Page 1 FX-1202 / FX-2202 / FX-3202 / FX-5202 FZ-WP Series (Dustproof and Waterproof, Internal Adjustment Type) FZ-123WP / FZ-223WP / FZ-323WP FZ-1202WP / FZ-2202WP / FZ-3202WP FX-WP Series (Dustproof and Waterproof Type, External Adjustment Type) FX-123WP / FX-223WP / FX-323WP FX-1202WP / FX-2202WP / FX-3202WP 1WMPD4004606A...
Page 2: About This Manual
SAFETY NOTES AND OTHER NOTES This manual contains the following safety warnings, symbols and other messages. Word and symbol (for harm to persons / for damage to property): A hazardous situation that, if not avoided, will or could result in minor or CAUTION moderate injury or property damage.
Page 3: Table Of Contents
Contents Introduction ............................7 1.1. About the models .......................... 7 1.2. Features ............................8 1.3. Compliance ........................... 9 Part Names, Installation, and Cautions ..................10 2.1. 0.0001 g models .......................... 11 2.2. 0.001 g models / 0.01 g models ....................12 2.3.
Page 4 9.1. Setting procedure ........................64 9.2. Details of the function table ......................67 9.3. "Environment / Display" explanation ................... 74 9.4. "Clock" explanation (FZ / FZ-WP series only) ................76 9.5. "Comparator" explanation ......................84 9.5.1. Setting example. "Comparison when stable or overloaded (excluding near zero)" ....85 9.6.
Page 5 15.1. RS-232C ............................ 164 15.2. Windows Communication Tools Software (WinCT) ..............164 15.3. Windows Communication Tools for Parameter Setting (WinCT-ParamSet) ......165 Commands ..........................166 16.1. Control commands ........................166 16.2. <AK> code and error codes ...................... 168 16.3. Command usage examples ...................... 169 Key Lock Function ........................
Page 6 Options and Accessories ......................231 23.1.1. Options ........................... 231 23.1.2. Accessories ..........................235 Terms ............................240...
Page 7: Introduction
1.1. About the models The FZ / FX / FZ-WP / FX-WP series are available in multiple models with different combinations of weighing capacities and readability. In this manual, they are classified and described according to the readability as shown in the table below.
Page 8: Features
1.2. Features The FZ / FX / FZ-WP / FX-WP series are compact balances with readability from 0.0001 g to 0.01 g and can be installed almost anywhere. (For details, refer to "22. Specifications".） The FZ / FZ-WP series are equipped with an internal weight so sensitivity adjustment can be performed with just one key press.
Page 9: Compliance
The keys on the balance can be locked by sending a specified command to the balance. (For details, refer to "17. Key Lock Function".) Various optional devices (sold separately) are available. (For details, refer to "23.1.1. Options".) When an optional communication interface, FXi-05, FXi-08, or GXA-27, is installed, weighing data format different from that of the RS-232C interface can be selected.
Page 10: Part Names, Installation, And Cautions
Part Names, Installation, and Cautions This product is a precision instrument, and it should be carefully unpacked. The contents of the package vary depending on the model. Make sure that everything is included. It is advisable to store the packing materials so that they can be used when transporting the balance for repair.
Page 11: G Models
2.1. 0.0001 g models The large breeze break must be attached before use. Follow steps 1 to 3 below to attach the large breeze break Place the large breeze break on the main unit with the locking handles pulled out. (10) Push the locking handles back in while keeping the breeze break pressed against the main unit...
Page 12: G Models / 0.01 G Models
2.2. 0.001 g models / 0.01 g models Follow steps 1 to 4 below to assemble the small breeze break (Refer to the next page for the dustproof and waterproof type, 0.001 g models / 0.01 g models.) Name Name Name Small breeze break*...
Page 13: Dustproof And Waterproof Type 0.001 G Models / 0.01 G Models
2.3. Dustproof and waterproof type 0.001 g models / 0.01 g models Follow steps 1 to 4 below to assemble the small breeze break Caution: Do not deform this diaphragm.* Name Name Name Diaphragm for achieving the Small breeze break* 17 Main unit rear side waterproof performance*...
Page 14: Assembling
2.4. Assembling Assemble the weighing pan and the small breeze break (included with all models of the FZ / FZ-WP series except for the 0.0001 g models and with the FX-123 / 223 / 323 / 523 / 123WP / 223WP / 323WP) or the large breeze break (included with all the 0.0001 g models) while referring to the previous section "2.
Page 15 FZ-WP/FX-WP series The balance’s dustproof and waterproof rating is equivalent to IP65, and its second digit, "5", corresponds to "having no harmful influence by receiving direct jet of water". Washing with strong water pressure or submersion in water may cause water to enter the balance and cause a malfunction.
Page 16: Adjusting The Level Of The Balance
2.6. Adjusting the level of the balance Level the balance by adjusting the leveling feet so that the bubble of the bubble spirit level is centered in the red circle. Bubble spirit level circle Bubble The balance The balance is level. is tilted.
Page 17 Influence of magnetism may cause weighing errors. When measuring magnetic materials (iron, etc.), keep the sample away from the balance main body by means such as underhook weighing. Magnetic material Convection Weighing errors may occur if there is a difference between the ambient temperature and temperature of the sample (and the container).
Page 18: Cautions After Use
As another approach, using the optional AD-1683A static eliminator or applying an anti-static spray is also effective. About the FZ-WP / FX-WP series The balance has a highly airtight casing for achieving dustproof and waterproof performance. Therefore, the values displayed on the balance may become unstable due to minute indoor pressure fluctuations in the room when opening or closing the door.
Page 19: Display And Key Panel (Basic Operation)
Display and Key Panel (Basic Operation) 3.1. Display Lit display Blinking display Name Processing indicator Stabilization indicator Standby indicator for power supply Number of statistical data (statistical calculation function) Load/capacity relationship in % (Capacity indicator) Function table set value display Response indicators (lit for 30 seconds after start of weighing) Comparator indicators Display hold mark...
Page 20: Key Operation
3.2. Key operation Key operations affect how the balance functions. Normal key operation during measurement is "Press and release the key immediately" or "Press and hold the key for (approx.) 2 seconds". Please do not press and hold the key for 2 seconds unless required. Press the key Press and hold the key (Press and release the key immediately.)
Page 21: Weighing
4.1.1. Units The FZ / FX / FZ-WP / FX-WP series are equipped with the units (modes) of measure shown below. You can specify the units (modes) to store with the function table. (Refer to "9.7. "Unit" for storing units (modes) explanation").
Page 22 The tables below show the weighing capacity and the readability for each unit, depending on the balance model. Capacity Readability Unit FZ / FX Gram 0.0001 Ounce (Avoir) 3.59 5.36 8.88 0.00001 Troy Ounce 3.27 4.88 8.10 0.00001 Metric Carat 1260 0.001 Momme...
Page 23 Capacity Readability Unit FZ / FX / FZ-WP / FX-WP FZ / FX Gram 0.001 Ounce (Avoir) 4.30 7.76 11.2 18.3 0.00005 Pound 0.268 0.485 0.705 1.14 0.000005 Pound/Ounce 0L 4.30 oz 0L 7.76 oz 0L 11.29 oz 0L 18.34 oz 1L 0.01 oz Troy Ounce 3.92...
Page 24: Programmable-Unit
4.1.2. Programmable-unit The programmable-unit function allows the balance to calculate and display the conversion result by multiplying the weighing value in grams with the coefficient you have set with the function table. Note that the coefficient must be within the minimum and maximum range below. If the coefficient is outside this range, an error message will appear, and the balance will return to setting mode, prompting you to enter a valid value.
Page 25 Step Description Display and key operation Confirming the set coefficient The currently set coefficient is displayed with the first digit blinking. Setting a new coefficient Set a coefficient by operating the keys as explained below. SAMPLE key Selects a digit to change the value. The selected digit blinks. RE-ZERO key Changes the value.
Page 26: Basic Operation
4.2. Basic operation 4.2.1. Zero-point setting, tare subtraction operation, and weighing range At the start of weighing The balance determines the reference zero-point when the weighing display is turned on with the ON:OFF key. Depending on the load condition at that time, the balance will automatically judge whether to perform zeroing or tare subtraction operation.
Page 27 Re-zero operation Pressing the RE-ZERO key sets the display to zero. Re-zero operation with the RE-ZERO key automatically determines which operation to perform: zero setting or tare subtraction. Based on the "zero range", tare subtraction is performed when the range is exceeded.
Page 28 Turning on/off the readability digit Step Description Display and key operation Weighing operation Pressing the SAMPLE key toggles the readability digit on / off. Weighing range Each balance model has a specific range in which it can weigh and display. If a gross weight exceeds the maximum display capacity for the model, the balance displays , indicating that the weight is over the weighing range.
