- Page 1 SRL–EXT MOTORCYCLE MESH & BLUETOOTH ® COMMUNICATION SYSTEM FOR SHOEI HELMETS QUICK START GUIDE ENGLISH / 1.0.0...
-
Page 2: Downloadable Sena Software
Downloadable Sena Software Download the SENA MOTORCYCLES App on Google Play Store Store. SENA MOTORCYCLES • Device Configuration Setting Download the following items at sena.com. Firmware Sena Device Manager • Firmware upgrade • Device configuration setting Quick Start Guide, User’s Guide Follow us on Facebook, YouTube, Twitter and Instagram to check the latest information and helpful tips. -
Page 3: Product Details
Product Details Wired Microphone Mesh Intercom connector Antenna Status LED Charging LED Mesh Intercom Button DC Power Charging & Firmware Upgrade (-) Button Port Center Button (+) Button Speaker(L) Connector Speaker(R) Connector Battery Connector... -
Page 4: Installation
Installation The SHOEI’s RF-1400 Helmet is compatible with the SRL-EXT. The model name of the RF-1400 Helmet varies depending on the region. • RF1400(US), NXR 2(EU), Z-8(JP) • For more information about installation, refer to the User’s Guide. -
Page 9: Icon Legend
Mesh Intercom Antenna Pull the Mesh Intercom Antenna inwards slightly to unfold it. Icon Legend Tap button the specified Press and Hold button for the HOLD number of times specified amount of time Audible prompt “Hello” Basic Operations Powering On Powering Off HOLD Volume Up... -
Page 10: Checking The Battery Level
Phone Pairing ① HOLD “ Configuration menu” Blinking ② “ Phone pairing” ③ Select SRL-EXT in the list of Bluetooth devices detected. Bluetooth SRL - EXT Device B • For more information on phone pairing, refer to the User’s Guide. -
Page 11: Using The Phone
Using the Phone Answer a Call End a Call HOLD Reject a Call HOLD Siri and Google Assistant Activate the Siri or Google Assistant Installed on Your Phone “ Hey Google” HOLD or “Hey Siri” Music Control Play/Pause HOLD Track Backward Track Forward HOLD HOLD... - Page 12 “ Mesh intercom on, Open Mesh, channel 1” Mesh Intercom Off “ Mesh intercom off” Note: When Mesh Intercom is on, the SRL-EXT will automatically connect to nearby SRL-EXT users and the headset will be in Open Mesh (default: channel 1) initially.
- Page 13 ① Enter into the Channel Setting. “ Channel setting, 1” ② Navigate between channels. ••• Exit •••) “ #” ③ Save the channel. “ Channel is set, channel #” Note: You can use the SENA MOTORCYCLES App to change the channel.
- Page 14 Group Mesh Group Mesh is a closed group intercom function that allows users to join, leave, or rejoin a group intercom conversation without pairing each headset. 1) Creating a Group Mesh Creating a Group Mesh requires two or more Open Mesh users.
- Page 15 2) Joining an Existing Group Mesh One of the current users in an Existing Group Mesh can allow users (one or more) in Open Mesh to join the Existing Group Mesh. Existing Group Mesh Open Mesh Existing Group Mesh One (You) of the current users in the Existing Group Mesh and ①...
-
Page 16: Bluetooth Intercom
Enable/Disable Mic (Default: Enable) Users can enable/disable the microphone when communicating in a Mesh Intercom. HOLD “ Mic on” or “Mic off” Reset Mesh If the headset in an Open Mesh or Group Mesh resets the Mesh, it will automatically return to Open Mesh (default: channel 1). HOLD “... - Page 17 Using the Smart Intercom Pairing (SIP) SIP allows you to quickly pair with your friends for intercom communication by scanning the QR code on the SENA MOTORCYCLES App without remembering the button operation. ① Pair the mobile phone with the headset.
- Page 18 Using the Button Users (You, B) enter into Intercom Pairing. ① Blinking HOLD “ Intercom pairing” Turns blue ② The two headsets (A and B) will be automatically paired. ③ Repeat the steps above to pair with other headsets (C and D). Last-Come, First-Served If the headset has multiple paired headsets for intercom conversations, the last paired headset is set as the First Intercom Friend.
-
Page 19: Two-Way Intercom
Two-way Intercom Start/End Conversation with the First Intercom Friend D Start/End Conversation with the Second Intercom Friend C Start/End Conversation with the Third Intercom Friend B... - Page 20 FM Radio FM Radio On/Off Start/Stop Scanning HOLD HOLD Seek Forward Seek Backward Navigating Preset Stations HOLD Note: You can also save the current station from the SENA MOTORCYCLES App.
-
Page 21: Configuration Menu
Configuration Menu Accessing the Configuration Menu HOLD “ Configuration menu” Navigating Between Menu Options Execute Menu Options... -
Page 22: Troubleshooting
Troubleshooting Fault Reset Pinhole Fault Reset Button Note: Fault Reset will not restore the headset to factory default settings. Factory Reset ① HOLD “ Configuration menu” ② “ Factory reset” “ Headset reset, ③ good-bye”... -
Page 23: Quick Reference
Quick Reference TYPE OPERATION BUTTON COMMANDS HOLD Power on / Power off Basic Operations Volume up / Volume down Answer phone call HOLD End phone call Mobile Phone HOLD Reject phone call Activate the Siri or HOLD Google Assistant Siri and Google Assistant... - Page 24 TYPE OPERATION BUTTON COMMANDS Mesh Intercom on/off Channel setting HOLD Mesh Grouping Mesh Intercom™ HOLD Reset Mesh HOLD Enable/Disable Mic HOLD Intercom pairing Intercom Start/End intercom HOLD Play/Pause music HOLD Track forward Music HOLD Track backward...
- Page 25 TYPE OPERATION BUTTON COMMANDS HOLD FM radio on/off HOLD Select preset FM Radio Seek forward/backward Scan up FM band/ HOLD stop scanning 1.0.0_EN_April2022...
