Lock button on the transmitter. 2. Continue to hold the Lock button, wait at least 4 but no longer than 10 seconds, then press the Trunk button. 3. Release both buttons. To lock the doors: The horn will chirp and the headlamps will flash once to acknowledge the lock signal.
Page 18: To Use The Panic Alarm
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To use the Panic Alarm: Press and hold the Panic Button for at least 1 second to activate the panic alarm. Press and hold the panic button a second time or unlock the door with the key (if equipped with central locking) to deactivate the alarm.
Page 19: Transmitter Battery Service
2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios. Transmitter Battery Service The recommended replacement batteries are CR2016. 1. Pry the transmitter halves apart with a dime or similar object.
Page 20: Tamper Alert
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To set the alarm: 1. Remove the keys from the ignition switch and get out of the vehicle. 2. Lock the door using either the power door lock switch, the key, or the Keyless Entry Transmitter and close all doors.
Page 21: Trunk Lock And Release
TRUNK LOCK AND RELEASE Trunk Release Button Use the key or the Remote Keyless Entry Transmitter to open the trunk from outside the vehicle. From inside the car the trunk lid can be released by turning the ignition ON and depressing the Trunk Release Button located on the instrument panel to the left of the steering wheel.
Page 22: Trunk Internal Emergency Release
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Trunk Internal Emergency Release Emergency Release NOTE: As a security measure, a Trunk Internal Emer- gency Release lever is built into the trunk latching mechanism. In the event of an individual being locked inside the trunk, the trunk can be simply opened by pulling on the glow-in-the-dark handle attached to the trunk latching mechanism.
Page 23: Occupant Restraints
The window controls on the driver’s door operate all windows. The driver’s window switch has an Auto Down feature. Press the window switch past the detent, release, and the window will go down automatically. To open the window part way, pull the window switch part way and release it when you want the window to stop.
Page 24: Lap/Shoulder Belts
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle up even though you are an excellent driver, even on short trips. Someone on the road may be a poor driver and cause a collision which includes you. This can happen far away from home or on your own street. Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision.
Page 25 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the front seat. Latch Plate THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 2. The seat belt latch plate is on the back of your seat. Grasp the latch plate and pull out the belt.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
Page 27: Seat Belt Pretensioners
WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as pos- sible and keep it snug.
Page 28: Enhanced Driver Seat Belt Reminder System (Beltalert)
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The pretensioners are triggered by the front airbag con- trol module (see Airbag Section). Like the front airbags, the pretensioners are single use items. After a collision that is severe enough to deploy the airbags and preten- sioners, both must be replaced.
Page 29: Seat Belts And Pregnant Women
4. Turn off the engine. A single chime will sound to signify that you have successfully completed the pro- gramming. The Enhanced Warning System (BeltAlert) can be reacti- vated by repeating this procedure. NOTE: Although the Enhanced Warning System (BeltAlert) has been deactivated, the Seat Belt Warning Light will continue to illuminate while the driver’s seat belt remains unbuckled.
Page 30: Driver And Right Front Passenger Supplemental Restraint System (Srs) - Airbag
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Driver and Right Front Passenger Supplemental Restraint System (SRS) - Airbag Front Airbag Components This vehicle has front airbags for both the driver and front passenger as a supplement to the seat belt restraint systems.
Page 31 The seat belts are designed to protect you in many types of collisions. The front airbags deploy only in moderate to severe frontal collisions. But even in collisions where the airbags work, you need the seat belts to keep you in the right position for the airbags to protect you properly.
Page 32 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 33 • The airbag control module also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or RUN positions. These include all of the items listed above except the knee bolster, the instrument panel, and the steering wheel and column.
Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If A Deployment Occurs The airbag system is designed to deploy when the airbag control module detects a moderate-to-severe frontal col- lision, to help restrain the driver and front passenger, and then to immediately deflate. NOTE: A frontal collision that is not severe enough to need airbag protection will not activate the system.
Page 35: Child Restraint
Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children 12 years and under should ride properly buck- led up in a rear seat. According to crash statistics, children are safer when properly restrained in the rear seat rather than in the front. WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle.
Page 37 WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint. •...
Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Older Children and Child Restraints Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year.
Page 39 LATCH-compatible child restraint systems are now avail- able. However, because the lower anchorages are to be introduced over a period of years, child restraint systems having attachments for those anchorages will continue to also have features for installation using the vehicle’s seat belts.
Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Do not install a LATCH-equipped child restraint in the center of the rear seat of the vehicle. This is not a seating position in the vehicle, and a child seat cannot be correctly installed in this position. Addi- tionally, there is no tether anchorage provided for correctly installing a child seat in the center of the rear seat.
Page 41 You will first loosen the adjusters on the lower straps and on the tether strap so that you can more easily attach the hooks or connectors to the vehicle anchorages. Next attach the lower hooks or connectors over the top of the anchorage bars, pushing aside the seat cover material.
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. To attach a child restraint tether strap: 1. Lift the carpet flap to expose the anchor directly behind the seat where you are placing the child restraint.
Page 43: Engine Break-In Recommendations
WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap. Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision.
Page 44: Safety Tips
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Do not use non-detergent or straight mineral oils. A new engine may consume some oil during its first few thousand miles of operation. This is a normal part of the break-in and not an indication of a problem. SAFETY TIPS Exhaust Gas WARNING!
Page 45: Periodic Safety Checks You Should Make Outside
Airbag Light The light should come on and remain on for 6 to 8 seconds as a bulb check when the ignition switch is first turned ON. If the bulb is not lit during starting, have it replaced. If the light stays on or comes on while driving, have the system checked by an authorized dealer.
Page 47: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Convertible Top Operation ....49 To Lower The Top ..... .49 To Raise The Top .
Page 48 48 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Multi-Function Control Lever ....69 Headlights, Parking Lights, Instrument Panel Lights ......69 Automatic Headlights—If Equipped .
Page 49: Convertible Top Operation
CONVERTIBLE TOP OPERATION WARNING! The convertible top does not provide the structural protection that a reinforced metal roof does, and the fabric top cannot be expected to prevent the ejection of the occupants of a vehicle in a collision. Therefore it is important that all occupants wear their seat belts at all times when riding in a convertible.
Page 50 50 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Release the top from the windshield header by pulling both latch handles rearward until the latch hooks are free. Unlatching Convertible Top 4. Press the Power Top Switch to disengage the top pins from the header.
Page 51: To Raise The Top
CAUTION! Damage to the top material could result if the latch handles are not completely closed when the top is lowered. The convertible top cover cannot be in- stalled while the latch handles are open. To Raise The Top: CAUTION! To avoid damage to the sunvisors, rotate the driver’s and passenger’s sunvisor to the forward (against glass) position before raising or lowering the con-...
Page 52: Top Cover Installation
52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Use the center pull cup to pull down on the header. Hook each latch hook to its striker. Latch both sides. CAUTION! Car top carriers, ski racks, etc., should not be at- tached to the convertible top mechanism as they will damage the top.
Page 53 Installation From Inside The Vehicle 1. Kneel on the rear seat and tuck the rear edge and side edges of the top cover under the black molding near the trunk. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53 2. Insert both tabs located on the front of the top cover in between the seatback and seatback bracket.
Page 54 54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Snap the top cover flaps to the inner trim panel snaps. The side of the seat back cushion hides the snap. Top Cover Flap 4. Press down on the forward portion of the top cover to engage the hook and loop fasteners.
Page 55 Installation From Outside The Vehicle 1. Start on one side of the vehicle and tuck as much of the top cover as possible under the black molding. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55 2. Snap the top cover flap to the inner trim panel snap. (The side of the seat back cushion hides the snap.) Top Cover Flap...