Page 29: Smart Range Function
4.3. Smart range function The FZ-254D and FX-254D are equipped with two ranges: standard range and precision range (high resolution range). Smart range function The balance automatically switches between the standard and precision (high resolution) ranges depending on the value to be displayed. The precision range can be used even with a heavy container (tare) on the weighing pan if you set the display to zero by pressing the RE-ZERO key.
Page 30: Counting Mode (Pcs)
4.4. Counting mode (PCS) This is the mode to determine the number of objects in a sample. Based on the reference sample unit weight (weight per piece), the balance calculates and displays how many pieces the sample weight corresponds to. The smaller the variation in the unit weight of sample pieces is, the more accurate the count will be.
Page 31 Step Description Display and key operation Weighing operation Place a container on the weighing pan if necessary. Press the RE-ZERO key to display Container (In this example, the number of sample pieces to store is 25.) Place the specified number of samples on the weighing pan.
Page 32: Counting Mode
Step Description Display and key operation Weighing operation Counting mode The balance is now ready to perform counting. With the stabilization indicator lit, pressing the PRINT key outputs the weighing value (count) externally. A printer, PC, or peripheral equipment (sold separately) is required.
Page 33: Percent Mode (Percent Weighing Mode)
4.5. Percent mode (Percent weighing mode) The percent mode displays the weighing value in a percentage compared with a reference mass as 100%. This is useful for target weighing or sample variance checks. Caution appears if the balance judges that the sample is too light to be stored as the 100% reference mass.
Page 34: Percent Weighing
Step Description Display and key operation Weighing operation Press the PRINT key to store the 100% reference mass. The balance displays 100.00 %. The stored 100% reference mass is stored in nonvolatile memory even if the power is removed. Percent weighing Now it is ready to perform percent weighing.
Page 35: Impact Shock Detection (Isd) Function
Impact Shock Detection (ISD) Function The balance has a function to detect impact shocks to the mass sensor section and to display the impact level. By lowering the impact level at the time of loading, it is possible not only to alleviate variation in the weighing value but also to reduce the risk of failure of the mass sensor section.
Page 36: Impact History Output
5.2. Impact history output The stored impact history can be output by sending a specified command to the balance or performing key operation. Output by key operation Step Description Display and key operation Press the ON:OFF key to turn off the display. With the display off, press the ON:OFF key while holding down the MODE key.
Page 37 Examples of impact history output The output contents of the FZ / FZ-WP series and those of the FX / FX-WP series are different. FZ / FZ-WP series: Date, time, impact level and login user information are output together on one line.
Page 38: Response Adjustment
Response Adjustment Disturbances such as draft and vibration at the place where the balance is installed affect weighing. In the response adjustment settings, the response characteristics of the balance can be set in three stages according to the disturbance. Indicator Function table Response Display stability...
Page 39 Step Description Operation Press the MODE key to select a rate of the response adjustment. (Either FAST , MID. , or SLOW can be chosen.) After a few seconds of inactivity, or when the PRINT key is pressed, the balance displays The balance returns to weighing mode and displays the updated response indicator for a while.
Page 40: Sensitivity Adjustment / Calibration Test
Sensitivity Adjustment / Calibration Test Since the balance resolution is high, its weighing values may change due to gravity and day-to-day environmental changes. It is necessary to perform sensitivity adjustment using a weight to keep the weighing values from changing even if gravity or the environment changes. It is advisable to perform sensitivity adjustment when the balance is installed for the first time or relocated or when the weighing values in daily inspection and the like have deviated significantly.
Page 41 Cautions on using an external weight It is critical that the weight for sensitivity adjustment be accurate as it ensures the accuracy of the balance after sensitivity adjustment. Select from the list below an appropriate weight for sensitivity adjustment / calibration test using an external weight.
Page 42: Sensitivity Adjustment Using The Internal Weight (Fz / Fz-Wp Series Only)
Sensitivity adjustment using the internal weight (FZ / FZ-WP series only) Sensitivity adjustment using the internal weight can be performed with one key press. (The FX / FX-WP series does not have a function to perform sensitivity adjustment using the internal weight.) Caution Refer to "2.6.
Page 43: Calibration Test Using The Internal Weight (0.0001 G Models Of The Fz Series Only)
7.2. Calibration test using the internal weight (0.0001 g models of the FZ series only) This function uses the internal weight to check how accurate the balance weighs. (No sensitivity adjustment is performed.) This function is available only when the output of reports compliant with GLP/GMP and the like is set ( set to or ) in the function table ("9.
Page 44 Step Description Display and key operation Weighing operation The checked full-scale point value is displayed. For the full-scale point, see the reference values shown below. If the displayed value falls within the normal range, the balance has been adjusted correctly with the internal weight.
Page 45: Sensitivity Adjustment Using An External Weight
7.3. Sensitivity adjustment using an external weight This is a function to perform sensitivity adjustment using an external weight. Operating procedure Step Description Display and key operation Weighing operation With nothing on the weighing pan, warm up the balance by providing power for at least half an hour, or at least an hour for the 0.0001 g models..
Page 46 Step Description Display and key operation Weighing operation Place the external weight on the weighing pan. Then, press the PRINT key. The balance weighs the weight. Do not apply vibration and the like to the balance. Remove the weight from the weighing pan. After the sensitivity adjustment, the balance will output the "sensitivity adjustment report"...
Page 47: Calibration Test Using An External Weight
7.4. Calibration test using an external weight This is a function to perform calibration test using an external weight to check how accurate the balance weighs. (No sensitivity adjustment is performed.) This function is available only when the output of reports compliant with GLP/GMP and the like is set ( set to or ) in the function table ("9.
Page 48 Step Description Display and key operation Weighing operation The balance weighs the value for the zero-point. Do not apply vibration and the like to the balance. The measured zero-point value is displayed for a few seconds. Place the weight on the weighing pan. Then, press the PRINT key.
Page 49: Setting The Value Of The External Weight
7.5. Setting the value of the external weight When performing a sensitivity adjustment or calibration test, the value of your external weight can be set. For usable weights, refer to the list for "Cautions on using an external weight". To set the value, follow the setting procedure after is displayed as described in "7.3.
Page 50 Step Description Display and key operation Set the value of the weight by operating the keys as explained below. Weight selection SAMPLE key Toggles between the display where all digits blink (weight selection mode) and where the last two digits blink* (instrumental error adjustment mode).
Page 51: Correcting The Internal Weight Value (Fz / Fz-Wp Series Only)
7.6. Correcting the internal weight value (FZ / FZ-WP series only) Caution The function to perform correction of the internal weight value is disabled at factory settings. To enable it, follow the setting procedure below. Setting procedure Step Description Display and key operation Press the ON: OFF key to turn the display off.
Page 52 Step Description Display and key operation Press the RE-ZERO key to set "Internal weight value correction switch" to " ". "Internal weight value correction switch" To store the setting and return to weighing mode, press the PRINT key.
Page 53: How To Correct The Internal Weight Value: Method 1 (Manual)
7.6.1. How to correct the internal weight value: method 1 (MANUAL) In this method, the value of the balance's internal weight is manually corrected based on an external weight: First, perform sensitivity adjustment with the internal weight while referring to "7.1.
Page 54 Step Description Display and key operation Weighing operation Press the SAMPLE key several times until is displayed. Press several times does not appear, follow step 1 to change the setting. Press the PRINT key. Perform correction by operating the following keys as explained below. RE-ZERO key Changes (+1) the value to be corrected.
Page 55 Step Description Display and key operation Weighing operation Press the CAL key. The balance returns to weighing mode. Attach the breeze break, and then press the CAL key to perform sensitivity adjustment with the internal weight. Place the external weight on the weighing pan to confirm that the internal weight value has been adjusted correctly within the correct range (refer to "22.2.
Page 56: How To Correct The Internal Weight Value: Method 2 (Auto)
7.6.2. How to correct the internal weight value: method 2 (AUTO) In this method, the value of the balance's internal weight is automatically corrected based on an external weight: First, perform sensitivity adjustment while referring to "7.3. Sensitivity adjustment using an external weight".
Page 57 Step Description Display and key operation Weighing operation Perform sensitivity adjustment while referring to "7.3. Sensitivity adjustment using an external weight". Once the sensitivity adjustment process is over and the weight is removed, appears. When preparation is complete, press the PRINT key. With displayed, balance...
Page 58: Function Selection Switch And Initialization
"allow changes/use" can be selected. When "prohibit changes" is set, inadvertent data change can be prevented because the function cannot be activated. There are the following types of "Function selection switch". Item FZ / FZ-WP series FX / FX-WP series Function selection ・ Function table ・ Function table switch ・...
