WARNING! IMPORTANT USER INFORMATION! Over-current protection of the power circuit is required in accordance with 7.2 of
EN 60204-1:2006. The supply disconnecting device to be in accordance with 5.3 of EN60204-1:2006. Ask a qualified electrician
about compliance. The use of extension leads to connect these compressors to the mains is not recommended.
1.3.

GENERAL SAFETY INSTRUCTIONS

9
Familiarise yourself with the application and limitations of the compressor.
9
Ensure the compressor is in good order and condition before use. If in any doubt DO NOT use the unit and contact an electrician/
service agent.
‰
WARNING! Compressor must only be serviced by an authorised agent.
8
DO NOT tamper with, or attempt to adjust, pressure switch or safety valve.
9
Before moving, or maintaining the compressor ensure it is unplugged from the mains supply and that the air tank pressure has been
vented.
9
Maintain the compressor in good condition and replace any damaged or worn parts. Use genuine parts only. Unauthorised parts may
be dangerous and will invalidate your warranty.
9
Read the instructions relating to any accessory to be used with this compressor. Ensure the safe working pressure of any air
appliance used exceeds compressors output pressure. If using a spray gun, check that the area selected for spraying is provided with
an air change system/ventilation.
9
Ensure the air supply valve is turned off before disconnecting the air supply hose.
9
To move a transportable compressor use the handle only.
8
DO NOT attempt to move the compressor by any other means.
9
Use the compressor in a well ventilated area.
9
Ensure the compressor is placed on a firm surface.
9
Keep tools and other items away from the compressor when it is in use.
9
Keep area clean and clear of unnecessary items.
9
Ensure the air hose is not tangled, twisted or pinched.
9
Keep children and unauthorised persons away from the working area.
8
DO NOT dis-assemble compressor for any reason. The unit must be checked by qualified personnel only.
8
DO NOT use the compressor outdoors, or in damp, or wet locations.
8
DO NOT operate within the vicinity of flammable liquids, gases or solids.
8
DO NOT touch the compressor cylinder, cylinder head or pipe from head to tank as these may be hot.
8
DO NOT use this product to perform a task for which it has not been designed.
8
DO NOT deface the certification plate attached to the compressor tank.
8
DO NOT cover the compressor or restrict air flow around the unit whilst operating.
▲
DANGER! DO NOT direct the output jet of air towards people or animals.
8
DO NOT operate the compressor without an air filter.
8
DO NOT allow anyone to operate the compressor unless they have received full instructions.
‰
WARNING! The air tank is a pressure vessel and the following safety measures apply:
8
DO NOT tamper with the safety valve.
8
DO NOT modify or alter the tank in any way.
8
DO NOT strap or weld anything to the tank.
8
DO NOT subject the tank to impact, vibration or to heat.
8
DO NOT allow contact with abrasives or corrosives.
9
Drain condensation from tank daily and inspect inside walls for corrosion every three months and have a detailed tank inspection
carried out annually. The tank shell must not fall below the certified thickness at any point.
‰
WARNING! If an electrical fuse blows, ensure it is replaced with an identical fuse type and rating.
9
When not in use, store the compressor carefully in a safe, dry, childproof location.
9
When the compressor is not in use it should be switched off, disconnected from the mains supply and the air drained from the tank.
1.4. INSPECTION OF PRESSURE TANK BOTH INTERNAL AND EXTERNAL
1.4.1. Under the Pressure systems Safety Regulations 2000 it is the responsibility of the owner of the compressor to initiate
a system of inspection that both defines the frequency of the inspection and appoints a person who has specific responsibility for
carrying out the inspection.
2. INTRODUCTION
Heavy-duty 3-phase compressor suitable for the professional workshop. Triple cylinder pump system coupled with a 3hp motor maximizes
performance to keep running costs low compared to single stage, single phase models. Pump features heavy-duty full cast cylinders, capped
by alloy heads for improved heat dissipation and long-life. Features an easy-to-use bespoke control panel with two outlets, one regulated
and one direct. Heavy-duty drive guards protect belt and flywheel that is designed to force air over the pump to aid cooling. Heavy-duty
pneumatic wheels with single front lockable castor for easy manoeuvrability. Supplied with hose reel to keep your workspace tidy. Full CE
certification, test certificates and operating/maintenance manual. Includes a drain valve for easy release of condensed water build-up in the
tank.

3. SPECIFICATION

Model No: .......................................................................... SAC3203B3PH
Air Displacement cfm(L/min): .......................................................13.4(380)
Maximum Free Air Delivery cfm(L/min): .......................................10.9(310)
Maximum Pressure: ..............................................................145psi(10bar)
Minimum Rated Supply: ........................................................................32A
Motor Output: ........................................................................................3hp
Outlet: ......................................................Hi-Flow Quick Release Coupling
Phase: ...................................................................................................3ph
Receiver Capacity: .............................................................................. 200L
Size (W x D x H): .....................................................1410 x 600 x 1020mm
Speed: ..........................................................................................1243rpm
Supply: ................................................................................................415V
© Jack Sealey Limited
Original Language Version
SAC3203B3PH Issue 4 (3,4,5) 04/04/22