Page 56 56 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Tuck the top cover tab closest to you into the space between the seatback and the seatback bracket. 4. Walk to the other side of the vehicle and finish tucking the top cover under the black molding. Insert the remain- ing tab between the seatback and the seatback bracket.
Page 57: Top Cover Removal
6. Press down on the forward portion of the top cover to engage the hook and loop fasteners. Hook and Loop Fasteners Top Cover Removal Unsnap the snaps and disengage the hook and loop fasteners, slide the tabs from the rear seat and then from the rear of the top storage area.
Page 58: Mirrors
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console/armrest has a pencil /tire gage holder and a tissue holder mounted on the underside of the cover. The bottom of the console bin also has built in holders for compact discs or cassette tapes. The power outlet is also mounted inside the center console (if equipped).
Page 59: Automatic Dimming Mirror - If Equipped
Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle). The mirror should be adjusted while set in the day position (toward windshield). Automatic Dimming Mirror — If Equipped This mirror will automatically adjust for annoying head- light glare from vehicles behind you.
Page 60: Electric Remote-Control Mirrors
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electric Remote-Control Mirrors Both of the outside mirrors can be adjusted by using the remote controls mounted on the instrument panel located to the left of the steering wheel. Power Mirror Controls NOTE: Place the mirror selector switch in the center (neutral) position to prevent accidental movement of the mirrors.
Page 61: Illuminated Vanity Mirrors
Illuminated Vanity Mirrors An illuminated vanity mirror is on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on automati- cally. Closing the mirror cover turns off the lights. Illuminated Vanity Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61 SEATS...
Page 62 62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reclining Bucket Seats The recliner control is on the side of the seat. To recline, lean forward slightly before lifting the lever, then lean back to the desired position and release the lever. To return the seat to the upright position, lean forward slightly before lifting the lever, then lean forward to the desired position and release the lever.
Page 63: Power Driver's Seat
Power Driver’s Seat The power seat switches are on the outboard side of the seat, near the floor. Use the forward switch to move the front of the seat cushion up and down. Use the rear switch to move the rear of the seat cushion up and down. The middle switch will move either the entire seat forward and rearward or the seat cushion up and down.
Page 64: To Fold The Front Seatback Forward
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The left rotary switch controls the heat level for the driver’s seat, and the right rotary switch controls the heat level for the passenger’s seat. These switches feature several heat settings ranging from 0 to 6. To Fold The Front Seatback Forward: Turn the high mounted release lever rearward and fold the seatback forward.
Page 65: Adjustable Head Restraints
Adjustable Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Adjust the restraints so that the upper edge is as high as practical. To raise, pull up on the head restraint. To lower, depress the button on the post guide and push down on the head restraint.
Page 66 66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Then lift the secondary latch located under the front edge of the hood, near the center and raise the hood. Hood Safety Catch Use the hood prop rod to secure the hood in the open position.
Page 67: Lights
LIGHTS Front Map/Reading Lights These lights, located under the rearview mirror, come on whenever a door is opened or the illuminated entry system is activated. The lights can also be turned on with the doors closed by means of switches located on the front of the rearview mirror.
Page 68 68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE turn on the lights. Turn the panel dimmer switch fully clockwise to prevent the lights from coming on when a door is opened. NOTE: The interior lights have a “fade to off” feature. When the lights are turned off, they gradually “fade”...
Page 69: Multi-Function Control Lever
Multi-Function Control Lever Multi-Function Lever The Multi-Function lever controls the operation of the headlights, turn signals, headlight beam select switch, instrument panel light dimming, passing light, dome light, and fog lights. Headlights, Parking Lights, Instrument Panel Lights Turn the end of the Multi-Function lever to the first detent for parking light operation.
Page 70: Automatic Headlights-If Equipped
70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights—If Equipped This system automatically turns your headlights on at a preset level of outdoor lighting. Turn the end of the control lever to the third detent to turn the system on. When the system is on, the headlight delay feature is also on.
Page 71: Headlight Beam Select Switch
Headlight Beam Select Switch Pull the turn signal lever towards you to switch the headlights to HIGH beam. Pull the turn signal lever a second time to switch the headlights to LOW beam. Flash to Pass You can signal another vehicle with your headlights by lightly pulling the turn signal lever toward the steering wheel.
Page 72: Mist
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To use the washer, pull the lever toward you and hold while spray is desired. If the lever is pulled while in the delay range, the wiper will operate for several cycles after the lever is released, and then resume the intermit- tent interval previously selected.
Page 73: Tilt Steering Column
TILT STEERING COLUMN To tilt the column, push down on the lever below the turn signal control and move the wheel up or down, as desired. Push the lever back up to lock the column firmly in place. Tilt Steering Column Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73 WARNING! Tilting the steering column while the vehicle is...
Page 74: Electronic Speed Control- If Equipped
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Traction Control Switch To turn the Traction Control System On, press the switch until the Traction Control indicator in the instrument cluster turns off. NOTE: The Traction Control System is enabled each time the ignition switch is turned On. This will occur even if you used the switch to turn the system off before powering down or turning the ignition to Lock.
Page 75: To Set At A Desired Speed
in use. The CRUISE Indicator in the instrument cluster will light up when the Speed Control is ON. NOTE: You must press the ON button to activate the system each time the engine is started. WARNING! Leaving the Electronic Speed Control system ON when not in use is dangerous.
Page 76: To Accelerate For Passing
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To decrease speed while speed control is Engaged, press and hold the COAST button. Releasing the button when the desired speed is reached, will establish a new SET speed. Tapping the COAST button once will result in a 1 mph (1.6 km/h) decrease in the SET speed.
Page 77: Garage Door Opener - If Equipped
Rolling Hills The transaxle may downshift into third gear and remain there as the vehicle travels over rolling hills. The trans- axle will upshift into fourth gear when the road flattens out. The transaxle will resume its normal shift schedule if you depress the accelerator pedal during any of the above conditions.
Page 78: Programming The Universal Transceiver
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! A moving garage door can cause injury to people and pets in the path of the door. People or pets could be seriously or fatally injured. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 79: Rolling Code" Programming
3. Choose one of the three Universal Transceiver buttons to program. Place the hand held controller one to three inches from the Universal Transceiver while keeping its indicator light in view. Programming Universal Transceiver 4. Using both hands, press the hand held transmitter button and the desired Universal Transceiver button.
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On garage door openers with the “Rolling Code” feature, the transmitter code changes after each use to prevent the copying of your code. To check if your device is protected by a “Rolling Code” system: •...
Page 81: Canadian Programming/Gate Programming
Canadian Programming/Gate Programming Canadian frequency laws, and the technology of some entry gates, require you to press and release the hand held transmitter button every two seconds during pro- gramming Continue to press and hold the Universal Transceiver button while you press and release the hand held trans- mitter button until the frequency signal has been learned.
Page 82: Electrical Power Outlet
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. This device may not cause harmful interference. 2. This device must accept any interference that may be received including interference that may cause undesired operation. NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 83: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instruments And Controls ....87 Instrument Cluster Standard ....88 Instrument Cluster Premium .
Page 84 84 UNDERSTANDING YOUR INSTRUMENT PANEL Seek Button (Radio Mode) ....102 Tuning ......102 Radio Data System (RDS) .
Page 85 Sales Code RBB—AM/FM Stereo Radio With Cassette Tape Player And CD Changer Capability ....110 Radio Operation ..... . 110 Mode Button .
Page 86 86 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Sound System Controls — If Equipped ......124 Radio Operation ..... . 125 Tape Player .
Page 87: Instruments And Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 87 INSTRUMENTS AND CONTROLS...
Page 88: Instrument Cluster Standard
88 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER STANDARD...
Page 89: Instrument Cluster Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 89 INSTRUMENT CLUSTER PREMIUM...
Page 90: Instrument Cluster - Gtc Model
90 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – GTC MODEL...