Page 59 Step Description Display and key operation Set the function selection switch by operating the keys as explained below. SAMPLE key Selects the blinking digit (switch) to change. RE-ZERO key Changes the value of the blinking digit (switch). : Prohibit changes and use : Allow changes and use PRINT key Stores the new value.
Page 60 No function No function ■ Prohibit internal weight value correction ■ Internal weight correction Allow internal weight value correction FX / FX-WP series (the display at factory settings) Param- Name Description eter Prohibit changes to the function table. Function table Allow changes to the function table.
Page 61: Initializing The Balance
8.2. Initializing the balance This function returns the parameters of the balance to the factory settings. 8.2.1. Initialization (all items) This function resets the following parameters to the factory settings. Sensitivity adjustment data Function table other than the password lock function, unit weight (counting mode), and 100% reference mass value (percent mode) External weight value Function selection switch settings...
Page 62 Step Description Display and key operation Press the PRINT key. (To cancel, press the CAL key.) Press the RE-ZERO key to switch between " ". Pressing the PRINT key starts initialization. When the process is completed, the balance automatically returns to weighing mode.
Page 63: Initialization (Function Table Only)
8.2.2. Initialization (function table only) This function returns the following parameters to the factory settings. Function table other than the password lock function Function selection switch settings Statistical calculation data Setting procedure Step Description Display and key operation Press the ON: OFF key to turn the display off. While holding down the PRINT and SAMPLE keys, press the ON: OFF key to display While holding down...
Page 64: Function Table
Step Description Display and key operation Pressing the PRINT key starts initialization. When the process is completed, the balance automatically returns to weighing mode. Function Table The balance's functions, communications, etc. can be set and changed with the function table ("9.
Page 65 Setting procedure This example shows how to set the parameters for " (Data output mode)" and " (Auto print difference)" to " (Auto print mode A)" and " (100 d)" respectively. Step Description Key operation Class Item In weighing mode, press and hold the SAMPLE key for 2 seconds to display Press and hold for 2...
Page 66 Step Description Key operation Class Item Press the SAMPLE several times to select the item. Press several times "10 d" of "Auto print band width" If you want to change other item(s) in the same class, repeat steps 4 and 5. finish changing settings for the class, proceed...
Page 67: Details Of The Function Table
9.2. Details of the function table Class Item Parameter Description Fast response, sensitive value This setting also acts as the averaging time when " ■ (Hold function)" is set to " Condition (On)". Slow response, stable value Stricter judgment (The If the range in which the lowest digit displayed ±1) weighing display fluctuates...
Page 68 Class Item Parameter Description The buzzer sounds when you operate the keys and the like. Buzzer Environment ■ / Display (Continued from Impact shock level indicator Impact Shock Detection previous page) ■ Confirms and sets the time Refer to "9.4. "Clock" explanation and date.
Page 69 Class Item Parameter Description Outputs data accepting the Key mode PRINT key when the ■ weighing value is stabled. Outputs data when the Auto print mode A weighing value is stable beyond the range of (Reference: zero) from the zero point. Outputs data when the Auto print mode B weighing value is stable...
Page 70 Class Item Parameter Description At the specified display refresh rate Every 2 seconds ■ Every 5 seconds Every 10 seconds Used when "Interval output mode" is set for "Data output Every 30 seconds Interval time mode" ( set to ). Data output Every 1 minute (Continued from...
Page 71 Class Item Parameter Description A&D standard format ■ DP format KF format Refer to "9.6. "Data output" explanation" Data format MT format NU format CSV format No output ■ Sets whether or not the ID number is output. ID output Output No output ■...
Page 72 Class Item Parameter Description Water temperature ■ Displayed only when density Liquid density input mode is stored in unit Density registration. Density Solids measurement ■ Refer to "11. Density (Specific function Density measurement Gravity) Measurement". Liquids mode This setting is only applicable Sets a coefficient.
Page 73 Class Item Parameter Description ■ On (Restrict weighing Refer to "12. Password Lock operation) Function". Lock function On (Allow basic weighing operation) Password Administrator password input lock User 1 password input Password registration User 10 password input Correction of the internal weight value: method 1 Refer to "7.
Page 74: Environment / Display" Explanation
9.3. "Environment / Display" explanation "Condition ( )" Sensitive response to fluctuation of a weighing value. For powder or liquid target weighing, weighing a very light sample, or when work efficiency set to is required rather than display stability, set the parameter to be a small value. When set, FAST is displayed.
Page 75: Hold Function
"Hold function ( )" (Animal weighing mode) This function is used to weigh a moving object such as an animal. When the weighing data is over the animal weighing range from zero and the display fluctuation is within the stabilization range for a fixed period of averaging time, the processing indicator illuminates and the balance displays the average weight of the weighing data.
Page 76: Auto Power Off
"Auto power-OFF ( )" This is a function to automatically turn off only the display when there is no operation made for a certain amount of time (approx. 10 minutes) while the power is on. "Readability ( )" For weighing with lower precision, the readability digit can be turned off without key operation. This is useful when built into automated devices.
Page 77 Checking / setting procedure Display and key Step Description operation In weighing mode, press and hold the SAMPLE key for 2 seconds to display Press and hold for 2 seconds Press the SAMPLE key to display Press the PRINT key to enter the mode to check and set the time and date.
Page 78: Checking The Date
Display and key Step Description operation Checking the date The currently set date is displayed. If you need to change the date, press the RE-ZERO key. Proceed to step 5 "Setting the date (Selected digits blink)". To step 5 "Setting the date (Selected digits...
Page 79 Display and key Step Description operation Setting the date (Selected digits blink) First, select a date format for the order of displaying year ( ), month ( ), and day ( ). Operate the keys as explained below. RE-ZERO key With each press, the selection changes in the order of "year( )/month(...
Page 80: Changing The Date
Display and key Step Description operation Changing the date Set the date by operating the keys as explained below. (Input the last two digits of the year. For example, "22" means 2022.) RE-ZERO key Changes (+1) the value of the blinking digits. MODE key Changes (−1) the value of the blinking digits.
Page 81: Checking The Time
Display and key Step Description operation Checking the time The currently set time is displayed. (All digits blink.) If you need to change the time, press the RE-ZERO key. Proceed to step 8 "Setting the time". To step 8 "Setting the time".
Page 82: Setting The Time
Display and key Step Description operation Setting the time Set the time (in 24-hour format) by operating the keys as explained below. RE-ZERO key Changes (+1) the value of the blinking digits. MODE key: Changes (−1) the value of the blinking digits. SAMPLE key Selects the digits that blink.
Page 83 Display and key Step Description operation Finishing checking / setting The next item of the function table menu is displayed ("9. Function Table"). To finish checking / setting, press the CAL key. The balance returns to weighing mode.
Page 84: Comparator" Explanation
9.5. "Comparator" explanation The results of the comparison are indicated by HI , OK , and LO on the display. There are five types of comparisons: "No comparison" "Comparison when stable or overloaded (excluding near zero)" "Comparison when stable or overloaded (including near zero)" "Continuous comparison (excluding near zero)"...
Page 85: Setting Example. "Comparison When Stable Or Overloaded (Excluding Near Zero)
9.5.1. Setting example. "Comparison when stable or overloaded (excluding near zero)" Selecting a comparison method (operating range, comparison criteria, and value input) Step Description Display and key operation In weighing mode, press and hold the SAMPLE key for 2 seconds to display Press and hold for 2 seconds...
Page 86 Entering the upper limit value Step Description Display and key operation With displayed, press the PRINT key. The currently set upper limit value is displayed (with all digits blinking). If no change is required for the value, press the PRINT or CAL key. Proceed to step 9.
Page 87 Step Description Display and key operation To change the value, press the RE-ZERO key. Change and store the setting by operating the keys as explained below. SAMPLE key Selects the digit that blinks. RE-ZERO key Changes (+1) the value of the blinking digit. MODE key Reverses the polarity.
Page 88 Entering the lower limit value Step Description Display and key operation With displayed, press the PRINT key. The currently set lower limit value is displayed (with all digits blinking). If no change is required for the value, press the PRINT or CAL key. Proceed to step 12.
Page 89 Step Description Display and key operation To change the value, press the RE-ZERO key. Change and store the setting by operating the keys as explained below. SAMPLE key Selects the digit that blinks. RE-ZERO key Changes (+) the value of the blinking digit. MODE key Reverses the polarity.
Page 90 Step Description Display and key operation To return to weighing mode, press the CAL key.
Page 91: Data Output" Explanation
9.6. "Data output" explanation 9.6.1. Data output modes The data output timing of the balance can be switched by setting " (Data output mode)" in " (Data output)" of the function table ("9. Function Table"). Key mode Function table: set to The balance outputs the weighing data once when the PRINT key is pressed while the stabilization indictor is displayed.
