User's Guide
BQ25171EVM Evaluation Module
This user's guide describes the characteristics, operation, and use of the BQ25171EVM evaluation module
(EVM). This EVM is designed to help the user evaluate and test the various operating modes of the BQ25171.
This user's guide includes setup instructions for the hardware and software, a schematic diagram, a bill of
materials (BOM), and PCB layout drawings for the evaluation module.
Throughout this user's guide, the abbreviations EVM, BQ25171EVM, BMS032, and the term evaluation module
are synonymous with the BMS032 evaluation module, unless otherwise noted.
1
Introduction.............................................................................................................................................................................2
1.1 Printed Circuit Board Assembly.........................................................................................................................................
Descriptions..................................................................................................................................................................2
2 Test Summary.........................................................................................................................................................................
2.1 Equipment..........................................................................................................................................................................
2.2 Cautions.............................................................................................................................................................................
2.3 Test Instructions.................................................................................................................................................................
Layout......................................................................................................................................................................4
3.2 Schematic........................................................................................................................................................................
3.3 Bill of Materials.................................................................................................................................................................
4 Revision History...................................................................................................................................................................
Trademarks
All trademarks are the property of their respective owners.
Hot surface! Contact may cause burns. Do not touch!
Some components may reach high temperatures >55°C when the board is powered on. The user
must not touch the board at any point during operation or immediately after operating, as high
temperatures may be present.
SLUUCA3B - JULY 2020 - REVISED JULY 2021
Submit Document Feedback
ABSTRACT
Table of Contents
Materials...................................................................................................................4
WARNING
Copyright © 2021 Texas Instruments Incorporated
Table of Contents
BQ25171EVM Evaluation Module
2
3
3
3
3
10
11
14
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments BQ25171EVM
Summary of Contents for Texas Instruments BQ25171EVM
-
Page 1: Table Of Contents
BQ25171EVM Evaluation Module ABSTRACT This user’s guide describes the characteristics, operation, and use of the BQ25171EVM evaluation module (EVM). This EVM is designed to help the user evaluate and test the various operating modes of the BQ25171. This user’s guide includes setup instructions for the hardware and software, a schematic diagram, a bill of materials (BOM), and PCB layout drawings for the evaluation module. -
Page 2: Introduction
600mA with external resistor on ISET. 1.1 Printed Circuit Board Assembly The BQ25171EVM PCB contains the BQ25171 IC, LDO TPS7B8133 and support circuits. This board contains several jumpers and connectors. S1 (VSET) allows selected output voltages to be programmed. R9 resistor allows a wide range of adjustment of VSET. -
Page 3: Test Summary
This section describes the jumpers and connectors on the EVM as well as how to properly connect, setup, and use the BQ25171EVM. Note that the default jumper setting of headers are marked with two dots to indicate the shorting jumper position. This will put the unit into a single cell Li-Ion configuration, 4.2 V at 400 mA. -
Page 4: Board Layout, Schematic, And Bill Of Materials
3 Board Layout, Schematic, and Bill of Materials 3.1 Board Layout The board layout is shown in Figure 3-1 Figure 3-6. Figure 3-1. Top Overlay BQ25171EVM Evaluation Module SLUUCA3B – JULY 2020 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... - Page 5 Board Layout, Schematic, and Bill of Materials Figure 3-2. Top Solder SLUUCA3B – JULY 2020 – REVISED JULY 2021 BQ25171EVM Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
- Page 6 Board Layout, Schematic, and Bill of Materials www.ti.com Figure 3-3. Top Layer BQ25171EVM Evaluation Module SLUUCA3B – JULY 2020 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
- Page 7 Board Layout, Schematic, and Bill of Materials Figure 3-4. Bottom Layer SLUUCA3B – JULY 2020 – REVISED JULY 2021 BQ25171EVM Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
- Page 8 Board Layout, Schematic, and Bill of Materials www.ti.com Figure 3-5. Bottom Solder BQ25171EVM Evaluation Module SLUUCA3B – JULY 2020 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
- Page 9 Board Layout, Schematic, and Bill of Materials Figure 3-6. Bottom Overlay SLUUCA3B – JULY 2020 – REVISED JULY 2021 BQ25171EVM Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
-
Page 10: Schematic
Board Layout, Schematic, and Bill of Materials www.ti.com 3.2 Schematic The BQ25171EVM schematic is shown in Figure 3-7. Figure 3-7. Schematic BQ25171EVM Evaluation Module SLUUCA3B – JULY 2020 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... -
Page 11: Bill Of Materials
RES, 8.20 k, 1%, 0.1 0603 RC0603FR-078K2L Yageo W, 0603 6.20k RES, 6.20 k, 1%, 0.1 0603 RC0603FR-076K2L Yageo W, 0603 SLUUCA3B – JULY 2020 – REVISED JULY 2021 BQ25171EVM Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... - Page 12 Test Point, Body 3.25 x S1751-46 Harwin TP4, TP6, TP7, hooks, SMT 1.65 mm TP8, TP9, TP10, TP11, TP12, TP13, TP14, TP15 BQ25171EVM Evaluation Module SLUUCA3B – JULY 2020 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
- Page 13 0, 0603 Unless otherwise noted in the Alternate Part Number and/or Alternate Manufacturer columns, all parts may be substituted with equivalents. SLUUCA3B – JULY 2020 – REVISED JULY 2021 BQ25171EVM Evaluation Module Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
-
Page 14: Revision History
Updates were made in Section 1.2 ........................2 • Update was made in Section 3.2........................• Update was made in Section 3.3........................BQ25171EVM Evaluation Module SLUUCA3B – JULY 2020 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... - Page 15 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
- Page 16 www.ti.com Regulatory Notices: 3.1 United States 3.1.1 Notice applicable to EVMs not FCC-Approved: FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and software developers to write software applications for use with the end product.
- Page 17 www.ti.com Concernant les EVMs avec antennes détachables Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à...
- Page 18 www.ti.com EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS. 4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling or using the EVM, including without limitation any warning or restriction notices.
- Page 19 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2019, Texas Instruments Incorporated...
- Page 20 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products.IMPORTANT NOTICE Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2021, Texas Instruments Incorporated...
