Sioux Tools SAG03S Series Instructions-Parts List Manual

Sioux Tools SAG03S Series Instructions-Parts List Manual

Right angle die grinders
Hide thumbs Also See for SAG03S Series:
Table of Contents
  • Wartung
  • Bedienung
  • Mantenimiento
  • Operación
  • Manutenzione
  • Usage Prévu
  • Eu-Konformitätserklärung
  • Dichiarazione DI Conformità Eu
  • Eu-Verklaring Van Overeenstemming
  • Eu-Försäkran Om Överensstämmelse

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1
Read and understand these instructions before operating this tool.
Everyone using, maintaining, changing accessories or working near this tool must read, understand and follow these Safety Instructions!
Sioux power tools may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
Tools should be inspected regularly to verify that all original markings and labels are present and legible. Contact Sioux Tools to obtain
replacement labels when necessary
Die grinders can cause flying particles.
Proper eye protection must be worn at all times by tool user and bystanders.
Flying particles can cause eye injury.
Power tools generate noise.
Ear protection must be worn when tool noise level exceeds 85 dBA. We also recommend that ear protection be worn when the tool
noise level is below 85 dBA. See the tool's information sheet for the noise level. Appropriate controls to reduce the risk may include
actions such as damping materials to prevent work pieces from "ringing" . Always ensure that the muffler material is in the die
grinder. Support the weight of the tool in a stand or balancer whenever possible. Hold the tool with a light but secure grip. Always
hold tightly enough to counteract reaction forces but know that the risks due to vibration are greater when the grip force is higher.
Prolonged exposure to noise can cause hearing loss.
Using this tool can cause the operator to experience discomfort in the hands, arms, shoulders, neck, and other place.
In order to help prevent this, the operator should find a comfortable working positions that maintains secure grip and footing.
If the operator experiences pain, throbbing, aching, tingling, numbness, burning, or stiffness they should contact both the employer and
a physician.
Power tools vibrate.
Excessive vibration can cause injury. If numbness, tingling, pain or whitening of the skin occurs, stop using tool and consult a
physician. See the tool's information sheet for the vibration level.
Prolonged exposure to vibration can cause injury.
Rotating grinding wheels can cause cuts and abrasions.
Keep hands and other body parts away from grinding wheels to prevent cutting or pinching. Wear protective clothing and gloves to
protect hands. Operators and maintenance personnel should be physically able to handle the bulk, weight and power of the tool.
Contact with rotating grinding wheels can cause injury.
Die grinders present a risk of entanglement.
Keep loose hair away from power tools and accessories. Keep hands away from moving parts of the tool and accessories. Do
not wear jewelry, loose clothing, or neckwear around power tools. Keep work area clear of cleaning rags and all items that could
become entangled with the tool. When using the tool overhead, wear a helmet.
Entanglements can cause injuries.
Grinding operations creates dust.
Ensure that that sparks and debris do not create a hazard. Do not breathe grinding dust. Use approved mask. Risk assessment should
include the potential to disturb existing dust. Direct the exhaust so as to minimize disturbance of dust in a dust-filled environment.
Working with certain materials creates emission of dust and fumes which can cause a potentially explosive environment.
Breathing grinding dust can cause injury.
Slips, trips, and falls are major causes of workplace injury.
Be aware that the exhaust from this tool can cause slippery surfaces and the air hose can present a trip hazards.
Proceed with care in unfamiliar surroundings as there can be hidden hazards.
This tool is not insulated for contact with electric power sources.
Do not use near live electric circuits. When drilling into walls, be aware that they may have hidden electric wires.
Electric shock can cause injury.
This tool is not intended for use in a flammable or explosive atmosphere.
Do not use this tool in a flammable or explosive atmosphere.
Explosions and fire can cause injury.
Grinding metals creates sparks that can ignite flammable materials and vapors.
Only grind metals if the area is free of combustible or explosive materials or vapors.
Explosions and fire can cause injury.
Grinding wheels that malfunction or spin off can cause injury.
Overspeeding wheels can explode.
Check the speed of the tool regularly with a tachometer. These checks should be done without any mounted accessories. If the
tachometer reads faster than the rated speed of the tool, discontinue use. Check the speed rating of the accessory or the speed
printed on the wheel. This speed must be greater than the nameplate speed of the grinder and the actual speed of the grinder as
measured with a tachometer. Do not exceed rated operating air pressure.
Exploding wheels can cause injury or death.
250 Snap-on Drive • Murphy, NC 28906 • USA • Phone: 828-835-9765 •www.siouxtools.com
Form ZCE860D
INSTRUCTIONS & PARTS LIST FOR
SAG03S & SAG03X SERIES RIGHT ANGLE DIE GRINDERS
SAVE THESE INSTRUCTIONS!
When used improperly power tools can create hazardous situations.
Improperly used power tools can cause injury or death.
DIE GRINDER SAFETY
Original
Instructions
SERIAL "E"
WARNING
1
Form ZCE860D
Date 2022May20/A
Page 1 of 28
Date 2022May20/A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAG03S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sioux Tools SAG03S Series