Page 92: Stream Mode
Stream mode Function table: set to The balance outputs the weighing value at the rate set by " (Display refresh rate)" in " (Environment/Display)" of the function table ("9. Function Table"), regardless of the status of the stabilization indicator. The display does not blink at this time. Example of use: "To monitor constantly the weighing values on a computer"...
Page 93 Caution Depending on the interval time and baud rate, complete data may not be transmitted unless the baud rate is increased. Auto print mode C Function table: set to The balance outputs the weighing data when the weighing value is beyond the range of " (Auto print polarity)"...
Page 94: Data Output Settings
9.6.2. Data output settings RS-232C connection can be set by " (Connection)" in " (Serial interface)" of the function table ("9. Function Table") in such a way as to allow irregular operations according to connected peripheral devices. " " " setting functions Description Param- Class...
Page 95: Weighing Data Format
9.6.3. Weighing data format Selecting the weighing data format The output format used with the RS-232C interface can be selected by setting " (Data format)" in " (Serial interface)" of the function table ("9. Function Table"). The output format used with an optional communication interface can be selected by setting " (Data format)"...
Page 96 RS-232C interface: set to KF format Optional interface*: set to except for FX-05) This is the Karl-Fischer moisture meter format. Consists of 14 characters (excluding the terminator). There are no headers. The polarity sign is added to the first character if the value is not an overload or zero. The data is zero-suppressed (leading zeros are replaced with spaces).
Page 97: Csv Format
RS-232C interface: set to CSV format Optional interface: set to The data part and unit part of A&D standard format are separated by a separator ",". Outputs the unit even when overloaded. When the decimal comma (,) is set, a semicolon (;) will be used instead as a separator. Header Data Unit...
Page 98: Output Examples Of Weighing Data Format
9.6.4. Output examples of weighing data format When stable A&D T TAB + 4 TAB When unstable A&D − − − − − − − S TAB − 6 TAB ASCII character codes Carriage return ASCII 0Dh Line feed ASCII 0Ah : Space ASCII 20h TAB: Horizontal tab...
Page 99 When overloaded (positive) A&D L TAB + 9 TAB When overloaded (negative) A&D − − − − − − L TAB − 9 TAB ASCII character codes Carriage return ASCII 0Dh Line feed ASCII 0Ah : Space ASCII 20h TAB: Horizontal tab ASCII 09h...
Page 100 Units A&D D.P. Counting mode Percent mode Ounce (Avoir) Pound Pound ounce Troy ounce Metric carat Momme Pennyweight Grain Tael (HK general, Singapore) Tael (HK, jewelry) Tael (Taiwan) Tael (China) Tola (India) Mesghal Density Programmable-unit (Multi-unit)
Page 101: Other Data Formats
9.6.5. Other data formats In addition to weighing data, other data can be added. Switch each function on/off as necessary in the function table ("9. Function Table"). ASCII character codes Carriage return ASCII 0Dh : Space ASCII 20h Line feed ASCII 0Ah ID number To output, set "...
Page 102 Time To output the time using the clock data of the FZ / FZ-WP series balance, set " (Time / date output)" to " (Time output only)" or " (Time and date output)" in the function table ("9. Function Table"). 24-hour format.
Page 103: Unit" For Storing Units (Modes) Explanation
9.7. "Unit" for storing units (modes) explanation This section explains "Unit ( )" of the function table ("9. Function Table"). The units (modes) can be stored by the following procedure to select with the MODE key when the balance is in weighing mode. Use this setting to change the order of units or hide unnecessary units. The units stored are maintained in non-volatile memory even if the AC adapter is removed and are valid until updated.
Page 104 Step Description Display and key operation Specify the units (and modes) in the order they are displayed by operating the keys as explained below. SAMPLE key: Selects a unit (or mode). RE-ZERO key: Specifies the selected unit (or mode) and displays " ". Press the PRINT key to store the units (modes).
Page 105: Glp Report And Id Number
9.8. GLP report and ID number 9.8.1. Main objectives Data compliant with GLP, GMP and the like can be output to a printer or PC via an RS-232C or optional interface. GLP stands for Good Laboratory Practice. GMP stands for Good Manufacturing Practice. For GLP / GMP report output, data includes the balance manufacturer (A&D), model name, serial number, ID number, date*, time*, and space for a signature.
Page 106: Setting The Id Number
9.8.2. Setting the ID number The ID number can be used as an identification number for the balance during maintenance of the balance. The ID number is stored in non-volatile memory even if the AC adapter is removed and is valid until a new registration is made.
Page 107 Step Description Display and key operation Press the PRINT key. Set the ID number by operating the keys as explained below. SAMPLE key Selects the digit that blinks. RE-ZERO key Changes the character of the blinking digit (in forward order). Refer to "Correspondence table".
Page 108: Glp Report
Step Description Display and key operation Press the CAL key to return to weighing mode. 9.8.3. GLP report To output data compliant with GLP, GMP and the like using an AD-8127 compact printer or a PC, set " (GLP output)" to " (On with the balance’s internal clock)" or " (On with the external device’s clock)" in "...
Page 109 Output for sensitivity adjustment with the internal weight This is the GLP output when sensitivity adjustment of the balance is performed with the internal weight. (Function table: " " set to " ") Caution The balance’s internal clock may require adjustment. If so, set with in the function table ("9.
Page 110 Outputting clock data of an external device The examples below show data output compliant with GLP, GMP, and the like when " " is set to " (On with the external device’s clock)" in the function table ("9. Function Table"). It is possible to use the clock data of an external device such as a PC or printer when "...
Page 111 Output for calibration test with the internal weight This is the GLP output when the accuracy of a balance is checked with the internal weight. (Sensitivity adjustment is not performed.) Only 0.0001 g models support this output. (Function table: " "...
Page 112 Output for sensitivity adjustment with an external weight This is the GLP output when a sensitivity adjustment of a balance is performed with an external weight. (Function table: " " set to " ") Examples Printer format (AD-8127) PC format (RsCom) ˽...
Page 113 Output for calibration tests with an external weight This is the GLP output when the accuracy of a balance is checked with an external weight. (Sensitivity adjustment is not performed.) (Function table: " " set to " " ) Examples Printer format (AD-8127) PC format (RsCom) ˽...
Page 114 Output of "Title block" and "End block" Purpose and operation The "Title block" and "End block" can be added before and after a series of weighing data for data management. Pressing and holding the PRINT key for 2 seconds outputs the "Title block" and "End block" alternately. Caution When an AD-8127 compact printer is used to output data, set it to dump printing mode.
Page 115 Examples (Function table: " " set to " ", " " set to " ") Printer format (AD-8127) PC format (RsCom) ˽ : Space, ASCII 20h With the FZ / FZ-WP series, date and time data is output. <TERM>: Terminator, C or C : Carriage return, ASCII 0Dh : Line feed, ASCII 0Ah...
Page 116: Application Function
9.9. "Application function" Applications can be switched by " (Application mode)" in " (Application function)" of the function table ("9. Function Table"). 9.9.1. "Normal weighing mode" This mode is for normal weighing. It is enabled at factory settings. " (Application mode)" set to " " 9.9.2.
Page 117 Preparation Display and key Step Description operation Switching to "Statistical calculation mode" (Change in the function table) Press and hold the SAMPLE key for 2 seconds to display Press and hold for 2 seconds. Press the SAMPLE key several times to display Press several times.
Page 118: Selecting The Weighing Unit
Display and key Step Description operation Press the RE-ZERO key to select the desired parameter for The example on the right shows the display when the parameter " " is selected to output the following items: Number of data instances, Sum, Maximum, Minimum, Range (maximum–minimum), Average, Press several times.
Page 119: Operating Procedure
Operating procedure Display and key Step Description Weighing operation operation Entering data for statistical calculation In statistical calculation mode, the data No. of the weighing value used for statistical calculation is displayed in the display's upper left corner. Operate the statistical calculation functions by operating the keys as explained below.
Page 120 Display and key Step Description Weighing operation operation PRINT key (when a weighing value is displayed) Outputs the data No. and weighing value and adds the displayed weighing value to statistical processing. (The output is different from the format set in "9.6.3.
Page 121 Display and key Step Description Weighing operation operation When the stabilization indicator lights up, press the PRINT key to add the displayed weighing value to the statistical processing. The number of data instances at the display's top left increases by one. Repeat steps 2 to 4 for every weighing.
Page 122 Display and key Step Description Weighing operation operation To output the statistical results, press the PRINT key when a statistical result is displayed. Example of statistical results output Parameter (for Statistical results output Deleting the latest data When the wrong data is entered, it can be deleted and excluded from statistical calculation. Only the last entry will be deleted, and other previous data cannot be deleted.