Page 91: Instrument Cluster Description
INSTRUMENT CLUSTER DESCRIPTION 1. Fuel Gauge When the ignition key is in the ON position, the pointer will show the level of fuel remaining in the fuel tank. 2. Traction Control — If Equipped This display indicator illuminates momentarily as a bulb check when the ignition switch is first turned ON.
Page 92 92 UNDERSTANDING YOUR INSTRUMENT PANEL 5. Tachometer The red area of the scale shows the maximum permissible engine revolutions-per-minute (rpm x 1000) for each gear range. Before reaching the red area (over 6,500 rpm), ease up on the accelerator to prevent engine over speed. 6.
Page 93 through several of your typical driving cycles. In most situations the vehicle will drive normally and will not require towing. The Malfunction Indicator Light flashes to alert to serious conditions that could lead to immediate loss of power or severe catalytic converter damage. The vehicle should be serviced as soon as possible if this occurs.
Page 94 94 UNDERSTANDING YOUR INSTRUMENT PANEL U.S. federal regulations require that upon transfer of vehicle ownership, the seller certify to the purchaser the correct mileage that the vehicle has been driven. There- fore, if the odometer reading is changed, during repair or replacement, be sure to keep a record of the reading before and after the service so that the correct mileage can be determined.
Page 95 If the light comes on and remains on while driving, stop the vehicle and shut off the engine. Do not operate the vehicle until the cause is corrected. The light does not show the quantity of oil in the engine. This can be determined using the procedure shown in Section 7.
Page 96 96 UNDERSTANDING YOUR INSTRUMENT PANEL In an ABS equipped vehicle, the Brake System Warning light will come on if the ABS light is not functioning or if the ABS system is not communicating. 19. Seat Belt Reminder Light When the ignition switch is first turned ON, this light will turn on for 5 to 8 seconds as a bulb check.
Page 97: Compass, Temperature, And Trip Computer Display - If Equipped
COMPASS, TEMPERATURE, AND TRIP COMPUTER DISPLAY — IF EQUIPPED Trip Computer Display This feature allows you to choose between a compass / temperature display and one of five trip conditions being monitored. Control Buttons Step Button Use this button to choose or cycle through the five trip conditions.
Page 98: Trip Conditions
98 UNDERSTANDING YOUR INSTRUMENT PANEL Trip Conditions Average Fuel Economy (AVG ECO) This display shows the average fuel economy since the last reset. Estimated Range (DTE) This display shows the estimated distance that can be traveled with the fuel remaining in the tank. This esti- mated distance is based on the most recent trip informa- tion: (Average Fuel Economy) x (Fuel Remaining) This display cannot be reset.
Page 99 Automatic Compass Calibration The self-calibrating feature of the compass eliminates the need to calibrate the compass for normal conditions. During a short initial period, the compass may appear erratic and the CAL symbol will appear on the display. After the vehicle has completed at least one complete circle in an area free from large metal objects, calibration will be complete when the CAL symbol is extinguished.
Page 100: Cigar Lighter/Ashtray
100 UNDERSTANDING YOUR INSTRUMENT PANEL Outside Temperature If the outside temperature is more than 131°F (55°C), the display will show 131°F. When the outside temperature is less than 40°F ( 40°C), the display will show 40°F/C. CIGAR LIGHTER/ASHTRAY For a nominal charge your dealer can provide a “smok- er’s”...
Page 101: To Set The Clock
To Set The Clock: 1. Use a ballpoint pen or similar object to press the hour (H) or minute (M) buttons on the radio, The time setting will increase each time you press the button. 2. Press any other button to exit from the clock setting mode.
Page 102: Sales Code Raz-Am/ Fm Stereo Radio With Cassette Tape Player, Cd Player And Cd Changer Controls
102 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RAZ—AM/ FM STEREO RADIO WITH CASSETTE TAPE PLAYER, CD PLAYER AND CD CHANGER CONTROLS RAZ Radio Operating Instructions — Radio NOTE: Power to operate the radio is controlled by the ignition switch. It must be in the ON or ACC position to operate the radio.
Page 103: Pty (Program Type) Button
which are broadcasting this information. PTY (Program Type) is used to characterize the station’s program ma- terial, for example Rock Music . PTY (Program Type) Button Pressing this button once will turn on the PTY mode for 5 seconds. If no action is taken during the 5 second time out the PTY icon will turn off.
Page 104: Balance
104 UNDERSTANDING YOUR INSTRUMENT PANEL The radio display will flash “SEEK” and the selected PTY program type when searching for the next PTY station. If no station is found with the selected PTY program type, the radio will return to the last preset station. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station.
Page 105: To Set The Radio Push-Button Memory
Pressing the AM/FM button continues the search in the alternate frequency band. To stop the search, press SCAN a second time. To Set The Radio Push-button Memory When you are receiving a station that you wish to commit to push-button memory, press the SET button. SET 1 will show in the display window.
Page 106: Fast Forward (Ff)
106 UNDERSTANDING YOUR INSTRUMENT PANEL Fast Forward (FF) Press the FF button up momentarily to advance the tape in the direction that it is playing. The tape will advance until the button is pressed again or the end of the tape is reached.
Page 107: Operating Instructions - Cd Player
To turn off the Dolby Noise reduction System: Press the Dolby button (button 2) after you insert the tape. The NR light in the display will go off when the Dolby System is off. The Dolby System is automatically reactivated each time a tape is inserted.
Page 108: Seek Button
108 UNDERSTANDING YOUR INSTRUMENT PANEL Seek Button Press the top of the SEEK button for the next selection on the CD. Press the bottom of the button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first 10 seconds of the current selection.
Page 109: Tape Cd Button
current channel name and number will then be displayed until an action occurs. A CD or tape may remain in the player while in the Satellite Radio mode. Tape CD Button Press this button to select between CD player and Tape player.
Page 110: Sales Code Rbb-Am/Fm Stereo Radio With Cassette Tape Player And Cd Changer Capability
110 UNDERSTANDING YOUR INSTRUMENT PANEL CD Diagnostic Indicators When driving over a very rough road, the CD player may skip momentarily. Skipping will not damage the disc or the player, and play will resume automatically. As a safeguard and to protect your CD player, one of the following warning symbols may appear on your display.
Page 111 NOTE: Power to operate the radio is supplied through the ignition switch. It must be in the ON or ACC position to operate the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the volume control to the right increases the volume and to the left decreases it.
Page 112: Mode Button
112 UNDERSTANDING YOUR INSTRUMENT PANEL stations to be locked into push-button memory. The stations stored in SET 2 memory can be selected by pressing the push-button twice. Every time a preset button is used a corresponding button number will be displayed. Audio The audio button controls the BASS, TREBLE, BAL- ANCE, and FADE.
Page 113: Cassette Player Features
Cassette Player Features With ignition OFF and the sound system OFF, you can eject the tape cassette by pushing the EJECT button. You can turn the tape player ON by inserting a cassette or activating the MODE button (with a cassette in the radio), but only when the ignition and radio are on.
Page 114: Cd Changer Control Capability - If Equipped
114 UNDERSTANDING YOUR INSTRUMENT PANEL When Dolby is ON, the NR symbol appears on the display. Each time a tape is inserted the Dolby will turn * “Dolby” noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. Dolby and the double-D symbol are trademarks of Dolby Labo- ratories Licensing Corporation.
Page 115: Sales Code Rbk-Am/ Fm Stereo Radio With Cd Player And Cd Changer Controls
Operating Instructions - Satellite Radio Mode (If Equipped) Refer to the Satellite Radio section of the Owner’s Manual. CD Diagnostic Indicators When driving over a very rough road, the CD player may skip momentarily. Skipping will not damage the disc or the player, and play will resume automatically.
