LED2WORK TUBELED 40 II Integrated Operating Instructions Manual page 2

| Zeichnungen
| Drawings
| Schémas
| Dibujos
| Disegni
151010-01
151110-01
151210-01
151310-01
152010-01
152210-01
2 | BA TUBELED_40 II Integrated . BA 05/2022
A B
220 mm 74 mm
395 mm 74 mm
570 mm 74 mm
745 mm 74 mm
340 mm 78 mm
700 mm 78 mm
C D
158 mm 125 mm
333 mm 250 mm
508 mm 200 mm
508 mm 250 mm
248 mm 240 mm
508 mm 305 mm