Page 123: Clearing Statistical Data
Display and key Step Description operation Press the PRINT key to exclude the latest data from statistical processing. The number of data instances displayed with the weighing value is reduced by one. Output example "*CANCEL*" output Clearing statistical data All statistical data will be deleted and the number of data instances will be zero. Display and key Step Description...
Page 124 Display and key Step Description operation Pressing the PRINT key initializes the statistical data. The number of data instances returns to zero. Output example "*CLEAR*" output...
Page 125: Statistical Calculation Mode (Example Of Use)
9.9.4. Statistical calculation mode (example of use) Here, as an example of using statistical calculation mode, mixing of the multiple formula ingredients such as medicine is explained. The mixing process is recorded using the balance and the printer. In this example, an FX-323 and AD-8127 (in dump printing mode) are connected using the RS-232C serial interface.
Page 126 Display and key Step Description operation Enabling "Auto rezero after data output" Select "Auto rezero after data output" by pressing the SAMPLE key Press several times several times to display then the PRINT key to display Press the SAMPLE key several times to display Press several times Enable "Auto...
Page 127 Operating procedure Display and key Step Description Weighing operation operation Press the RE-ZERO key to set the display to zero. Place a container on the weighing pan, then press the PRINT key to set the display to 0.000 g. (The tare weight is stored.) If an external output device is connected, the data is output.
Page 128 Display and key Step Description Weighing operation operation When there are more formula ingredients to mix, repeat To step 4 or step 6 step 4. To finish mixing, proceed to step 6. After mixing is completed, press the MODE key to display the statistical result.
Page 129: Underhook
10. Underhook The underhook is used for underhook weighing such as the measurement of magnetic materials. To use the built-in underhook, remove the cap on the bottom of the balance. Caution Do not apply excessive force to the underhook. When not in use, attach the cap to prevent dust from getting into the balance. Do not push the underhook upward.
Page 130: Density (Specific Gravity) Measurement
11. Density (Specific Gravity) Measurement The balance has density mode that calculates the density of a solid or liquid from the weight in air and the weight in liquid. We recommend using a separately sold AD-1654 density determination kit for measurements. For assembly and installation instructions, refer to the "AD-1654 Density Determination Kit Instruction Manual".
Page 131: Preparation For Measurement (Change In Function Table)
11.1. Preparation for measurement (Change in function table) Prior to density (or specific gravity) measurement, change the balance's function table as follows. Storing " (Density mode)" with "Unit" " (Density mode)" can be stored with " (Unit)" in the function table ("9.
Page 132 Display and key Step Description operation Press the RE-ZERO key to specify the unit; the indicator " " is displayed with the specified unit. Press the PRINT key to store the specified units. Press the CAL key to return to weighing mode. Pressing the MODE key switches the units in the specified order: "...
Page 133: Sample Selection
Sample selection Select either solids or liquids as the sample to be measured. The sample to be measured can be specified with " (Density measurement mode)" in " (Density measurement function)" of the function table ("9. Function Table"). Selecting procedure Display and key Step Description...
Page 134 Display and key Step Description operation Select the sample to be measured by operating the keys as explained below. SAMPLE key Selects " (Density measurement mode)". RE-ZERO key Selects " (Solids)" or " (Liquids)" for " ". The following settings are available. "...
Page 135 Selecting "Liquid density input" for solid density (specific gravity) measurement Proceed to step 17 for liquid density (specific gravity) measurement when " " is set to " (Liquids)" as the setting of [ (Liquid density input)] is not related. Selecting procedure Display and key Step Description...
Page 136 Display and key Step Description operation The preliminary setting is complete. To start measurement, press the CAL key to return to weighing display. Press the MODE key to display density mode unit. Proceed to "11.2. Measuring the density (specific gravity) of a solid"...
Page 137: Measuring The Density (Specific Gravity) Of A Solid
11.2. Measuring the density (specific gravity) of a solid The following describes the operation when " (Sample selection)" is set to " (Solids)" in " (Density measurement function)" of the function table ("9. Function Table"). For the setting method, refer to "11.1.
Page 138 Display and key Step Description Weighing operation operation Weight in liquid measurement mode Transfer the sample from the weighing pan in air to the weighing pan in liquid and wait for the display to stabilize. (" " lit, " " lit) At this time, adjust so that the sample is about 10 mm below the liquid level.
Page 139: Inputting The Density Of A Liquid
Display and key Step Description Weighing operation operation Solid density display mode When a density is displayed, pressing the PRINT key outputs the density. The density (specific gravity) unit is " ". Output example with PC (RsCom): Density (specific gravity) Density (specific A&D standard format (factory setting) gravity) output...
Page 140 Water temperature input method Below is a supplementary explanation of step 7 "Liquid density input mode (" " set to " ")" in "11.2. Measuring the density (specific gravity) of a solid (" " set to " ")". The currently set water temperature is displayed. (25.0 °C at factory settings) For relationship between water temperature and water density, refer to "Correspondence table between water temperature and...
Page 141 Density input method Below is a supplementary explanation of step 7 "Liquid density input mode" (" " set to " ")" in "11.2. Measuring the density (specific gravity) of a solid (" " set to " ")". The currently set density is displayed. (1.000 g/cm at factory settings.) The set value can be changed with the key operations explained below.
Page 142: Measuring The Density (Specific Gravity) Of A Liquid
11.4. Measuring the density (specific gravity) of a liquid The following describes the operation when " (Sample selection)" is set to " (Liquids)" in " (Density measurement function)" of the function table ("9. Function Table"). For the setting method, refer to "11.1.
Page 143 Display and key Step Description Weighing operation operation Weight in liquid measurement mode For density measurement, put the liquid in the beaker and sink the float. (" " lit, " " lit) At this time, adjust so that the float is about 10 mm below the liquid level.
Page 144 Display and key Step Description Weighing operation operation Liquid density display mode When a density is displayed, pressing the PRINT key outputs the density. Output example with PC (RsCom): Density (specific gravity) A&D standard format (factory setting) Density (specific ST,+0000.247˽DS<TERM> gravity) output ˽: Space, ASCII 20h <TERM>: Terminator, C...
Page 145: Inputting The Volume Of The Float
11.5. Inputting the volume of the float Below is a supplementary explanation of step 7 "Liquid volume input mode" in "11.4.Measuring the density (specific gravity) of a liquid". The currently set volume of the float is displayed. (Factory setting is 10.00 cm The set value can be changed with the key operations explained below.
Page 146: Password Lock Function
12. Password Lock Function Usage The password lock function can restrict the use and functions of the balance. It is effective in preventing falsification of date and time settings or preventing changes in the function table by the user. Input The password is set with four digits using the following four keys: 256 combinations (= 4 ×...
Page 147 set to : Login with the Administrator’s password required when changing settings Anyone can perform weighing operations, but restrictions can be placed on initialization and setting changes (including clock). (Password entry using the ON:OFF key will not be required at the start of weighing.) There are two login levels: Administrator ( ) and Guest ( Login level...
Page 148: Enabling Password Lock Function
12.1. Enabling password lock function With " (Password function)" set in the function table ("9. Function Table"), the password function can be switched between Disabled (" set to " "), Enabled (" set to " "), and Enabled (" " set to " "). Setting method Display and key Step...
Page 149: Entering A Password At The Start Of Weighing
Display and key Step Description operation Press the RE-ZERO key to switch between " " and " " to display (" " is blinking when is selected.) With " " selected, press the PRINT key to enable the password lock function. is displayed.
Page 150 Display and key Step Description operation Enter a 4-digit password with the key operations explained below. MODE key Enters " ", and then activates the next digit to the right for input. SAMPLE key Enters " ", and then activates the next digit to the right for input. PRINT key Enters "...
Page 151 Display and key Step Description operation When the correct password is entered, the login level, all segments and indicators, and weighing display are displayed in order. To log in as the Administrator, enter the password of the Administrator. (The factory default password is set at the Administrator level, which can be changed by pressing the RE-ZERO key four times: "...
Page 152: Login With The Password Of The Administrator When Changing The Settings (" " Set To " ")
12.2.2. Login with the password of the Administrator when changing the settings (" " set to " ") To log in as a guest ( Display and key Step Description operation With the display turned off, press the ON:OFF key. After appears, the balance returns to weighing mode.
Page 153 Display and key Step Description operation Enter a 4-digit password with the key operations explained below. MODE key Enters " ", and then activates the next digit to the right for input. SAMPLE key Enters " ", and then activates the next digit to the right for input. PRINT key Enters "...