Page 116 116 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Power to operate the radio is supplied through the ignition switch. It must be in the ON or ACC position to operate the radio. Seek Press and release the SEEK button to search for the next station in either the AM or FM mode.
Page 117: Cd Player Operation
Press the AUDIO button a second time and TREB will be displayed. Press the SEEK + or SEEK – to increase or decrease the Treble tones. Press the AUDIO button a third time and BAL will be displayed. Press the SEEK + or SEEK – to adjust the sound level from the right or left side speakers.
Page 118 118 UNDERSTANDING YOUR INSTRUMENT PANEL Inserting The Compact Disc CAUTION! This CD player will accept 4 only. The use of other sized discs may damage the CD player mechanism. You may either insert or eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio OFF, the display will show the time of day.
Page 119: Cd Changer Control Capability - If Equipped
Press the SEEK button to move to the next randomly selected track. Press the RND (button 4) button a second time to stop Random Play. Mode Press the MODE button repeatedly to select between the CD player, the optional remote CD changer and the Satellite Radio (if equipped).
Page 120 120 UNDERSTANDING YOUR INSTRUMENT PANEL Random Play (RND) Press the Random button to play the tracks on the selected disc in random order for an interesting change of pace. Random can be cancelled by pressing the button a second time or by ejecting the CD from the changer. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to the Satellite Radio section of the Owner’s...
Page 121: Sales Code Rb1-Am/Fm Stereo Radio With Dvd/Gps Navigation System
SALES CODE RB1—AM/FM STEREO RADIO WITH DVD/GPS NAVIGATION SYSTEM RB1 Radio The navigation system provides maps, turn identifica- tion, selection menus and instructions for selecting a variety of destinations and routes. Refer to your “Navi- gation User’s Manual” for detailed operating instruc- tions.
Page 122: Loading The Cd Changer
122 UNDERSTANDING YOUR INSTRUMENT PANEL Loading the CD Changer When inserting the first CD into the changer if the radio is on, wait until the single slot is illuminated on both sides and simply insert the first disc. To insert additional CDs into the changer, the instructions follow: 1.
Page 123: Program Button 1
Program Button 1 Press this button to play the next available disc. Program Button 4 (Random Play) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the current compact disc in random order to provide an interesting change of pace.
Page 124: Cd Changer Operation With The Changer Off
124 UNDERSTANDING YOUR INSTRUMENT PANEL To eject additional CDs from the changer, first select the numbered button where the CD is located and then press the EJT button. CD Changer Operation with the Changer Off The CD changer is able to load and eject discs with the ignition power off.
Page 125: Radio Operation
The left hand control is a rocker type switch with a push-button in the center. The function of the left hand control is different depending on which mode you are in. The following describes the left hand control operation in each mode.
Page 126: Cassette Tape And Player Maintenance
126 UNDERSTANDING YOUR INSTRUMENT PANEL The button in the center of the left hand switch will cause the CD changer to play the next available disc. CASSETTE TAPE AND PLAYER MAINTENANCE To keep the cassette tapes and player in good condition, take the following precautions: 1.
Page 127: Radio Operation And Cellular Phones
4. Do not use solvents such as benzine, thinner, cleaners, or antistatic sprays. 5. Store the disc in its case after playing. 6. Do not expose the disc to direct sunlight. 7. Do not store the disc where temperatures may become too high.
Page 128: Climate Controls
128 UNDERSTANDING YOUR INSTRUMENT PANEL CLIMATE CONTROLS Automatic Temperature Control (ATC) — If Equipped Automatic Temperature Controls The ATC system can maintain a steady comfort level in various weather conditions with a simple two step op- eration. Press the AUTO button and select your comfort setting.
Page 129 Fan Control Use this control to regulate the amount of air forced through the system in any mode you select. Turn the control clockwise to increase fan speed. In ambient temperatures below 21°C (70°F), fan opera- tion is delayed when the engine is first started. The fan will automatically start when the engine coolant is warm enough to heat the air.
Page 130 130 UNDERSTANDING YOUR INSTRUMENT PANEL engine speed or power may be noticed when the com- pressor is on. This is a normal occurrence since the compressor will cycle on and off to maintain comfort and improve fuel economy. Recirculate Button Press this button to recirculate the air inside the vehicle.
Page 131 NOTE: There is a varying difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature provides improved comfort during sunny but cool con- ditions. Windshield Defrost Air is directed through the defrost outlets and side window demist outlets.
Page 132 132 UNDERSTANDING YOUR INSTRUMENT PANEL Hot Weather Automatic Recirculation The system will automatically recirculate the air inside the vehicle when the interior is very warm. This will provide maximum cooling. The system will also occa- sionally return to REC on hot, humid or very hot, dry days to maintain occupant comfort.
Page 133 UNDERSTANDING YOUR INSTRUMENT PANEL 133 Operating Tips (ATC only)
Page 134: Manual Air Conditioning/Heater Control
134 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If the system is in the AUTO mode and the fan control is already rotated fully clockwise or fully coun- terclockwise, the control may have to be rotated to the middle and then to the desired fan setting for manual adjustment of fan speed.
Page 135 Slight changes in engine speed or power may be noticed when the air conditioning compressor is on. This is a normal occurrence as the compressor will cycle on and off to maintain comfort and increase fuel economy. NOTE: If your air conditioning performance seems lower than expected, check the front of the air condition- ing condenser for an accumulation of dirt or insects.
Page 136 136 UNDERSTANDING YOUR INSTRUMENT PANEL • Panel — Air Conditioning Outside air flows through the air condition- ing system and then through the outlets located in the instrument panel. • Bi-Level — Air Conditioning Outside air flows through the air condition- ing system and then through the outlets located in both the instrument panel and floor outlets.
Page 137 Rear Seat Outlets These outlets are located under the front seats and direct warm air to the rear seat passengers. Air is directed through these outlets when you select either the Floor, Bi-Level, or Mix modes. Rear Window Defroster The Rear Window Defroster button is located to the right of the Mode Control.
Page 138 138 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Do not use the recirculation mode as it will not clear windows under these conditions. Summer Operation Air conditioned vehicles must be protected with a high- quality antifreeze coolant to provide proper corrosion protection and to raise the boiling point of the coolant for protection against overheating.
Page 139 UNDERSTANDING YOUR INSTRUMENT PANEL 139 Operating Tips (Manual A/C Control Only)
Page 140 140 UNDERSTANDING YOUR INSTRUMENT PANEL Outside Air Intake Make sure the air intake, directly in front of the wind- shield, is free of ice, slush, snow or other obstructions such as leaves. Leaves collected in the air-intake plenum may reduce air flow and plug the plenum water drains. Air Intake...
Page 141: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....144 Automatic Transaxle ....144 Manual Transaxle .
Page 142 142 STARTING AND OPERATING Tire Safety Information ....156 Tire Markings ......156 Tire Identification Number (TIN) .
Page 143 Trailer Towing ......179 Towing Requirements ....179 Flexible Fuel –...
Page 144: Starting Procedures
144 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. CAUTION! Long periods of engine idling, especially at high engine speeds can cause excessive exhaust tempera- tures which can damage your vehicle.
Page 145: Extreme Cold Weather (Below -20°F Or -29°C)
Ignition Key Positions WARNING! Never pour fuel or other flammable liquid into the throttle body air inlet opening in an attempt to start the vehicle. This could result in flash fire causing serious personal injury. STARTING AND OPERATING 145 CAUTION! Do not attempt to push or tow your vehicle to get it started.
Page 146: If Engine Fails To Start
146 STARTING AND OPERATING If Engine Fails to Start If the engine fails to start after you have followed the “NORMAL STARTING” WEATHER” procedures, it may be flooded. Push the accelerator pedal all the way to the floor and hold it there while cranking the engine.
