SAVE THESE INSTRUCTIONS
CLAREMONT DINING CHAIR ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
PART LIST
FIGURE
A
B
C
D
E
F
G
I
J
MODEL #:61SRR2205CLR
QUANTITY
1PC
1PC
1PC
1PC
10+1PCS
10+1PCS
1PC
1PC
1PC
DESCRIPTION
RIGHT ARM
LEFT ARM
BACK
SEAT
BOLT(M6*15)
FLAT WASHER
ALLEN WRENCH
SEAT CUSHION
BACK CUSHION
Page 1/3
Advertisement
Table of Contents
Related Manuals for Sonoma CLAREMONT 61SRR2205CLR
Summary of Contents for Sonoma CLAREMONT 61SRR2205CLR
- Page 1 SAVE THESE INSTRUCTIONS CLAREMONT DINING CHAIR ASSEMBLY INSTRUCTIONS MODEL #:61SRR2205CLR ASSEMBLE ON A FLAT, PROTECTED SURFACE. PART LIST FIGURE QUANTITY DESCRIPTION RIGHT ARM LEFT ARM BACK SEAT BOLT(M6*15) 10+1PCS FLAT WASHER 10+1PCS ALLEN WRENCH SEAT CUSHION BACK CUSHION Page 1/3...
- Page 2 CLAREMONT DINING CHAIR ASSEMBLY INSTRUCTIONS MODEL #:61SRR2205CLR ASSEMBLE ON A FLAT, PROTECTED SURFACE. STEP 1 A. PLACE SEAT (D) UPSIDE DOWN ON A FLAT, PROTECTED SURFACE. B. CONNECT RIGHT ARM (B) TO SEAT (D) WITH FLAT WASHER (G) AND SHORT BOLT (E) USING ALLEN WRENCH (G).
- Page 3 WEIGHT LIMIT 250 LBS CARE AND CLEANING IN ORDER TO PROLONG THE LIFE OF YOUR CHAIR, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR DURING INCLEMENT WEATHER. WARRANTY 1 YEAR LIMITED WARRANTY FOR FRAME AND CUSHIONS. CUSTOMER SERVICE: PLEASE NOTE - DO NOT RETURN THIS ITEM TO THE RETAILER. CUSTOMER SERVICE HOT LINE: 1-866-905-4107 SERVICE HOURS: 11:30 A.M to 8:00 P.M EASTERN STANDARD TIME /8:30 A.M to 5:00 P.M PACIFIC STANDARD TIME E-MAIL: WWW.YOTRIO.COM...
