- Page 1 DIGITAL VIDEO RECORDER Product Specification Manual HRX-1635/HRX-1634/HRX-835A...
- Page 2 ❖ Design and specifications are subject to change without prior notice. You can download the latest version from the Hanwha Techwin web site. (www.hanwha-security.com) ❖ The initial administrator ID is “admin” and the password should be set when logging in for the first time.
-
Page 3: Important Safety Instructions
Hanwha Techwin retains the copyright on this manual. Keep these instructions. ● This manual cannot be copied without Hanwha Techwin's prior written approval. Heed all warnings. ● We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of Follow all instructions. - Page 4 overview aTTenTIon Products supporting each feature ● IL Y A RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UNE BATTERIE DE TYPE INCORRECT. METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS. Function Products ● Ne pas ingérer la pile, risque de brûlure chimique. HRX-1635/HRX-1634/HRX-835A ●...
-
Page 5: Table Of Contents
overview conTenTS overvIeW Important Safety Instructions Before Start Contents Features Package Contents Part Names and Functions (Front) Part Names and Functions (Rear) InSTallaTIon Checking the Installation Environment Rack Installation Power HDD Addition connecTIng WITH oTHer DevIce Connecting to an External Device Connecting the USB Connecting the Alarm Input/Output Connecting the Network... -
Page 6: Features
overview feaTureS Package conTenTS The product records video and audio from cameras to a hard disk, and enables playback from the hard disk. Please unwrap the product, and place the product on a flat place or in the place to be installed. It also provides remote monitoring environment for video and audio over the network using a remote computer. -
Page 7: Part Names And Functions (Front)
overview HrX-1634 ParT nameS anD funcTIonS (fronT) HrX-1635/HrX-835a ALARM NETWORK BACKUP POWER DIGITAL VIDEO RECORDER ALARM NETWORK BACKUP POWER DIGITAL VIDEO RECORDER Recorder Mouse Quick Guide HrX-1634 Power Cable Power Adaptor SATA Power Cable ALARM NETWORK BACKUP POWER DIGITAL VIDEO RECORDER SATA Data Cable (2 ea) HDD Fixing Screw (8 ea) Bracket Rack (2 ea)/Screw(4 ea) -
Page 8: Part Names And Functions (Rear)
overview ParT nameS anD funcTIonS (rear) Part Names Functions VIDEO IN Video Signal Input Port (BNC type connector). HrX-1635 Port for connecting a separate ground cable. Ground Connection ■ For safe handling of the device, please add a ground wire. SPOT BNC type of output port for the Spot signal. -
Page 9: Checking The Installation Environment
installation installation Please take note of the followings before using this product. rack InSTallaTIon ● Do not use the product outdoor. Install the Bracket-Rack as shown in the figure, and then fasten the ● Do not spill water or liquid in the connection part of the product. screws on both sides. -
Page 10: Hdd Addition
installation HDD aDDITIon Installing the HDD Make sure to unplug the power cord from the wall outlet to prevent possible electric shock, injury or product ■ If you are adding a new or previously used HDD to this product in addition to the HDD(s) originally installed, format the new HDD damage. - Page 11 installation How to install an HDD in HrX-1634 4. Fix the bracket with the HDD to the recorder with screws. 1. Loosen the screws on the left/right sides and back and slide the cover back to remove it. 2. Connect the SATA/power cable of the HDD to the connector on the motherboard.
-
Page 12: Connecting To An External Device
connecting with other device connecTIng To an eXTernal DevIce connecTIng THe alarm InPuT/ouTPuT ■ The following figures are based on Model HRX-1635. The Alarm In/Out port at the back is composed of the following. AC L1 AC L2 30VDC 2A, 125VAC 0.5A MAX Alarm MAX DC18V, Typical DC12V, 2A DC +... -
Page 13: Connecting The Network
connecting with other device connecTIng THe neTWork connecting the network camera ■ example) For more information about network connection, see "Setting the Network" in the Wisenet Recorder User Manual. ex) IP : 192.168.1.100 network connection via ethernet (10/100/1000BaseT) Switch Switch Windows Network Viewer Network Camera... - Page 14 PTZ Camera System keyboard <RS-422> TX + - Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. TX + - Data + - The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
