Morris MOR-PAC90WIFI Owner's Manual

Hide thumbs

Advertisement

Quick Links

Portable Air Conditioner
Owner's Manual
Original instructions
MOR-PAC90WIFI
(With R290 refrigerant)
READ AND SAVE THESE INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOR-PAC90WIFI and is the answer not in the manual?

Questions and answers

Related Manuals for Morris MOR-PAC90WIFI

Summary of Contents for Morris MOR-PAC90WIFI

  • Page 1 Portable Air Conditioner Owner’s Manual Original instructions MOR-PAC90WIFI (With R290 refrigerant) READ AND SAVE THESE INSTRUCTIONS...

  • Page 2: Table Of Contents

    CONTENTS 1. BEFORE YOU BEGIN 2. FOR YOUR SAFETY 3. PRODUCT OVERVIEW    4. INSTALLATION 5. OPERATION 6. CLEANING AND CARE 7. TROUBLESHOOTING 8. DECOMMISSIONING...

  • Page 3: Before You Begin

    1 . BEFORE YOU BEGIN ​ 1.1 PRODUCT DESCRIPTION Our powerful portable air conditioners are great cooling solutions for single rooms, creating a comfortable atmosphere in your space. It also    has ventilation and dehumidifying functions for circulating air and removal of moisture.
  • Page 4 Further information is available in the USER MANUAL, SERVICE MANUAL, and the like. Service personnel are required to carefully read the USER MANUAL and SERVICE MANUAL before operation. THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY This appliance is intended to be used by expert or trained users in ●...
  • Page 5 The lack of smell does not indicate a lack of escaped gas. ● If a leak is detected, immediately evacuate all persons from ● the store, ventilate the room and contact the local fire department to advise them that a propane leak has occurred. Do not let any persons back into the room until the qualified ●...

  • Page 6: For Your Safety

    2. FOR YOUR SAFETY Your safety is the most important thing we are concerned about! Please read this manual carefully and fully understand before operating your appliance. WARNING OPERATIONAL PRECAUTIONS WARNING- to reduce the risk of fire, electric shock or injury to persons or property​...
  • Page 7 ■ Do not unplug by pulling on the power cord. ■ Do not use an extension cord or an adapter plug. ■ Do not put objects on the unit. ■ Do not climb or sit on the unit. ■ Do not insert fingers or other objects into the air outlet. ■...
  • Page 8 ■ Keep any required ventilation openings clear of obstruction.   ■ The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation. Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorizes their competence to handle...
  • Page 9 SAFETY PRECAUTIONS ON SERVICING Please follow these warnings when to undertake the following when servicing an appliance with R290. 2.2.1 Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimized.
  • Page 10 2.2.6 No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
  • Page 11 – refrigeration pipes or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected against being so corroded.

  • Page 12: Product Overview

    3. PRODUCT OVERVIEW ​ 3.1 PRODUCT DIAGRAM Air inlet with Control panel Drainage Hole air filter Air outlet with adjustable Caster Air Exhaust louver Handle Note: The appearance is only for reference. Please see the real product for detailed information.
  • Page 13 FEATURES High Capacity in a compact size with cooling, dehumidifying ✔ and fan function. Temperature setting and display ✔ LED Digital display ✔ Electronic control with built-in timer, sleep mode ✔   Self-evaporating system for better efficient ✔    Auto shut off when tank full ✔...

  • Page 14: Installation

    4. INSTALLATION ​      UNPACKING Unpack the carton and take the appliance and accessories out. ●   Check the device after unpacking for any damage or scratches on ● Accessories: ● 1. Exhaust hose ■ 2. Hose connector ■ 3. Window kit adapter ■...
  • Page 15      Choose your location If tipped more than 45°, allow the ● unit to set upright for at least 24 hours before start up. Place the unit on a firm, level surface ● in an area with at least 50cm of free   ...
  • Page 16 ATTACH THE EXHAUST HOSE The air conditioner requires being vented outside so that the exhaust air can escape the room which coming from the appliance contains waste heat and moisture. Do not replace or extend exhaust hose which will result in decreased efficiency, even worse shut down the unit due to low back pressure.
  • Page 17 Step 4: ​ C lose your window to secure the kit in place. It needs to hold the  windows kit firmly in place, secure the window kit with duct tape if required.​ h e gap between the adapter and the sides of the  is recommended that t​...
  • Page 18 Step 7: ​ A djust the louver at the air outlet, and then switch on the unit.