Page 147: Automatic Transaxle
WARNING! Remember to disconnect the cord before driving. Damage to the 110-115 volt AC electrical cord could cause electrocution. Use the heater when temperatures below 0°F (-18°C) are expected to last for several days. AUTOMATIC TRANSAXLE Brake/Transmission Interlock This interlock system prevents you from moving the gear selector out of the Park position unless the brake pedal is pressed.
Page 148: Automatic Transaxle Ignition Interlock System
148 STARTING AND OPERATING CAUTION! Damage to the transaxle may occur if the following precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 149: Four Speed Automatic Transaxle
Four Speed Automatic Transaxle The electronically controlled transaxle provides a precise shift schedule. The transaxle electronics are self calibrat- ing; therefore, the first few shifts on a new vehicle may be somewhat abrupt. This is a normal condition, and preci- sion shifts will develop within a few shift cycles.
Page 150 150 STARTING AND OPERATING WARNING! Your vehicle could move and injure you and others if it is not completely in P (Park). Check by trying to move the gearshift lever back and forth without depressing the shift button after you have set it in P. Make sure it is in Park before leaving the vehicle.
Page 151: Parking Brake
NOTE: Using the “3” range while operating the vehicle under heavy operating conditions will improve perfor- mance, fuel economy, and extend transaxle life by reduc- ing excessive shifting and heat build up. Use the “3” range when descending steep grades to prevent brake system distress.
Page 152 152 STARTING AND OPERATING To release the parking brake, apply the brake pedal and pull up on the parking brake lever. Push the release button and lower the lever fully. When parking on a hill, it is important to set the parking brake before placing the gear selector in Park, otherwise the load on the transmission locking mechanism may make it difficult to move the selector out of Park.
Page 153: Brake System
BRAKE SYSTEM Your vehicle is equipped with power assisted brakes as standard equipment. In the event power assist is lost for any reason (for example, repeated brake applications with the engine off), the brakes will still function. The effort required to brake the vehicle will be much greater than that required with the power system operating.
Page 154 154 STARTING AND OPERATING WARNING! Pumping of the brake pedal will diminish the effec- tiveness of Anti-lock brakes and may lead to an accident. Pumping makes the stopping distance longer. Just press firmly on your brake pedal when you need to slow down or stop. WARNING! •...
Page 155: Power Steering
POWER STEERING The power assisted steering system of your vehicle provides mechanical steering capability in the event power assist is lost. If for some reason the hydraulic pressure is interrupted, it will still be possible to steer your vehicle. Under these conditions you will observe a substantial increase in steering effort.
Page 156: Tire Safety Information
156 STARTING AND OPERATING • The system has been automatically deactivated to prevent damage to the brake system due to overheated brake temperatures. NOTE: Extended heavy use of Traction Control may cause the system to deactivate and turn on the traction control light located in the instrument cluster.
Page 157 • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter P is absent from this tire size designation. Example: 215/65R15 96H •...
Page 158 158 STARTING AND OPERATING 65 = Aspect Ratio in Percent (%) —Ratio of section height to section width of tire. 10.5 = Section Width in Inches (in) R = Construction Code — R means Radial Construction. — D means Diagonal or Bias Construction. 15 = Rim Diameter in Inches (in) Service Description: 95 = Load Index...
Page 159: Tire Identification Number (Tin)
Load Identification: ...blank... = Absence of any text on sidewall of the tire indicates a Standard Load (SL) Tire Extra Load (XL) = Extra Load (or Reinforced) Tire Light Load = Light Load Tire C,D,E = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load —...
Page 160: Tire Loading And Tire Pressure
160 STARTING AND OPERATING L9 = Code representing the tire size.(2 digits) ABCD = Code used by tire manufacturer.(1 to 4 digits) 03 = Number representing the week in which the tire was manufactured.(2 digits) —03 means the 3rd week. 01 = Number representing the year in which the tire was manufactured.(2 digits) —01 means the year 2001.
Page 161 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the, 1) number of people that can be carried in the vehicle 2) the total weight your vehicle can carry 3) the tire size designed for your vehicle 4) the cold tire inflation pressures for the front, rear and spare tires.
Page 162 162 STARTING AND OPERATING Steps for Determining Correct Load Limit 1. Locate the statement “The combined weight of occu- pants and cargo should never exceed XXX pounds” on your vehicle’s placard. 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle.
Page 163 STARTING AND OPERATING 163...
Page 164: Tires-General Information
164 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES—GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 165: Tire Inflation Pressures
2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Underinflation also increases tire rolling resistance and results in higher fuel consumption. 3.
Page 166 166 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure al- ways reinstall the valve stem cap–if equipped. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure”.
Page 167: Radial-Ply Tires
WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious accident. Don’t drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).
Page 168: Limited Use Spare - If Equipped
168 STARTING AND OPERATING Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, since the wheel is designed specifically for the compact spare. Do not install more than one compact spare tire/wheel on the vehicle at any given time.
Page 169: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck. And don’t let anyone near a spinning wheel, no matter what the speed.
Page 170: Replacement Tires
170 STARTING AND OPERATING Replacement Tires The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The manu- facturer strongly recommends that you use tires equiva- lent to the originals in size, quality and performance when replacement is needed (see the paragraph on tread wear indicators).
Page 171: Alignment And Balance
CAUTION! Replacing original tires with tires of a different size may result in false speedometer and odometer read- ings. Alignment And Balance Poor suspension alignment may result in: • Fast tire wear. • Uneven tire wear, such as feathering and one-sided wear.
Page 172: Tire Rotation Recommendations
172 STARTING AND OPERATING Snow tires generally have lower speed ratings than what was originally equipped with your vehicle and should not be operated at sustained speeds over 75 mph (120 km/h). Tire Rotation Recommendations Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving and braking functions.
Page 173: Autostick - If Equipped
AUTOSTICK — IF EQUIPPED Autostick is a driver-interactive transaxle that offers manual gear shifting capability to provide you with more control. Autostick allows you to maximize engine brak- ing, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can also provide you with more control during passing, city driving, cold slippery conditions, mountain driving, trailer towing, and many other situations.
Page 174: Fuel Requirements
174 STARTING AND OPERATING • Downshifts from third to second gear above 66 mph (106 km/h) and from second to first gear above 37 mph (60 km/h) will be ignored. • You can start out in first, second, or third gear. Shifting into fourth gear can occur only after vehicle speed reaches 15 mph (24 km/h).
Page 175: Reformulated Gasoline
Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, engine performance, and durability for your vehicle. The manufacturer recommends the use of gasolines that meet the WWFC specifications if they are available.
Page 176: Mmt In Gasoline
176 STARTING AND OPERATING MMT in Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase the octane num- ber. Gasolines blended with MMT offer no performance advantage beyond gasolines of the same octane number without MMT.
Page 177: Carbon Monoxide Warnings
Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives are not the responsibility of the manufacturer. NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly.
Page 178 178 STARTING AND OPERATING CAUTION! To avoid fuel spillage and overfilling, do not “top off” the fuel tank after filling. NOTE: Tighten the gas cap until you hear a “clicking” sound. This is an indication that the gas cap is properly tightened.
Page 179: Vehicle Loading
VEHICLE LOADING Vehicle Loading Capacities Front Seat Occupants ..... . . 2 Rear Seat Occupants ......2 Luggage .
Page 180 180 STARTING AND OPERATING NOTE: Using the “3” range while operating the vehicle under heavy operating conditions will improve perfor- mance and extend tranaxle life by reducing excessive shifting and heat build up. WARNING! Connecting trailer brakes to your vehicle’s hydraulic brake lines can overload your brake system and cause it to fail.
