Hanwha - WRR-5301/5501 - Field Replacement
This document will demonstrate how to replace and install power supplies for the
Step 1 - Prepare for Replacement
Before removing the lid and performing any work inside the chassis,
please ensure:
●
You have powered down the unit via the Windows interface;
●
The power cable has been removed from the unit;
●
You are properly grounded. Simple ways to ground yourself are:
● Wearing an ESD strap.
● Making contact with a grounded portion of the chassis.
Step 2 - Contents of FRU Replacement Kit
●
The kit will contain:
● Replacement for one or two Power Supplies
● (1) FRU Guide PDF
© 2019
Unit - Power Supply
WRR-5301/5501 units.
Page 1 of 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hanwha Techwin WRR-5301
Summary of Contents for Hanwha Techwin WRR-5301
- Page 1 Hanwha - WRR-5301/5501 - Field Replacement Unit - Power Supply This document will demonstrate how to replace and install power supplies for the WRR-5301/5501 units. Step 1 - Prepare for Replacement Before removing the lid and performing any work inside the chassis, please ensure: ●...
- Page 2 Step 3 - Remove/Install a Power Supply ● The lid does not need to be removed to replace the Power Supply. ● Depress the clamp to the left (when facing the rear of the chassis). ● While the clamp is pressed, pull the power supply toward the rear of the chassis to remove it. ●...