Page 154: Logging Out
Display and key Step Description operation When the correct password is entered, the login level, all segments and indicators, and weighing display are displayed in order. To log in as the Administrator, enter the password of the Administrator. (The factory default password is set at the Administrator level, which is set by pressing the RE-ZERO key four times: "...
Page 155: How To Register
How to register Display and key Step Description operation In weighing mode, press and hold the SAMPLE key for 2 seconds to display Press and hold for 2 seconds Press the SAMPLE key several times until appears. Press several times Press the PRINT key to display Press the SAMPLE key to display Press the PRINT key to display the login level (...
Page 156: Changing Password
Display and key Step Description operation Press the SAMPLE key to select the login level ( through ) that you want to change. If the login level has a registered password already, the stability indicator " " lights. (The password can be changed.) Press several times.
Page 157 Display and key Step Description operation Enter a 4-digit password with the key operations explained below. MODE key Enters " ", and then activates the next digit to the right for input. SAMPLE key Enters " ", and then activates the next digit to the right for input. PRINT key Enters "...
Page 158 Display and key Step Description operation When all four entries using the keys are completed, the new password is displayed. appears. (" " is blinking when is selected.) (If the CAL key is pressed, the display returns to the 4th digit entry.) Press the RE-ZERO key to switch between "...
Page 159: Deleting Password (User)
12.6. Deleting password (User) Caution The administrator password cannot be deleted. To change the password, refer to "12.4. Registering (changing) password" and "12.5. Changing password" How to delete Display and key Step Description operation While referring to "12.5. Changing password", select the user ( through ) whose password you want to delete and display the password entry display.
Page 160: Interface Specifications
13. Interface Specifications 13.1. RS-232C Connector D-Sub 9-pin (male) Transmission system EIA RS-232C Transmission form Asynchronous, bi-directional Data transmission rate Approx. 5 times per second, approx. 10 times per second, approx. 20 times per second (Linked with " (Display refresh rate)" in " (Environment / Display)"...
Page 161: Cables Needed To Connect To Peripheral Devices
13.2. Cables needed to connect to peripheral devices Connection cables for peripheral devices and interfaces are as follows. Connection cables for peripheral interface Peripheral Connection cable Communication Note interface Name Model Standard / Option Model AX-KO1710-200 [Standard] RS-232C cable included with the Multi-functional AD-8127 AX-KO2741-100...
Page 162: Printing Weighing Values To A Printer
14. Printing Weighing Values to a Printer The following shows examples of the balance’s function table settings and the printer settings corresponding to the type of printer to be used and the method of printing data, such as weighing value. 14.1.
Page 163: Adding Information Such As Date/Time And Id Number To Weighing Values With The Balance's Clock Function
14.1.2. Adding information such as date/time and ID number to weighing values with the balance’s clock function Common settings for the balance to print weighing values and additional information on the AD-8127 Class Item Parameter Description Printer Connection Serial interface DP format Data format Settings to print weighing values and additional information on the AD-8127...
Page 164: Connecting To A Pc
15. Connecting to a PC 15.1. RS-232C The RS-232C interface of the balance is the DCE (Data Communication Equipment) that can be connected to a PC. Straight-through cables should be used at the RS-232C cables. If the PC does not have an RS-232C connector, use an AX-USB-9P (USB converter with cable, sold separately).
Page 165: Windows Communication Tools For Parameter Setting (Winct-Paramset)
(WinCT-ParamSet) WinCT-ParamSet is data communication software for Windows that enables a PC to change the function table settings in the FZ / FX / FZ-WP / FX-WP series balances. Communication with a PC is performed via RS-232C. For connection between the balance and PC, a cable such as AX-USB-9P (USB converter with cable) is required.
Page 166: Commands
Turns the display off. Operates the CAL key. FZ / FZ-WP series: Sensitivity adjustment with the internal weight FX / FX-WP series: Sensitivity adjustment with an external weight FZ / FZ-WP series: Sensitivity adjustment with an external weight Operates the MODE key.
Page 167 Command Description [Function in weighing mode] Locks specified key switches. LK: ***** A numerical value from 00000 to 00063 enters in place of ***** . (For details, refer to "17.2. Locking specified key switches"). Requests the locking status for specified key switches. (For details, refer to "17.2.
Page 168: Ak> Code And Error Codes
Turns the display on/off. (Only when the display is on.) R、Z、<ESC>T Same as the RE-ZERO key. Tare operation FZ / FZ-WP series: Sensitivity adjustment with the internal weight FX / FX-WP series: Sensitivity adjustment with an external weight FZ / FZ-WP series: Sensitivity adjustment with an external weight...
Page 169: Command Usage Examples
16.3. Command usage examples In the following examples, " (AK, Error code)" is set to " (On)" in " (Serial interface)" or " (Optional interface)" of the function table ("9. Function Table") so that an <AK> code (ackknowledgement, ASCII 06h) is sent when the balance has successfully processed the command. ASCII codes and symbols CR: Carriage return, ASCII 0Dh Line feed, ASCII 0Ah...
Page 170 Example of the CAL command (S ensitivity adjustment with the internal weight of the FZ/FZ-WP series) PC side Balance side Step Command Response Display Weighing operation CAL command Attach the breeze break Before execution Command received Processing Nothing on the Waiting for rezero weighing pan stability...
Page 171 Example of the CAL command (S ensitivity adjustment with the internal weight of the FX/FX-WP series) EXC command for the FZ / FZ-WP series PC side Balance side Step Command Response Display Weighing operation CAL command Before execution Nothing on the...
Page 172 PC side Balance side Step Command Response Display Weighing operation Remove the weight Waiting for rezero stability (Processing) Process completed Zero display Example of the T command PC side Balance side Step Command Response Display Weighing operation T command Before execution Place the Command received container on the...
Page 173 Example of the PT command PC side Balance side Step Weighing Command Response Display operation PT command (Tare weight: 100 g) Before execution Command received Tare value display ?PT command Tare value "˽" represents a space.
Page 174: Key Lock Function
17. Key Lock Function By sending a specific command to the balance, you can lock the key switches on the balance. When controlling the balance only with an external device such as a PC, use this function. The key control commands can be executed even when the key switches are locked. For the key control commands, refer to section "16.
Page 175: Communication Options (Fx-05 / Fxi-08 / Gxa-27)
18. Communication Options (FX-05 / FXi-08 / GXA-27) FX-05 ( 18.1. USB interface) An FX-05 (sold separately) installed on the balance allows connection between the balance and a PC via the included USB cable in order to output weighing data to the PC. Two methods of communication, Quick USB mode (uni-directional communication) and Virtual COM mode (bi-directional communication) are available, which can be switched by "...
Page 176: How To Install
Back of the balance Remove the screws (2 pieces) and panel on the back of the balance. Step 3 For the FZ-WP/FX-WP series, also remove the rubber packing attached with the panel. Peel off the cable connector attached to the panel with double-sided adhesive tape, and pull it out of the balance case.
Page 177: Additional Settings For Fx-05
18.1.2. Additional settings for FX-05 Installing an FX-05 on the balance adds the following " (Optional interface)" menu after " (Serial interface)" in the function table ("9. Function Table"). Set the following items related to output of data via the FX-05. Class Item Parameter...
Page 178: Usb Operation Modes
18.1.3. USB operation modes To switch Quick USB mode (uni-directional communication) and Virtual COM mode (bi-directional communication), follow the steps below. Caution If the parameters other than " (Quick USB mode)" cannot be selected in " " of the function table, unplug the AC adapter and plug it in again.
Page 179 Display and key Step Description operation Select " (Quick USB mode)" or " (Virtual COM mode)" as the Quick USB mode parameter for " " with the RE-ZERO key. Virtual COM mode Press the PRINT key to store the setting. Press the CAL key to return to weighing mode.
Page 180: Quick Usb Mode
18.1.4. Quick USB mode In Quick USB mode, connect the balance to your PC with the included USB cable to input the output data of the balance directly into Excel, Word, or other software on your PC. Windows 7 or later is supported. This mode uses the standard Windows driver (HID), so a dedicated driver is not required and communication is enabled simply by connecting your PC and the balance.
Page 181 Display and key Step Description Weighing operation operation Open the waterproof cap. Connect the balance to a PC using the USB cable included with the FX-05. At the initial connection, the PC will automatically start installing the driver. Back of the balance FX-05 Waterproof cap USB cable...
Page 182 Display and key Step Description Weighing operation operation To end communication, disconnect the USB cable. AC adapter Back of the balance FX-05 USB cable (included with FX-05)
Page 183: Virtual Com Mode
18.1.5. Virtual COM mode In Virtual COM mode, connect the balance to your PC with the included USB cable and create a COM port on your PC to enable bi-directional communication. Windows 7 or later is supported. A dedicated driver is required to enable use on PCs running an OS other than Windows 10 or 11.