Page 181: Flexible Fuel - (2.7L Engines With Automatic Transmission Only)
FLEXIBLE FUEL – (2.7L Engines with Automatic Transmission Only) E-85 General Information The information in this section is for Flexible Fuel ve- hicles only. These vehicles can be identified by the unique fuel filler door label that states Ethanol (E-85) or Un- leaded Gasoline Only.
Page 182: Selection Of Engine Oil
182 STARTING AND OPERATING • you operate the vehicle immediately after refueling for a period of at least 5 minutes Observing these precautions will avoid possible hard starting and/or significant deterioration in drivability during warm up. NOTE: When the ambient temperature is above 90°F (32°C), you may experience hard starting and rough idle following start up even if the above recommendations are followed.
Page 183: Starting
• Engine Oil Selection for Operating on E-85 If you operate the vehicle on E-85 fuel, either full or part-time, use only Mopar Flexible Fuel 5W-30 engine oil (P/N 4318086) or an equivalent that meets the Manufacturer’s Standard MS-9214. Equivalent com- mercial Flexible Fuel engine oils may be labeled as Flexible Fuel (FFV) or Alternate Fuel (AFV).
Page 184: Replacement Parts
184 STARTING AND OPERATING Replacement Parts Many components in your Flexible Fuel Vehicle (FFV) are designed to be compatible with ethanol. Always be sure that your vehicle is serviced with correct ethanol com- patible parts. CAUTION! Replacing fuel system components with non-ethanol compatible components can damage your vehicle and may void the warranty.
Page 185: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....186 If Your Engine Overheats ....186 Jacking And Tire Changing .
Page 186: Hazard Warning Flasher
186 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER Hazard Flasher Switch The flasher switch is on top of the steering column, just behind the steering wheel. Depress the switch and both cluster indicators and all front and rear direc- tional signals will flash.
Page 187 NOTE: There are steps that you can take to slow down an impending overheat condition. If your air conditioner is on, turn it off. The air conditioning system adds heat to the engine cooling system and turning off the A/C removes this heat.
Page 188: Jacking And Tire Changing
188 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack.
Page 189 Do not attempt to raise this vehicle using a bumper jack. WHAT TO DO IN EMERGENCIES 189 1. Block wheel diagonally op- posite flat tire. 2. Remove the spare tire, scissors jack and lug wrench from stowage.
Page 190 190 WHAT TO DO IN EMERGENCIES 3. Before raising the vehicle, use lug wrench to carefully pry off wheel cover (if equipped with steel wheels) or center cap (if equipped with aluminum wheels). Loosen, but do not remove, the wheel nuts by turning them counterclockwise one turn while the wheel is still on the ground.
Page 191 WHAT TO DO IN EMERGENCIES 191 Jack Engagement Locations...
Page 192 192 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6. Remove lug nuts and tire. 7.
Page 193: Jump-Starting Procedures If Battery Is Low
JUMP-STARTING PROCEDURES IF BATTERY IS WARNING! • Do not attempt to push or tow your vehicle to get it started. Vehicles equipped with an automatic transaxle cannot be started this way. Unburned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle.
Page 194 194 WHAT TO DO IN EMERGENCIES WARNING! Do not permit vehicles to touch each other as this could establish a ground connection and person injury could result. Jump Starting 5. Connect the other cable, first to the negative terminal of the booster battery and then to the jump start attach- ment of the vehicle with the discharged battery.
Page 195 6. Start the engine in the vehicle that has the booster battery, let the engine idle a few minutes, then start the engine in the vehicle with the discharged battery. 7. When removing the jumper cables, reverse the above sequence exactly. Be careful of the moving belts and fan. WARNING! Any procedure other than above could result in: 1.
Page 196: Driving On Slippery Surfaces
196 WHAT TO DO IN EMERGENCIES DRIVING ON SLIPPERY SURFACES Acceleration Rapid acceleration on snow covered, wet, or other slip- pery surfaces may cause the front wheels to pull errati- cally to the right or left. This phenomenon occurs when there is a difference in the surface traction under the front (driving) wheels, particularly with high output engines.
Page 197: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE If your vehicle is equipped with Traction Control, turn the system off before attempting to “rock” the vehicle. If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels.
Page 198: Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground)
198 WHAT TO DO IN EMERGENCIES TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground) Automatic Transaxle Your vehicle may be towed under the following condi- tions: The gear selector must be in NEUTRAL, the distance to be towed must not exceed 15 miles (25 km), and the towing speed must not exceed 25 mph (40 km/h).
Page 199: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS 2.4L Engine ......201 2.7L Engine ......202 Onboard Diagnostic System —...
Page 200 200 MAINTAINING YOUR VEHICLE Appearance Care And Protection From Corrosion ..... . 229 Convertible Top Care ....234 Washing .
Page 201: 2.4L Engine
MAINTAINING YOUR VEHICLE 201 2.4L ENGINE 2.4L Engine Compartment...
Page 202: 2.7L Engine
202 MAINTAINING YOUR VEHICLE 2.7L ENGINE 2.7L Engine Compartment...
Page 203: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 204: Emissions Inspection And Maintenance Programs
204 MAINTAINING YOUR VEHICLE EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system. Failure to pass could prevent vehicle registration. For states which have an I/M (Inspection and Maintenance) requirement, this check verifies the following: the MIL (Malfunction Indicator Lamp) is functioning and is not on when the engine is running,...
Page 205: Replacement Parts
If your OBD system is not ready, you should see your authorized dealer or repair facility. If your vehicle was recently serviced or had a battery failure or replacement, you may need to do nothing more than drive your vehicle as you normally would in order for your OBD system to update.
Page 206: Maintenance Procedures
206 MAINTAINING YOUR VEHICLE WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 207 Engine Oil Dipstick CAUTION! Overfilling or underfilling will cause aeration or loss of oil pressure. This could damage your engine. Change Engine Oil Road conditions and your kind of driving affects the interval at which your oil should be changed. Check the following list to decide if any apply to you.
Page 208 208 MAINTAINING YOUR VEHICLE If none of these apply to you, then change your engine oil at every interval shown on schedule A of the Mainte- nance Schedules section of this manual. NOTE: Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or 6 months whichever comes first.
Page 209 Engine Oil Viscosity (SAE Grade) Engine Oil Fill Cap SAE 5W-20 and SAE 5W-30 engine oils are recom- mended for all operating temperatures. These engine oils are designed to improve low temperature starting and vehicle fuel economy. Refer to the engine oil filler cap for the preferred engine oil viscosity grade for each vehicle.
Page 210 210 MAINTAINING YOUR VEHICLE Materials Added To Engine Oils The manufacturer strongly recommends against the ad- dition of any additives (other than leak detection dyes) to engine oil. Engine oil is an engineered product and it’s performance may be impaired by supplemental addi- tives.
Page 211 replaced if there is any malfunction due to a faulty spark plug. Check the specifications section for the proper type of spark plug for use in your vehicle. Engine Air Cleaner Filter Under normal driving conditions, replace the air filter at the intervals shown on Schedule “A”.
Page 212 212 MAINTAINING YOUR VEHICLE CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and the...
Page 213: Crankcase Emission Control System
Crankcase Emission Control System Proper operation of this system depends on freedom from sticking or plugging due to deposits. As vehicle mileage builds up, the Positive Crankshaft Ventilation (PCV) valve and passages may accumulate deposits. If a valve is not working properly, replace it with a new valve.
Page 214: Air Conditioner
214 MAINTAINING YOUR VEHICLE WARNING! Battery posts, terminals and related accessories con- tain lead and lead compounds. Wash hands after handling. Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin or clothing. Don’t lean over a battery when attaching clamps.
Page 215: Power Steering - Fluid Check
through the condenser as required. Fabric front fascia protectors may reduce air flow to the condenser, reducing air conditioning performance. WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you.
