- Page 1 INSTALLATION + USER √ Instructions Thule Slide Out G2 12V 301838 - 301840, 301861 Bring your life SDD900-00 | 3380065400 thule.com 2020-12-14...
- Page 3 Trittstufen - Bedienungsanleitung STEP - USER INSTRUCTIONS Opstaptrede - Gebruikershandleiding Marchepieds - Instructions d'utilisation Gradini - Istruzioni per l'uso Safety Escalones - Manual de usuario Fotsteg - Användarmanual Astinlaudat - Käyttöohje Trapper - Brugermanual Trapper - Brukerhåndbok Stopnie - Instrukcja obslugi WARNINGS &...
- Page 4 1 WARNINGS & INFO Instructions Safety Instructions Safety STEP STEP SDD900-00...
- Page 5 2 CONTENT M8 x 90 mm M8 x 90 mm DIN 125 DIN 933 DIN 933 DIN 125 DIN 985 DIN 985 OPTIONAL OPTIONAL 2,9 x 9,5 mm 2,9 x 9,5 mm F4,8 x 0,8 mm F4,8 x 0,8 mm DIN 7981 - TX10 DIN 7981 - TX10 3 TOOLS...
-
Page 6: Installation
4 INSTALLATION MAX. 300 mm MAX. 400 mm EN 1645-1 EN 1646-1 420 mm 58 mm 258 mm 22 mm 10 mm 27 mm 57 mm 92 mm 127 mm 162 mm 231 mm 312 mm 332 mm SDD900-00... - Page 7 N° 13 Ø 9mm SDD900-00...
-
Page 8: Electrical Installation
5 ELECTRICAL INSTALLATION NIEUW 2020 G2 : ZWART / RED/ROT/ROOD/ ROUGE/ROSSO/ROJA/ black RÖD/PUNAINEN/RØD/ RØD/CZERWONY BLACK/SCHWARZ/ Sec. ZWART/NOIR/NERO/ NEGRO/SVART/ MUSTA/SORT/SVART/ CZARNY black Sec. OPTIONAL Ø 48mm TX10 RED/ROT/ROOD/ ROUGE/ROSSO/ROJA/ black RÖD/PUNAINEN/RØD/ RØD/CZERWONY Sec. BLACK/SCHWARZ/ ZWART/NOIR/NERO/ NEGRO/SVART/ MUSTA/SORT/SVART/ CZARNY black Sec. SDD900-00... - Page 9 THULE STEP with WARNING LAMP (or BUZZER) Dashboard START Key S3 START Step S2 grey Switch S1 brown black F 20A Battery 12V DC (main) BLACK/SCHWARZ/ GREY/GRAU/GRIJS/ ZWART/NOIR/NERO/ GRISE/GRIGIO/GRIS/ NEGRO/SVART/ GRÅ/HARMAA/GRÅ/ MUSTA/SORT/SVART/ GRÅ/SZARY CZARNY BROWN/BRAUN/ BRUIN/MARRON/ RED/ROT/ROOD/ MARRONE/MARÓN/ ROUGE/ROSSO/ROJA/ BRUN/RUSKEA/BRUN/ RÖD/PUNAINEN/RØD/...
- Page 10 THULE STEP with OPTIONAL RELAY (308200) for AUTOMATIC RETRACTION Dashboard START Key S3 START Capacity 2200µF Step S2 grey Relay brown Switch S1 black F 20A Battery 12V DC (main) BLACK/SCHWARZ/ GREY/GRAU/GRIJS/ ZWART/NOIR/NERO/ GRISE/GRIGIO/GRIS/ NEGRO/SVART/ GRÅ/HARMAA/GRÅ/ MUSTA/SORT/SVART/ GRÅ/SZARY CZARNY BROWN/BRAUN/...
- Page 11 Sec. Sec. STEP SDD900-00...
- Page 12 SDD900-00...
-
Page 13: Open & Close
6 OPEN & CLOSE SDD900-00... -
Page 14: Maintenance
7 MAINTENANCE SDD900-00... - Page 15 SDD900-00...
- Page 16 SDD900-00...
- Page 17 SDD900-00...
-
Page 18: Manual Release
8 MANUAL RELEASE SDD900-00... - Page 19 SDD900-00...
- Page 20 SDD900-00...
- Page 21 9 ACCESSORIES Electronic control unit (308812) Relay for Automatic retraction x10 (308200) SDD900-00...
- Page 22 SDD900-00...
- Page 23 SDD900-00...
- Page 24 Thule NV, Kortrijkstraat 343 – BE 8930 Menen, BELGIUM infoRV@thule.com www.thule.com SDD900-00 © Thule Group 2020. All rights reserved.
