A&D FX-iWP Series Instruction Manual

Dust and waterproof precision balance
Hide thumbs
Table of Contents

Advertisement

Quick Links

N
ADENDUM to FX-iN/FX-iWPN Legal For trade（LFT）Approved Models
Purchased FX-iN/FX-iWPN balances are LFT/Legal for Trade. These balances can be set following the
regulations for the US and Canadian markets. However, there are some differences and limitations in
comparison to the standard versions FX-i/FX-iWP balances, as detailed below.
Note: It is fully the responsibility of the purchaser to set up the balances, including calibration and sealing,
in accordance with local weights and measures regulations.
1. Display and key Operation
①
General Key operation
For the CAL, MODE, SAMPLE, and PRINT keys, please refer to "4. DISPLAY SYMBOLS
AND KEY OPERATION" of the standard instruction manual.
Key Operation for LFT Approved Model
The ON:OFF key becomes the ON:OFF/ZERO key
①
When this key is pressed and hold for 2 seconds: The display turns ON/OFF.
When this key is pressed once: The display is zeroed out.
For the other functions of the ON:OFF key mentioned in the general instruction manual, please
use the ON:OFF /ZERO key as the equivalent of the ON:OFF keys in the standard versions.
The RE-ZERO key in the standard version becomes the TARE key on the legal for
②
trade version.
When this key is pressed: The Tare value is registered/canceled.
For the other functions of the RE-ZERO key mentioned in the instruction manual,
please use the TARE key.
Front label
③
The front label must be changed in accordance with the selected mode.
(Example: FX120iN)
This is purchasers' responsibility
This document hosted by: www.oldwillknottscales.com
or
1
Ver.D20191212B
③
②
Default label (e=10d)
Label in the products' box (e=d)