  • Page 1 Sioux power tools may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Tools should be inspected regularly to verify that all original markings and labels are present and legible. Contact Sioux Tools to obtain replacement labels when necessary Die grinders can cause flying particles.
  • Page 2 Excessive overhang reduces the safe operating speed of mounted wheels, causes wheels to “whip”, and shafts to bend. When using die grinders, keep overhang to a minimum. Refer to enclosed “SAFETY GUIDE FOR SIOUX ABRASIVE WHEEL” for speed and overhang information. “Whipping”...
  • Page 3: Maintenance

    Whenever universal twist couplings (claw couplings) are used, lock pins shall be installed and whip check safety cables shall be used to help prevent possible hose-to-tool and hose-to-hose failure. The use of any accessory with this tool not provided or specified by Sioux Tools can perform unpredictably. Use only accessories provided or specified by Sioux Tools.
  • Page 4 Übersetzung Der Original Anleitungen BEDIENUNGSANLEITUNG UND TEILELISTE FÜR RECHTWINKLIGE SCHNEIDEISEN-SCHLEIFMASCHINEN DER SAG03S & SAG03X-SERIE SERIE “E” Lesen Sie diese Bedienungsanleitung, bevor Sie dieses Werkzeug in Betrieb nehmen. BEWAHREN SIE DIESE ANLEITUNG AUF! WARNUNG Unsachgemäßer Gebrauch von Werkzeugen kann zu gefährlichen Situationen führen. Jede Person, die dieses Werkzeug gebraucht, wartet, Zubehör auswechselt oder in der Nähe dieses Werkzeugs arbeitet, muss diese Sicherheitshinweise lesen, verstanden haben und befolgen! Unsachgemäßer Gebrauch von Werkzeugen kann zu Verletzungen oder zum Tod führen.
  • Page 5 Überdrehende Scheiben können explodieren. Die Drehzahl des Werkzeugs regelmäßig mit einem Drehzahlmesser überprüfen. Diese Kontrollen sollten ohne montierte Zubehörteile erfolgen. Wenn die Messwerte des Drehzahlmessers über der Nenndrehzahl des Werkzeugs liegen, das Werkzeug nicht weiterverwenden. Überprüfen Sie die Geschwindigkeitsleistung des Zubehörs oder die Geschwindigkeit, die auf der Scheibe angegeben ist.
  • Page 6: Wartung

    Bei Verwendung von Klauenkupplungen sind Sperrstifte anzubringen und Schlauchtrennsicherungen zu verwenden, um gegen mögliche Schlauch-Werkzeug- und Schlauch-Schlauch-Anschlussfehler zu schützen. Der Gebrauch von Zubehör, das nicht von Sioux Tools geliefert oder spezifiziert wurde, kann zu unvorhersehbaren Zwischenfällen führen. Verwenden Sie ausschließlich von Sioux Tools geliefertes oder empfohlenes Zubehör.
  • Page 7 Traducción De Las Instrucciones Originales INSTRUCCIONES Y LISTA DE PIEZAS PARA LAS RECTIFICADORAS DE MATRIZ EN ÁNGULO RECTO DE LA SERIE SAG03S & SAG03X SERIE “E” Lea y entienda estas instrucciones antes de usar esta herramienta. ¡NO PIERDA ESTAS INSTRUCCIONES! ADVERTENCIA Una herramienta motorizada puede ser peligrosa si no se usa correctamente.
  • Page 8 Las muelas con una velocidad muy alta pueden explotar. Verifique la velocidad regularmente con un tacómetro. Esto debe hacerse sin ningún accesorio puesto. Deje de usar la herramienta si el tacómetro indica una velocidad superior a la nominal. Verifique el régimen de velocidad del accesorio o la velocidad impresa en la muela.
  • Page 9: Mantenimiento