Page 184 Display and key Step Description Weighing operation operation Connect the balance to a PC using the USB cable included with the FX-05. Back of the balance AC adapter FX-05 USB cable (included with FX-05) A driver must be installed manually in systems other than Windows 10 or 11.
Page 185 Display and key Step Description Weighing operation operation Place a sample on the weighing pan. To send weighing data from the balance, press the PRINT key on the balance or send a send data command from the PC. Output example with PC (RsCom): A&D standard format (factory setting) ST,+0001.234˽˽g<TERM>...
Page 186: Fxi-08 (Ethernet Interface)
18.2. FXi-08 (Ethernet interface) Installing an FXi-08 (sold separately) on the balance allows connection to a LAN (Ethernet) to enable bi- directional communication with a PC on the LAN by TCP/IP. Straight-through cables (3) Ethernet hub Balance Balance FXi-08 FXi-08 This manual describes the procedure for communication using the WinCT-Plus software at factory settings.
Page 187: How To Install
Remove the two screws (2 pieces) and panel on the rear of the Stap 3 balance. For the FZ-WP / FX-WP series, also remove the rubber packing with the panel. Peel off the cable connector attached to the panel with double-sided Screws adhesive tape, and pull it out of the balance case.
Page 188: Additional Settings For The Fxi-08
18.2.2. Additional settings for the FXi-08 Installing an FXi-08 on the balance adds the following " (Optional interface)" menu after " (Serial interface)" in the function table ("9. Function Table"). Set the following items related to output of data via the FXi-08. Class Item Parameter...
Page 189: Installing Software Programs
18.2.3. Installing software programs If the following software programs are already installed on your PC, proceed to "18.2.4 Configuring the network". If not, log in by a user name with administrator privileges and install them. Installation of "DeviceInstaller" for FXi-08 configuration The "DeviceInstaller"...
Page 190 Step Description...
Page 191: Configuring The Network Settings
18.2.4. Configuring the network settings To implement a LAN connection, it is required to set the IP address, subnet mask, etc. for both the PC and the FXi-08. Please consult with the network administrator before assigning IP addresses, etc. FXi-08 factory settings IP address 172.16.100.2 Subnet mask...
Page 192 Example 2) When a PC is connected directly to a single balance (with an FXi-08 installed) Crossover cables should be used at the LAN cables. Instrument IP address Subnet mask 172.16.100.1 255.255.0.0 FZ-323 172.16.100.2 Crossover cable FZ-323 172.16.100.1 172.16.100.2...
Page 193: Configuring The Pc Settings
18.2.5. Configuring the PC settings Set the PC’s IP address and subnet mask. Open the "Internet Protocol Version 4 (TCP/IPv4) Properties" window, select "Use the following IP address", and enter the IP address and the subnet mask. Please consult with the network administrator for the set values. Caution Please set the PC's IP address manually.
Page 194: Checking The Settings Of The Balance And Fxi-08
18.2.6. Checking the settings of the balance and FXi-08 (1) Settings of the balance Communication settings for the balance and FXi-08 are made automatically. To change the balance’s output data, refer to "18.2.2 Additional settings for the FXi-08". (2) Settings of the FXi-08 Using the "DeviceInstaller"...
Page 195 Step Description Click on the + mark to expand the parameters and select the IP address that you would like to change as shown in the figure below. The FXi-08 is set to 172.16.100.2 at factory settings. If you do not change the IP address, proceed to "19.2.7. Setting RsMulti". To change the IP address, proceed to step 5.
Page 196 Step Description Check the "Assign a specific IP address" option, and click "Next". Enter the IP address, subnet mask, and default gateway, and click "Next". It may take a while to proceed to the next screen. Example of IP address: 172.16.100.3...
Page 197 Step Description Click the "Assign" button. It may take a while to complete the setting. Click "Finish".
Page 198 Step Description Quit after verifying that the IP address has been changed. Write down the set IP address on the IP address label included with the FXi-08 and attach it to the balance for identification.
Page 199: Configuring The Rsmulti Settings
18.2.7. Configuring the RsMulti settings Step Description Launch the software program from the Start menu on the PC: Click "Start", "Program", "A&D WinCT-Plus", "RsMulti". Caution The setting procedure may differ depending on your PC environment. To open the <Config> window, select [Open] from the [Config] menu in the RsMulti window.
Page 200 Step Description The connection settings can be added and changed in the <Config> window. To make a new addition, click [Add]. To change, click [Property]. For details, refer to the explanations about the <Config> and <Property> windows. In the default setting, "Example" is registered at CH1 and the IP address and the port number are set at the same as the default settings of FXi-08.
Page 201 Step Description As shown below, FZ-323 is registered in the <Config> window. To connect multiple units, click the [Add] button to add each unit connected and configure the settings in the same manner. The configuration is now ready. Press the [OK] button to save the settings.
Page 202: Data Acquisition With Rsmulti
18.2.8. Data acquisition with RsMulti Step Description Preparations for communication From the [Connect Name] list in the <RsMulti> window, select the name of the balance to be connected, and then click the [Test] button to check the connection. ・ When sending a send data command to the balance for data acquisition: Enter "Q"...
Page 203: Data Acquisition
Step Description Data acquisition ・ When sending the "Q" command to the balance for data acquisition: Click the "Command" button to send the set command to the balance for data acquisition. The sent data enters into the cells. (If [Repeat] is selected in the [Manual/Repeat] option, the command will be automatically sent in every setup time.) ・...
Page 204: Bluetooth ® Interface)
18.3. GXA-27 (Bluetooth ® interface) With a GXA-27 (sold separately) installed, the balance can be paired with a compatible instrument or a Bluetooth-equipped PC / tablet / smartphone to communicate wirelessly. The FZ-WP / FX-WP models have the capability for wireless communication without compromising dust-proof and waterproof performance (IP65 compliant).
Page 205: Additional Settings For The Gxa-27
18.3.1. Additional settings for the GXA-27 Installing a GXA-27 on the balance adds the following " (Optional interface)" menu after " (Serial interface)" in the function table ("9. Function Table"). Set the following items related to output of data via the GXA-27. Caution parameters are only available when is lit (bi-directional communication...
Page 206: Setting The Dip Switch
18.3.2. Setting the DIP switch Before installing the GXA-27 on the balance, set the DIP switch to match the connection method for the Bluetooth-enabled device. For the connection methods, refer to "18.3.4. Keyboard input connection (with HID over GATT Profile)" and "18.3.5.
Page 207: How To Install
Remove the two screws from the rear of the balance and remove the panel. For the FZ-WP / FX-WP series, also remove the rubber packing attached to the panel. Peel off the cable connector attached to the panel with double- Cable sided adhesive tape, and pull it out of the balance case.
Page 208: Keyboard Input Connection (With Hid Over Gatt Profile)
18.3.4. Keyboard input connection (with HID over GATT Profile) In this connection method, you connect the balance with the GXA-27 installed to a terminal that operates as a wireless keyboard, such as a Bluetooth-enabled PC, tablet, or smartphone. The output data from the balance can be input into general text applications (such as memo pad or spreadsheet software).
Page 209 Paring with A&D WeiV ® Caution Use the Scan screen of A&D WeiV ® to pair the balance with A&D WeiV ® If you have performed pairing using the settings screen of the Bluetooth-equipped terminal, unpair once and then operate the Scan screen of A&D WeiV ®...
Page 210 Step Description Once the connection is established, the balance model name and serial number will be displayed on the main screen.
Page 211 Connecting to a PC for bi-directional communication This manual describes the procedure for connection by pairing the balance (with the GXA-27 installed) and an AD-8541-PC Bluetooth® dongle for PC (sold separately). For more details, refer to the separate instruction manual "AD-8541-PC Wireless Communication Interface".
Page 212 Connecting to a remote display for bi-directional communication This manual describes the procedure for connection by pairing the balance (with the GXA-27 installed) and an AD-8931 remote display (sold separately), via Bluetooth ® . For the details of AD-8931 Bluetooth remote display (sold separately), refer to the separate instruction manual "Wireless Remote Display AD-8931".
Page 213 Display and key Step Description operation Press the RE-ZERO key several times to change the " " to " (Stream mode)". Press the PRINT key to store the setting. Press the CAL key to return to weighing mode. Pairing with an AD-8931 Caution One AD-8931 can be connected to one compatible weighing instrument.
Page 214 Display and key Step Description operation The BT indicator blinks, and pairing starts. BT indicator When pairing is established, the BT indicator lights up. If the balance to be connected is not found (i.e., if the BT indicator BT indicator does not light up), the power will turn off after about one minute.