Page 216: Suspension Ball Joints
216 MAINTAINING YOUR VEHICLE WARNING! Fluid level should be checked on a level surface with the engine off to prevent injury from moving parts, and to insure accurate fluid level reading. Do not overfill. Use only manufacturer’s recommended fluid. Power Steering Fluid Reservoir Fluid level should be maintained at the proper level indicated on the side of the reservoir.
Page 217 Hood Latch When performing other under hood services, the hood latch release mechanism and safety catch should be inspected, cleaned, and lubricated. It is important to maintain proper lubrication to insure that the hood mechanisms work properly and safely. Multi-Purpose Lubricant, NLGI Grade 2, should be ap- plied sparingly to all pivot and sliding contact areas.
Page 218: Windshield Wiper Blades
218 MAINTAINING YOUR VEHICLE • Trunk latches • Ash tray Windshield Wiper Blades Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a mild non abrasive cleaner. This will remove accumula- tions of salt or road film.
Page 219: Exhaust System
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
Page 220: Cooling System
220 MAINTAINING YOUR VEHICLE Cooling System Inspection WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition key to the OFF position. The fan is controlled by both the temperature of the engine cooling system and the pressure in the air conditioning system and can start at any time the ignition key is in the ON position.
Page 221 Do not remove the cap when the cooling system is hot. Cooling System — Drain, Flush and Refill At the intervals shown on the Maintenance Schedules, the system should be drained, flushed and refilled. The first change should not be required until 5 years or 100,000 miles (160,000 km), whichever comes first.
Page 222 222 MAINTAINING YOUR VEHICLE Adding Coolant When adding coolant, or refilling the system, a minimum solution of 50% recommended HOAT ethylene glycol engine coolant (antifreeze) and distilled water should be used. Use higher concentrations (not to exceed 70%) if temperatures below 34°F ( 37°C) are anticipated.
Page 223 Disposal Of Used Engine Coolant Used ethylene glycol based engine coolant is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community. Do not store ethylene glycol based engine coolant in open containers or allow it to remain in puddles on the ground.
Page 224: Hoses And Vacuum/Vapor Harnesses
224 MAINTAINING YOUR VEHICLE • Check coolant freeze point in the system. • If frequent coolant additions are required, or if the level in the bottle does not drop when the engine cools, the cooling system should be pressure tested for leaks. •...
Page 225 WARNING! Riding the brakes can lead to brake failure and possibly an accident. Driving with your foot resting or riding on the brake pedal can result in abnormally high brake temperatures, excessive lining wear, and possible brake damage. You may not have your full braking capacity in an emergency.
Page 226 226 MAINTAINING YOUR VEHICLE Master Cylinder The fluid level in the master cylinder should be checked when performing under hood services, or immediately if the brake system warning lamp shows system failure. Brake Fluid Reservoir Be sure to clean the top of the master cylinder area before removing the cap.
Page 227: Fuel System Hoses
Do not allow petroleum base fluid to contaminate the brake fluid as seal damage will result! Fuel System Hoses Electronic Fuel Injection high pressure fuel systems are designed with hoses and clamps which have unique material characteristics to provide adequate sealing and resist attack by deteriorated gasoline.
Page 228 228 MAINTAINING YOUR VEHICLE Procedure For Checking Fluid Level The fluid level in the automatic transaxle should be checked whenever the vehicle is serviced. Operation with an improper fluid level will greatly reduce the life of the transaxle and of the fluid. To properly check the automatic transaxle fluid level, the following procedure must be used: •...
Page 229: Appearance Care And Protection From Corrosion
Fluid and Filter Changes Automatic transmission fluid and filter should be changed as follows: Maintenance schedule “A” — No change necessary. Maintenance schedule “B” — Every 60,000 miles (96 000 km) change fluid and filter under the following condi- tions: •...
Page 230 230 MAINTAINING YOUR VEHICLE hot or cold weather and other extreme conditions will have an adverse effect on paint, metal trim, and under- body protection. The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle.
Page 231 Special Care • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month. • It is important that the drain holes in the lower edges of the doors, rocker panels and rear deck lid be kept clear and open.
Page 232 232 MAINTAINING YOUR VEHICLE Interior Care Use Mopar Fabric Cleaner to clean fabric upholstery and carpeting. Use Mopar Vinyl Cleaner to clean vinyl or leather uphol- stery. Mopar Vinyl Cleaner is specifically recommended for vinyl trim. Use mild (Ivory Flake) solution to clean all surfaces. Wipe with clear water and soft (lint free) cloth.
Page 233 can be removed easily with a soft cloth and Mopar Total Clean. Care should be taken to avoid soaking the leather with any liquid. Cleaning Headlights Your vehicle has plastic headlights that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed.
Page 234: Convertible Top Care
234 MAINTAINING YOUR VEHICLE • Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners. If soap is used, wipe clean with a clean damp rag. • Dry with a soft tissue. Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners.
Page 235: General Cleaning
General Cleaning Careful vacuuming of the top before washing is helpful in removing dust and other foreign particles. Wash in partial shade instead of direct sun. Wet the entire vehicle before washing the top. The top should be washed with a soft, natural bristle scrub brush, and a mild soap solution such as liquid dish washing soap.
Page 236: Cloth Top Protection
236 MAINTAINING YOUR VEHICLE Cloth Top Protection For appearance purposes, you may wish to protect your Twillfast™ (cloth) top periodically. A fabric protectant such as Scotchguard is suggested. The top should be clean and dry before application of the protectant. CAUTION! Avoid getting Scotchguard on the surrounding...
Page 237: Interior Fuses
compartment, near the air cleaner. This information ap- plies to vehicles built without the fuse and relay num- bering embossed on the Power Distribution Center Top Cover. Interior Fuses Fuse Panel Cover The fuse access panel is behind the end cover at the left side of the instrument panel.
Page 238 238 MAINTAINING YOUR VEHICLE Cavity Fuse Circuit 10 Amp Red Heated Rear Window In- dicator 20 Amp Yel- Instrument cluster illumi- nation, Park and tail Lights 20 Amp Yel- Power Receptacle, Horns, Ignition, Fuel, Start 15 Amp Blue Power Door Lock Motors (Body Control Module) 20 Amp Yel- Daytime Running Light...
Page 239: Vehicle Storage
VEHICLE STORAGE If you are leaving your vehicle dormant for more than 21 days you may want to take steps to protect your battery. You may: • Disconnect the negative cable from the battery. • Anytime you store your vehicle, or keep it out of service (i.e.
Page 240: Bulb Replacement
240 MAINTAINING YOUR VEHICLE BULB REPLACEMENT Headlight Bulb Replacement 1. Open the hood and remove the two headlight mount- ing screws. 2. Remove the push-in fasteners by prying under the head of the fasteners with a flat bladed tool.
Page 241 3. Gently pry the headlight assembly away from the fender as shown in the picture. This will free the ball stud from its retainer in the fender. Pull the headlight assem- bly away from the vehicle. 4. Turn the retaining ring counterclockwise and remove the bulb and socket assembly.
Page 242: Park, Turn Signal, Sidemarker Bulb Replacement
242 MAINTAINING YOUR VEHICLE 7. Reinsert the bulb and socket assembly and turn the retaining ring clockwise to secure the bulb. 8. Reinstall the headlight assembly. Park, Turn Signal, Sidemarker Bulb Replacement 1. Open the hood and remove the two headlight assem- bly mounting screws.
Page 243: Fog Light Bulb Replacement
3. Turn the bulb socket counterclockwise and remove the bulb and socket assembly. 4. Pull the bulb out of the socket, replace the bulb, and reinstall the bulb and socket to the headlight assembly. Reinstall the headlight assembly. MAINTAINING YOUR VEHICLE 243 Fog Light Bulb Replacement 1.
