The instructions in this document must be followed in conjunction with the
instructions in the installation and instruction manual of the respective de-
vice. Keep both the manual and this document for future reference.
General instructions
• The stand has been specifically designed to carry the respective SOLAMAGIC
model and must not be used for any other purpose.
• The stand must be placed outdoors on a firm, non-flammable floor.
• Make sure that the area around the stand cannot be accessed by people or
animals (caution: risk of collision and toppling over).
• The minimum safety distances specified in Appendix 2 of the installation and
instruction manual are minimum distances for proper air circulation. Make sure
that these distances to other objects are always maintained.
• The infrared radiator must be installed at a height of minimum 1.80 m above the
ground.
to installation and
instruction manual
SOLAMAGIC infrared radiator:
1
Supplement
Tripod with base
01/2022
Advertisement
Table of Contents
Related Manuals for solamagic IR03001
Summary of Contents for solamagic IR03001
- Page 1 Supplement to installation and instruction manual SOLAMAGIC infrared radiator: Tripod with base The instructions in this document must be followed in conjunction with the instructions in the installation and instruction manual of the respective de- vice. Keep both the manual and this document for future reference.
- Page 2 Installation procedure: a) F ixture to base stand - ECO+ models up to 2000 W with bracket (models: IR 03001, IR 04002) Traverse with M8 x 50 knurled screw on telescopic tube Secure the bracket with the M6 x 40 knurled screws, washer 6.4, lock washer and M6 nut to the traverse Max. extended height 2.20 m Secure the adapter firmly to the telescopic tube, using the 12.5 lock washer and the M12 x 30 screw. Screw the assembly into the base.
- Page 3 b) F ixture to tripod - models with slide clamp (models: IR 03001, IR 03002, IR 04004, IR 08002, IR 08003) Part C with M8 x 50 knurled screw, on telescopic tube Max. extended height 2.20 m Secure the adapter firmly to the telescopic tube, using the 12.5 lock washer and the M12 x 30 screw. Screw the assembly into the base.
- Page 4 M12 x 30 screw. Screw the assembly into the base. Start-up / operation: • Position the device so that heat is radiated in the desired direction, taking into account the instructions in Appendix 2 of the installation and instruction manual. Caution: The power lead must be extended away from the device. Caution: Before repositioning the device, shut down the radiator and let it cool down. Wilhelm Koch GmbH | Splieterstr. 23 | D- 48231 Warendorf | Tel.: 0049 (0)36628 6910 | Fax: 0049 (0) 36628 69120 | Email: info@solamagic.com | www.SOLAMAGIC.com 01/2022...
