1.1.7. this product must be fitted with a 3-phase plug according to the diagram, and will require a minimum of 16Amps per phase
(preferably 32Amp) electrical supply. You must contact a qualified electrician to ensure an appropriately fused supply is
available.
Connect GREEN/YELLOW wire to earth (E) terminal.
connect the live wires to live 1, 2 and 3. check for the correct direction of rotation (see arrow on belt cage) to confirm
correct wiring of 3-phase plug when the compressor is first run (the top cover will need to be removed to allow this).
When completed, check that there are no bare wires, that all wires have been connected correctly, that the cable external
insulation extends beyond the cable restraint and that the restraint is tight.
1.2.

general saFetY instrUctions

familiarise yourself with the application and limitations of the compressor.
9
ensure the compressor is in good order and condition before use. if in any doubt do not use the unit and contact an electrician/service
9
agent.
Warning! compressor must only be serviced by an authorised agent. do not tamper with, or attempt to adjust, pressure switch or
‰
safety valve.
Before moving, or maintaining the compressor ensure it is unplugged from the mains supply and that the air tank pressure has been
9
vented.
maintain the compressor in good condition and replace any damaged or worn parts. use genuine parts only. unauthorised parts may be
9
dangerous and will invalidate your warranty.
read the instructions relating to any accessory to be used with this compressor. ensure the safe working pressure of any air appliance
9
used exceeds compressors output pressure. if using a spray gun, check that the area selected for spraying is provided with an air change
system/ventilation.
ensure the air supply valve is turned off before disconnecting the air supply hose.
9
to move a transportable compressor use the handle only. lift the compressor so that the front leg gives enough clearance
9
for manoeuvring but maintain unit's centre of gravity in front of the wheels. do not attempt to lift or move the compressor by any other
means.
use the compressor in a well ventilated area and ensure it is placed on a firm surface.
9
Keep tools and other items away from the compressor when it is in use, and keep area clean and clear of unnecessary items.
9
ensure the air hose is not tangled, twisted or pinched.
9
Keep children and unauthorised persons away from the working area.
9
only move the compressor by the handle if portable.
9
do not dis-assemble compressor for any reason. the unit must be checked by qualified personnel only.
8
do not use the compressor outdoors, or in damp, or wet, locations.
8
do not operate within the vicinity of flammable liquids, gases or solids.
8
do not touch compressor cylinder, cylinder head or pipe from head to tank as these may be hot.
8
do not use this product to perform a task for which it has not been designed.
8
do not deface the certification plate attached to the compressor tank.
8
do not cover the compressor or restrict air flow around the unit whilst operating.
8
▲ danger! do not direct the output jet of air towards people or animals.
do not operate the compressor without an air filter.
8
do not allow anyone to operate the compressor unless they have received full instructions.
8
Warning! the air tank is a pressure vessel and the following safety measures apply:
‰
do not tamper with the safety valve, do not modify or alter the tank in any way and do not strap or weld anything to the tank.
8
do not subject the tank to impact, vibration or to heat and do not allow contact with abrasives or corrosives.
8
drain condensation from tank daily and inspect inside walls for corrosion every three months and have a detailed tank inspection carried
9
out annually. the tank shell must not fall below the certified thickness at any point.
Warning! if an electrical fuse blows, ensure it is replaced with an identical fuse type and rating.
‰
When not in use, store the compressor carefully in a safe, dry, childproof location.
9
When the compressor is not in use it should be switched off, disconnected from the mains supply and the air drained from the tank.
9
do not carry out any welding operations on any pressurised parts of the vessel.
8
1.3. inspection oF pressUre tanK both internal and eXternal
under the pressure systems safety regulations 2000 it is the responsibility of the owner of the compressor to initiate
1.3.1.
a system of inspection that both defines the frequency of the inspection and appoints a person who has specific responsibility for
carrying out the inspection.
2. introdUction
i
Heavy-duty low noise compressors suitable for garage, bodyshop and industrial applications. fitted with cast iron cylinder heads enabling
slower revving and improved pump life. fully enclosed, insulated design gives quiet running and protects vital components from damage.
features fully automatic pressure cut out switch and tank pressure gauge. Heavy-duty three phase electric motors with soft start feature.
control box features hour meter for monitoring use and optimising service times. supplied with full ce certification and test certificate.
3. speciFication
i
model no.
motor output
supply
Phase
minimum rated supply
speed
noise level
Air displacement cfm(ltr/min)
© Jack sealey limited
sAc42755Bln
5.5hp
415V
3ph
32A
1516rpm
69dB(A)
21.1(598)
Original Language Version
sAc72775Bln
7.5hp
415V
3ph
32A
1280rpm
66dB(A)
32.6(924)
sAc42755Bln, sAc72775Bln issue 3 (H, f) 02/03/18