  • Page 19: Operation

    ​ O PERATION 5. ​ CONTROL PANEL AND DISPLAY...
  • Page 20 LOCK Press to turn on or turn off the child lock function. Mode button Press to switch the operation mode MODE between fan, cooling, and dehumidifier. Increasing the desired temperature(16℃～32℃) or timer setting. POWER Press to switch the machine on or off. DOWN Decreasing the desired temperature or timer setting.
  • Page 21 REMOTE CONTROL...
  • Page 22 SETTINGS 5.3.1 Start-up and Shutdown Press POWER to turn the unit on. The unit runs in FAN as default. Press the MODE button to select the desired operation mode. Press POWER again to turn off the power. 5.3.2 Operation mode The unit has five operation modes: Cool, dry, fan, heat, sleep.
  • Page 23 B. Drying your room Press the MODE button on the control panel or remote control, and the LED of DRY operation lights up. The fan speed is unable to select. User should connect the hose to the drain outlet at the bottom of the unit. Note: In this mode, the fan speed switches over to low speed and cannot be selected.
  • Page 24 5.3.3 TIMER SETTING​ （ 1hour-24hours）: The timer has two ways of operation: To turn off (When power on) To turn on (When power off) Cancel timer 5.3.4 Automatic Defrost At low room temperatures, frost may buildup at the evaporator during operation. The unit will automatically start defrosting and the ​...
  • Page 25 ​ A bout WIFI control Information on the App ​ “ Smart Life” The ​ “ Smart Life”​ app is available for android and iOS. Scan the corresponding QR code to get directly to the download. Information on How to Use the App This appliance allows you to operate the appliance via your home net-work.
  • Page 26 disconnect, the WIFI lamp lights off.
  • Page 27 TROUBLESHOOTING of WIFI CONNECTION Network connection failed Solution 1.Check if you select the WIFI named “SmartLife​ - ​ X XXX”. Network connection 2.Turn off the machine and unplug the power timeout cord and plug in after 10 seconds, enter the App to connect again.

  • Page 28: Cleaning And Care

    Switch off the unit before ● operating. Remove the plug of the water ● outlet opening, and keep it in a safe area. Securely and properly connect ● the drain hose and make sure it is not kinked and clear of obstruction.
  • Page 29    3. Use a vacuum cleaner to suck dust from the filter. 4. Turn the filter over and rinse the air filter under running water. Let the water run through the filter in the opposite direction of airflow. Set aside and allow the filter to air dry completely before reinstalling.
  • Page 30 6.2. CLEANING UP OF REFRIGERANT General Measures: 1. Gas/vapor heavier than air. May accumulate in confined spaces, particularly at or below ground level. 2. Eliminate every possible source of ignition. 3. Use appropriate personal protection equipment (PPE). 4. Evacuate unnecessary personnel, isolate, and ventilate the area. 5.

  • Page 31: Troubleshooting

    7. TROUBLESHOOTING Symptom Inspection Solution Insert the power cord ✔ Check the power securely into the wall connection in securely​ . Outlet. The unit is not ✔ Check if the water level Empty the drain pan by operating. indicator lights up? removing the rubber plug.
  • Page 32 Check connection or ✔ Coil temperature sensor replace it. To clean or replace failures. the temperature sensor. ✔ Condensate water high Empty the drain pan by level alarm. removing the rubber plug.

  • Page 33: Decommissioning

    8. DECOMMISSIONING 8.1. STORAGE      Long-Term Storage - If you will not be using the unit for an extended period of time (more than a few weeks) it is best to clean the unit and dry it out completely. Please store the unit per the following steps: Unplug the unit and ​...
  • Page 34 8.2. DISPOSAL Releasing refrigerant into the atmosphere is strictly forbidden! WARNING!!! Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
