Thule Slide Out V12 Maintenance Manual

Thule Slide Out V12 Maintenance Manual

Roadtrek
Hide thumbs

Advertisement

Quick Links

Download this manual
Maintenance guide for steps
Roadtrek
PE
20/07/2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the Slide Out V12 and is the answer not in the manual?

Questions and answers

Related Manuals for Thule Slide Out V12

Summary of Contents for Thule Slide Out V12

  • Page 1 Maintenance guide for steps Roadtrek 20/07/2017...
  • Page 2 Reconnect cables Change switch (*) – to measure on the closest connection points of the motor (**) - if the step is open  close step – manual release procedure Slide 2 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 3 (301447 OS IS SL O Duc 16 12V400 20pc) (301448 Step SLO 16 duc 16 12V700 NA/OP) Mounting kit for Ducato (301449 OS IS SLO Duc 16 12V700 20pc) (306682 OS IS Duc Slide Out V12 > 2007) Ducato version USP’s •...
  • Page 4 (301447 OS IS SL O Duc 16 12V400 20pc) (301448 Step SLO 16 duc 16 12V700 NA/OP) Mounting kit for Ducato (301449 OS IS SLO Duc 16 12V700 20pc) (306682 OS IS Duc Slide Out V12 > 2007) Ducato version USP’s •...
  • Page 5 (First follow manual release procedure to start cleaning)  When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Slide 5 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 6 (First follow manual release procedure to start cleaning)  When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Slide 6 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 7 Manual release / Cleaning – Slide Out V12 Start from an open Slide Out Slide 7 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 8 Manual release / Cleaning – Slide Out V12 Start from an open Slide Out Disconnect motor arms 10mm Slide 8 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 9 Manual release / Cleaning – Slide Out V12 Start from an open slide out Disconnect motor arms Remove stops Slide 9 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 10 Manual release / Cleaning – Slide Out V12 Start from an open slide out Disconnect motor arms Remove stops Remove the complete footboard Slide 10 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 11 Cleaning – Slide Out V12 Start from an open slide out Disconnect motor arms Remove stops Remove the complete footboard  Clean inside with:  Vacuum cleaner  Long brush Slide 11 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 12 When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Spare Part: 1500603111- Alarmswitch slide out V12 Slide 12 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 13 Switch change – Slide Out V12 Remove endcap and front profile – when mounted on the vehicle ! Slide 13 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 14 Switch change – Slide Out V12 Remove endcap and front profile Front Back Remove step from the vehicle 306682 OS IS Duc Slide Out V12 > 2007 10mm 309946 OS IS Duc Slide Out V15 > 2007 10mm 10mm Slide 14...
  • Page 15 Switch change – Slide Out V12 Remove endcap and front profile Remove step from the vehicle Release the switch screws  Not the motor screws! Slide 15 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 16 Switch change – Slide Out V12 Remove endcap and front profile  Cross screw driver Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate Slide 16 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 17 Switch change – Slide Out V12 Remove endcap and front profile  Cross screw driver Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate  Cross screw driver x 4 Remove botom plate...
  • Page 18 Switch change – Slide Out V12 Remove endcap and front profile  Cross screw driver Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate  Cross screw driver x 4 Remove botom plate...
  • Page 19 (301447 OS IS SL O Duc 16 12V400 20pc) (301448 Step SLO 16 duc 16 12V700 NA/OP) Mounting kit for Ducato (301449 OS IS SLO Duc 16 12V700 20pc) (306682 OS IS Duc Slide Out V12 > 2007) Ducato version USP’s •...
  • Page 20  When footboard is completely open, in case of power failure  Cleaning  When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Slide 20 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 21  When footboard is completely open, in case of power failure  Cleaning  When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Slide 21 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 22 Manual release – Slide Out V16 Remove manually motor arm clips Slide 22 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 23 Manual release – Slide Out V16 Remove manually motor arm clips Rotate the motor arms to the center of the step Slide 23 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 24 Manual release – Slide Out V16 Remove manually motor arm clips Rotate the motor arms to the center of the step Remove footboard clamp Slide 24 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 25 Manual release – Slide Out V16 Remove manually motor arm clips Rotate the motor arms to the center of the step Remove footboard clamp Close the step by pushing the footboard back in the case Slide 25 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 26 Rotate the motor arms to the center of the step Remove footboard clamp Close the step by pushing the footboard back in the case Use the footboard clamp to fix the footboard Slide 26 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 27  When footboard is completely open, in case of power failure  Cleaning  When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Slide 27 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 28 Cleaning – Slide Out V16 Open the slide out completely Slide 28 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 29 Cleaning – Slide Out V16 Open the slide out compleatly Remove manually motor arm clips Slide 29 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 30 Cleaning – Slide Out V16 Open the slide out compleatly Remove manually motor arm clips Rotate the motor arms to the center of the step Slide 30 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 31 Cleaning – Slide Out V16 Open the slide out completely Remove manually motor arm clips Rotate the motor arms to the center of the step Remove stops Slide 31 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 32 Cleaning – Slide Out V16 Open the slide out compleatly Remove manually motor arm clips Rotate the motor arms to the center of the step Remove stops Remove the complete footboard Slide 32 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 33 Remove manually motor arm clips Rotate the motor arms to the center of the step Remove stops Remove the complete footboard  Clean inside with:  Vacuum cleaner  Long brush Slide 33 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 34  When step is closed, to clean footboard + casement  Switch change  When step is mounted on the vehicle, in case of switch failure Spare Part: 1500603129 - Alarmswitch slide out V16 Slide 34 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 35 Switch change – Slide Out V16 Remove endcap and front profile Slide 35 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 36 Switch change – Slide Out V16 Remove endcap and front profile Remove step from the vehicle DIN7981C TX25 10mm Slide 36 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 37 Switch change – Slide Out V16 Remove endcap and front profile Remove step from the vehicle Release the switch screws  Not the motor screws! Slide 37 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 38 Switch change – Slide Out V16 Remove endcap and front profile Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate Slide 38 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 39 Switch change – Slide Out V16 Remove endcap and front profile Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate Remove botom plate Slide 39 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 40 Remove endcap and front profile Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate Remove botom plate Remove dust helmet from the switch 17mm Slide 40 20150202 Thule Group Presentation for Slide Out maintenance...
  • Page 41 Remove step from the vehicle Release the switch screws 2x  Not the motor screws! 6x Remove frontplate Remove botom plate Remove dust helmet from the switch Replace the connector switch Slide 41 20150202 Thule Group Presentation for Slide Out maintenance...

This manual is also suitable for:

Slide out v16