Page 244: Center Stoplight Bulb Replacement
244 MAINTAINING YOUR VEHICLE 4. Turn the bulb and socket assembly counterclockwise to remove it from the housing. 5. Install the new bulb and socket assembly, reattach the wiring connector, and reinstall the fog light assembly. Center Stoplight Bulb Replacement You may wish to see your dealer for service of this light.
Page 245: License Plate Bulb Replacement
2. Disconnect the wiring connector as shown and re- move the plastic retainers. Remove the light housing from the vehicle. 3. Turn the bulb socket counterclockwise to remove it from the housing. Remove the bulb and reinstall the bulb and socket assembly. 4.
Page 246: Fluids And Capacities
246 MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Fuel (approximate) 2.4 and 2.7 Liter Engines (87 Oc- tane) Engine Oil-With Filter 2.4 and 2.7 Liter Engines (Refer to the engine oil fill cap for the correct SAE grade) Cooling System * 2.4 Liter Engines* (Mopar Antifreeze/Coolant 5 Year/ 100,000 Mile Formula)
Page 247: Recommended Fluids, Lubricants And Genuine Parts
RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) Engine Oil Use API Certified engine oil. SAE 5W-20 and SAE 5W-30 are recommended. Refer to the engine oil fill cap for the correct SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Page 248: Chassis
248 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transaxle Brake Master Cylinder Power Steering Reservoir Steering Gear & Linkage, Ball Joints, Prop Shafts & Yokes, Wheel Bearings Fluid, Lubricant, or Genuine Part Mopar ATF+4 Automatic Transmission Fluid. Mopar Brake Fluid DOT 3 Motor Vehicle. Mopar ATF+4 Automatic Transmission Fluid.
Page 249 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..250 Maintenance Schedules ....250 Schedule “B” ......253 Schedule “A”...
Page 250: Emission Control System Maintenance
250 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 251 • If equipped for and operating with E-85 (ethanol) fuel. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5,000 km) or 3 months, whichever comes first and follow schedule B of the “Maintenance Schedules”...
Page 252 252 MAINTENANCE SCHEDULES • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of coolant reservoir, brake master cylinder, and transaxle and add as needed. • Check all lights and all other electrical items for correct operation.
Page 253: Schedule "B
SCHEDULE “B” Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. Change the automatic transmission fluid and filter every 60,000 miles (96 000 km) if the vehicle is usually operated under one or more of the conditions marked with an •...
Page 254 254 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if necessary.* Inspect the front and rear brake pads, linings, rotors, rear drums and shoes. Rotate the tires.
Page 255 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if re- quired.* Replace the air cleaner filter. Inspect and check tension for power steering belt (2.4 Liter Engine). Adjust or replace if re- quired.
Page 256 256 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if necessary.* Inspect the front and rear brake pads, linings, rotors, rear drums and shoes. Rotate the tires.
Page 257 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. and replace if Inspect the air cleaner filter necessary.* Replace the air cleaner filter. Inspect and check tension for power steering belt (2.4 Liter Engine). Adjust or replace if re- quired.
Page 258 258 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if necessary.* Replace the air cleaner filter. Inspect and check tension for power steering belt (2.4 Liter Engine). Adjust or replace if re- quired.
Page 259 Miles (Kilometers) Change engine oil and engine oil filter, if not replaced at 3 months. Inspect the air cleaner filter and replace if necessary.* Inspect the front and rear brake pads, linings, rotors, rear drums and shoes. Replace the spark plugs on the 2.7 liter en- gine.
Page 260 260 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, if not re- placed at 3 months. Inspect the air cleaner filter and replace if neces- sary.* Replace the air cleaner filter. Replace the spark plugs on the 2.4 liter engine. Replace the ignition cables on the 2.4 liter engine.
Page 261: Schedule "A
SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if necessary.* Replace the air cleaner filter. Replace the spark plugs on 2.4 liter engine. Inspect the front and rear brake pads, linings, rotors, rear drums and shoes.
Page 262 262 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect and check tension for power steering belt (2.4 Liter Engine). Adjust or replace if re- quired.
Page 263 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect the front and rear brake pads, linings, rotors, rear drums and shoes. Replace the spark plugs on 2.4 liter engine. Replace the spark plugs on 2.7 liter engine.
Page 264 264 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the air cleaner filter and replace if required.* Replace the air cleaner filter. Inspect the front and rear brake pads, linings, rotors, rear drums and shoes. Replace the spark plugs on 2.4 liter engine.
Page 265 WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 267: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......268 Prepare For The Appointment .
Page 268: Suggestions For Obtaining Service For Your Vehicle
We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to you selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 269 • If for some reason you are still not satisfied, talk to the general manager or owner of the dealership. They want to know if you need assistance. • If your dealership is unable to resolve the concern, you may contact the Manufacturer’s Customer Center. Any communication to the Manufacturer’s Customer Center should include the following information: •...
Page 270: Warranty Information
270 IF YOU NEED CONSUMER ASSISTANCE Service Contract You may have purchased a service contract for your vehicle to help protect you from the high cost of unex- pected repairs after your manufacturer’s new vehicle limited warranty expires. The manufacturer stands be- hind only the manufacturer’s Service Contracts.
Page 271 IF YOU NEED CONSUMER ASSISTANCE 271 U.S. ONLY...
Page 272: Mopar Parts
272 IF YOU NEED CONSUMER ASSISTANCE MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are available from your dealer. They will help you keep your vehicle operating at its best. REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administra-...
Page 273 • Owner’s Manuals. These manuals have been prepared with the assistance of service and engineering specialists to acquaint you with specific Chrysler group vehicles. Included are starting, operating, emergency and maintenance pro- cedures as well as specifications, capabilities and safety tips.
Page 274: Department Of Transportation Uniform Tire Quality Grades
274 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 275: Temperature Grades
Temperature Grades The temperature grades are A (highest), B, and C, repre- senting the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
Page 277 INDEX...
Page 278 278 INDEX About Your Brakes ..... . 153 ABS (Anti-Lock Brake) System ... . . 153 Adding Engine Coolant (Antifreeze) .
Page 279 Auxiliary Power Outlet ....82 Ball Joints ......216 Battery .
Page 280 280 INDEX Charging System Light ....92 Chart, Tire Sizing ..... . . 157 Check Engine Light (Malfunction Indicator Light) .
Page 281 Cruise Control (Speed Control) ... . . 74 Cruise Light ......91 Customer Assistance .
Page 282 282 INDEX Oil ......206,246,247 Oil Change Interval ....207 Oil Selection .
Page 283 Additives ......176 Clean Air ......175 Ethanol .
Page 284 284 INDEX Heater, Engine Block ....146 High Beam Indicator ..... 92 Homelink Transmitter .
Page 285 Bulb Replacement ..... 239 Check Engine ......92 Daytime Running .
Page 286 286 INDEX Maintenance Procedures ....206 Maintenance Schedule ....250 Light Duty Schedule B .
Page 287 Parking Brake ......151 Parking On Hill ......152 Passing Light .
Page 288 288 INDEX Rotation, Tires ......172 Safety Checks Inside Vehicle ....44 Safety Checks Outside Vehicle .
Page 289 Starting and Operating ....144 Steering Power ......155,215 Tilt Column .
Page 290 290 INDEX Top Cover ......52 Towing ......179,197,198 Disabled Vehicle .
Page 291 Voltmeter ......92 Warning, Door Ajar ..... . 14 Warning Flasher, Hazard .
Page 292 292 INDEX...

Chrysler 2005 Sebring Convertible Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

Quick Links

INTRODUCTION

Chapters

Related Manuals for Chrysler 2005 Sebring Convertible

Summary of Contents for Chrysler 2005 Sebring Convertible
