Samsung SR8875 Quick Start Manual

quick start guide
Keep in mind!
How to turn on the power switch?
When you initially purchase the product,
▶
the power switch will be kept off.
Turn on the power switch at the bottom
of the robot cleaner. All functions will
work only when the power switch is
turned on.
When you turn the power switch off and then on,
all settings will be reset.
NOTE
Battery is naturally discharged!
▶ When you separate the robot cleaner from the charger,
the battery will naturally be discharged. Therefore keep
the cleaning robot on the charger, if possible.
If no key is pressed for approximately 5 minutes after
turning the power on, the power is automatically cut to
NOTE
prevent the battery discharging.To turn the power on
again, press and hold the power (Run/Stop) button on the
main body or on the remote control for a short while.
Auto charge is not smooth!
▶ When you execute the cleaning mode while the cleaning
robot is charged on the charger, it will return to automatically
charge more quickly and accurately.
1. In the following cases, lift the cleaning robot with your
hand and put it on the charger to charge it.
- When the charger is installed in a corner
- When the battery is fully discharged
- When the cleaning robot is trapped with an obstacle
- When the cleaning robot cannot pass over the doorsill to
the location where the charger is installed
2. When the charger and the cleaning robot are in separate
rooms, it could take a long period of time to automatically
charge the robot.
3. Check the installed condition of the charger.
(Refer to Installing the charger)
4. Wipe the obstacle sensor window lightly with a soft cloth.
To test the auto Homing, press the Charge button when the
cleaning robot is within 1.5M of the charger.
NOTE
The cleaning robot cannot cross over the doorsill!
The robotic vacuum cleaner's innovative
driving system makes it possible for it to
About 1.5 cm About 1.5 cm
Stair type Stair type Vertical type Vertical type
cross over doorsills with a height of
about 1.5 cm and clean all rooms.
The robotic vacuum cleaner may not be able to pass a 1.5
cm doorsill depending on the shape of the doorsill.
What do I do when the suction power is low
or the noise level is high?
▶ Clean the dust bin and filter.
▶ Clean the power brush.
The cleaning robot hits the obstacles such
as wall, furniture etc.
▶ The cleaning robot can bump into chair
legs, table legs, sofa etc. during the
operation. Put the chair on top of the
table while cleaning.
DJ68-00674N-1 EN.indd 1 DJ68-00674N-1 EN.indd 1
All manuals and user guides at all-guides.com
The cleaning robot is not able to clean the
corners!
▶
There is a weird noise!
▶
Charging time is too long!
▶
Troubleshoting for Error Codes
✽ If you press the Start/Stop button or turn off the Power
Because the cleaning robot cannot completely
clean the tight corners, wall between the sofas you
should regularly clean
those areas.
After turning off the power switch on the bottom, flip the
cleaning robot and remove any foreign substances
(Paper, vinyl) on the power brush or air pump.
If you charge the cleaning robot when the battery is heated
after the cleaning, the charging time could take longer.
ERROR
CAUSE
CODE
• Robotic vacuum • Turn off the Power Switch
cleaner is caught, at the bottom and move
stuck or trapped while the robotic vacuum cleaner
navigating. to a different location.
• A foreign substance • Turn off the Power Switch
(string, paper, toy at the bottom and remove
etc.) is caught in the the foreign substance from
power brush. the power brush.
• A foreign substance • Turn off the Power Switch
(string, paper, toy at the bottom and remove
etc.) is caught in the the foreign substance from
left driving wheel. the left driving wheel.
• A foreign substance • Turn off the Power Switch
(string, paper, toy at the bottom and remove
etc.) is caught in the the foreign substance from
right driving wheel. the right driving wheel.
• Check bumper • Slightly pull the stuck
sensor. bumper outward.
• A foreign substance • Turn off the Power Switch
(dust, stain etc.) is at the bottom and wipe
on the Obstacle the foreign substance from
sensor window. the front and rear sensor
windows using a soft cloth.
• A foreign substance • Turn off the Power Switch
(Dust, stain etc.) is at the bottom and wipe the
on the Cliff sensor foreign substance on the
window. cilff sensor window with a
soft cloth.
• Dust bin not • Insert the dust bin until you
inserted. hear a "Click" sound.
A foreign substance •
•
(String, cloth etc.)
is caught on the
edge-cleaning side
rotating brush.
Switch, the error code is cleared.
Code No. DJ68-00674N REV(0.0)
SR8875
SOLUTION
Turn off the Power Switch
at the bottom and wipe
the foreign substance
from the edge-cleaning
side rotating brush.
English