Page 215: Checking The Software Version Of The Balance
19. Checking the Software Version of the Balance Balance specifications may differ depending on the software version of the balance. To confirm the software version, follow the steps shown below. How to check Display and key Step Description operation Unplug the AC adapter from the balance and plug it in again. is displayed for about one second.
Page 216: Maintenance
20. Maintenance 20.1. Treatment of the balance When cleaning the balance Do not use organic solvents, alcohol, or chemical wipes. Main unit Wipe the main unit with a lint free cloth that is moistened with warm water and a mild detergent.
Page 217 Cleaning 0.0001 g models Step 1. Before cleaning the balance, unplug the AC adapter from the outlet. Step 2. Pull out the locking handles and remove the large breeze break from the main unit Step 3. Remove the weighing pan and breeze break ring , and clean the top of the main unit Step 4.
Page 218 Cleaning 0.001 g or 0.01 g models Step 1. Before cleaning the balance, unplug the AC adapter from the outlet. Step 2. Remove the small breeze break from the main unit . (For all FZ models and FX-123 / 223 / 323 / 523 models) Step 3.
Page 219 Cleaning dust-proof and waterproof 0.001 g or 0.01 g models Step 1. Before cleaning the balance, unplug the AC adapter from the outlet. Step 2. Remove the small breeze break from the main unit . (For all FZ-WP models and FX-123WP / 223WP / 323WP models) Step 3.
Page 220 FZ-WP / FX-WP series specifications The dustproof and waterproof specifications of the FZ-WP / FX-WP series are waterproof for daily use, which allows the weighing pan to be washed in water while installed. Note that if the balance is submerged in water or used in such a way that water pressure is applied to the bottom of the balance body, water may enter the interior of the balance.
Page 221: Troubleshooting
21. Troubleshooting 21.1. Checking the balance performance and environment Since the balance is a precision instrument, in some cases it may not be able to measure correct values due to adverse effects of the measurement environment or measurement method. If repeatability is poor when the sample is loaded and unloaded several times, or if the balance seems to be operating abnormally, check the following items.
Page 222: Error Displays And Codes
21.2. Error displays and codes Display Code Description and possible countermeasure Overload error A sample beyond the weighing capacity has been placed on the weighing pan. Remove the sample from the pan. Weighing pan error The weighing value is too light. Check that the weighing pan is installed correctly.
Page 223 Display Code Description and possible countermeasure Unit weight error The sample unit weight is too light to be used in counting mode; which may cause a significant counting error. For accurate counting, add samples to reach the displayed number, then press the PRINT key (even though pressing the PRINT key with no samples added will put the balance in counting mode).
Page 224: Asking For Repair
Display Code Description and possible countermeasure Format error The description of the received command is incorrect. Example) The number of digits of numerical values is incorrect. EC，E06 Example) There are alphabet characters among the numerical values Check the transmitted command. Parameter setting error The value of the received command has exceeded the allowed EC，E07...
Page 225: Specifications
Dustproof and waterproof rating Compliant with IP65 (FZ-WP / FX-WP series only) The internal weight may change in mass due to the usage environment and deterioration over time. "mg (milligram)" can only be selected for 0.0001 g models. "DS (density mode)" can be enabled by changing the factory default setting in the function table of the balance.
Page 226: Individual Specifications
22.2. Individual specifications 22.2.1. 0.0001 g models FZ-104 FZ-154 FZ-254 FZ-254D Internal adjustment type FX-104 FX-154 FX-254 FX-254D External adjustment type 252 g 102 g 152 g 252 g Weighing capacity 62 g 252.008 g 102.0084 g 152.0084 g 252.0084 g Maximum display 62.0009 g 0.001 g...
Page 227: G Models
22.2.2. 0.001 g models FZ-123 FZ-223 FZ-323 FZ-523 Internal adjustment type FX-123 FX-223 FX-323 FX-523 External adjustment type Dustproof and waterproof, FZ-123WP FZ-223WP FZ-323WP internal adjustment type Dustproof and waterproof FX-123WP FX-223WP FX-323WP type 122 g 220 g 320 g 520 g Weighing capacity 122.084 g...
Page 228: G Models
22.2.3. 0.01 g models FZ-1202 FZ-2202 FZ-3202 FZ-5202 Internal adjustment type FX-1202 FX-2202 FX-3202 FX-5202 External adjustment type Dustproof and waterproof, FZ-1202WP FZ-2202WP FZ-3202WP internal adjustment type Dustproof and waterproof FX-1202WP FX-2202WP FX-3202WP type 1220 g 2200 g 3200 g 5200 g Weighing capacity 1220.84 g...
Page 229: External Dimensions
22.3. External dimensions FZ-104 / 154 / 254 / 254D FX-104 / 154 / 254 / 254D Unit: mm Area under the floor weighing platform...
Page 230 FZ-123 / 223 / 323 / 523 FZ-123WP / 223WP / 323WP FX-123 / 223 / 323 / 523 FX-123WP/ 223WP / 323WP Unit: mm *1: Width of the opening when a clear plate is removed. *2: Inside dimension *3: Weighing pan diameter *4: Height from the weighing pan up to the cap of the breeze break (inside dimension) *5: Height of the opening when a clear plate is removed.
Page 231: Options And Accessories
23.1.1. Options Caution Only one of FX-05, FXi-08, FXi-09, or GXA-27 can be installed. When used with FXi-08 or FXi-09, the FZ-WP / FX-WP series are not dustproof or waterproof compliant with IP65. FX-05: USB interface (Supported OS: Windows 7 or later)
Page 232 GXA-27: Bluetooth interface Enables the balance to communicate wirelessly with a paired Bluetooth-equipped terminal such as a PC / tablet / smartphone. An FZ-WP / FX-WP balance installed with a GXA-27 has the capability for communication without compromising its dustproof and waterproof performance (compliant with IP65).
Page 233 FXi-10: Small breeze break Can be attached to all models of the FZ / FX series and FZ-WP / FX-WP series except for 0.0001 g models. FXi-10 compatible models 123WP 223WP 323WP FZ / FZ-WP series 1202 1202WP 2202 2202WP...
Page 234 1202, 2202, 3202, 5202 1202WP, 2202WP, 3202WP FXi-15: Carrying case A carrying case that can store and carry any model of the FZ / FX series and FZ-WP / FX-WP series except for 0.0001 g models. FXi-15 compatible models 123WP 223WP...
Page 235: Accessories
23.1.2. Accessories AD-8127: Multi-functional compact printer Small dot impact printer that connects with an A&D balance via the RS-232C interface. Various functions such as clock and calendar function, statistical function, interval print function, graphic print function, etc. are provided. AD-1654: Density Determination Kit (for the FZ / FX series) Specific gravity (density) of solids and liquids can be easily measured.
Page 236 AD-1683A: Static eliminator (Ionizer) Prevents weighing errors caused by electrically charged weighing samples. This DC-type static eliminator generates ions that travel far with no breeze, which is ideal for precisely measuring powder and such. A non-contact switch is equipped so that you can perform static elimination only when necessary.
Page 237 AX-KO2737-500: Waterproof RS-232C cable (5 m, D-Sub 9-pin, female to female) Length: 5 m. D-Sub 9-pin (female) to 9-pin (female) Waterproof type Only the 9-pin on the balance side is waterproof. Device connected: PC, PLC, printer, etc. Waterproof RS-232 cable AX-USB-9P: Serial / USB converter with cable (Cable length: approx.
Page 238 AD-1687 Weighing environment logger AD-1687 is equipped with four sensors for temperature, humidity, barometric pressure, and vibration to measure and store environmental data. When connected to the RS-232C interface of a balance, the AD-1687 can store environmental data along with weighing data. Data can be saved even in environments where a PC cannot be used.
Page 239 AD-1672: Tabletop breeze break This tabletop breeze break protects the balance from breezes and drafts due to air conditioning and the like or body movements. The transparent panel assembly consists of antistatic plastic material which protects the balance from static electricity. AD-8529PC-W: Bluetooth®...
Page 240: Terms
24. Terms Term Description Stable display The weighing value when the stabilization indicator is displayed. Ambient conditions such as vibration, drafts, temperature change, static Environment electricity, magnetic fields, and the like that affect the weighing operation. Sensitivity adjustment Adjustment of the balance so that it can weigh accurately. A weighing reference point or the zero display.
Page 241 MEMO...
Page 242 MEMO...
Page 243 THIS PAGE INTENTIONALLY LEFT BLANK.
Page 244 Back cover: A&D Global A&D Company, Limited 3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013, JAPAN Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-1566 A&D ENGINEERING, INC. 47747 Warm Springs Blvd, Fremont, California 94539, U.S.A. Tel: [1] (800) 726-3364 Weighing Support:[1] (888) 726-5931 Inspection Support:[1] (855) 332- 8815 A&D INSTRUMENTS LIMITED...