    Si se utilizan acoplamientos de torsión (acoplamientos de garras), también deberán instalarse pasadores y un cable de sujeción como protección en caso de que la manguera se suelte de la herramienta o de otra manguera. El uso de cualquier accesorio con esta herramienta que no sea proporcionado o especificado por Sioux Tools puede tener un rendimiento impredecible.
  • Page 10 Traduzione Delle Istruzioni Originali ISTRUZIONI E LISTINO PARTI PER MOLATRICI/LEVIGATRICI ANGOLARI SERIE SAG03S & SAG03X SERIALE “E” Leggere attentamente queste istruzioni prima di usare l'attrezzo. CONSERVARE QUESTE ISTRUZIONI! AVVERTIMENTO Utensili a motore non usati correttamente possono creare condizioni di rischio.. Chiunque usi, mantenga, sostituisca accessori o lavori vicino a quest’utensile deve leggere attentamente e seguire queste istruzioni di sicurezza! L’uso diverso dal previsto di questi utensili a motore può...
  • Page 11 Le mole portate a velocità eccessiva possono esplodere. Controllare frequentemente la velocità dell'utensile con un contagiri. Se il contagiri dovesse indicare una velocità di rotazione più elevata di quella omologata, sospendere l'utilizzo dell'utensile. Controllare la velocità nominale dell’accessorio o la velocità stampata sulla mola.
  • Page 12: Manutenzione

    L’utilizzo, con questo strumento, di accessori non forniti o specificati da Sioux Tools può portare a risultati imprevedibili. Utilizzare solo accessori forniti o specificati da Sioux Tools.
  • Page 13 Traduction Des Instructions Originales INSTRUCTIONS & LISTE DE PIÈCES POUR MEULEUSES D’OUTILLAGE À RENVOI D’ANGLE DROIT DE SÉRIE SAG03S & SAG03X SÉRIE “E” Veuillez lire et comprendre ces instructions avant d'utiliser cet outil. CONSERVEZ CES INSTRUCTIONS ! AVERTISSEMENT Une utilisation incorrecte d’outils électriques risque d’engendrer des situations dangereuses. Toute personne susceptible d’utiliser, d’entretenir, de remplacer des accessoires ou de travailler à...
  • Page 14 Ne pas modifier cet outil. Les modifications peuvent réduire l’efficacité ou les mesures de sécurité et augmenter les risques encourus par l’opérateur. Ne pas utiliser si l’outil a été endommagé. Les réparations doivent être effectuées dans un centre Sioux Tools agréé.
  • Page 15: Usage Prévu

    être utilisés pour empêcher un effet de fouet si un des raccords se brise. L’utilisation d’accessoires non fournis ou recommandés par Sioux Tools peut entraîner un fonctionnement irrégulier. N’utiliser que les accessoires fournis ou recommandés par Sioux Tools.
  • Page 16 Vertaling Van De Oorspronkelijke Instructies INSTRUCTIES EN ONDERDELENLIJST VOOR HAAKSE SLIJPMACHINES (SERIE SAG03S & SAG03X) SERIE “E” Zorg dat u deze instructies hebt gelezen en begrepen voordat u dit gereedschap gebruikt. BEWAAR DEZE INSTRUCTIES! WAARSCHUWING Bij verkeerd gebruik kunnen elektrische werktuigen gevaarlijke situaties teweegbrengen. Iedereen die accessoires gebruikt, onderhoudt of vervangt of nabij dit werktuig werkt, moet deze veiligheidsinstructies hebben gelezen, begrepen en volgen! Verkeerd gebruikte elektrische werktuigen kunnen letsel of de dood veroorzak.
  • Page 17 Te snel draaiende schijven kunnen exploderen. Controleer het toerental van het gereedschap regelmatig met een toerenteller. Deze controles moeten worden uitgevoerd zonder dat accessoires zijn gemonteerd. Als het gemeten toerental hoger is dan het nominaal toerental van het gereedschap, mag het niet meer worden gebruikt.
  • Page 18 Het gebruik van een niet door Sioux Tools geleverd of gespecificeerd onderdeel of accessoire kan onverwachte gevolgen hebben. Gebruik alleen door Sioux Tools geleverde of gespecificeerde onderdelen en accessoires.
  • Page 19 Översätt Från Original Instruktionerna ANVISNINGAR OCH RESERVDELSLISTA FÖR SAG03S & SAG03X-SERIEN” HÖGERVINKLADE TURBINSLIPAR SERIE “E” Läs och förstå dessa anvisningar innan du använder detta verktyg. SPARA DESSA ANVISNINGAR! VARNING Felaktig användning av motordrivna verktyg kan förorsaka risksituationer. Alla som använder, underhåller, byter tillbehör på eller arbetar nära detta verktyg måste läsa, sätta sig in i och följa dessa säkerhetsanvisningar! Felaktig användning av motordrivna verktyg kan förorsaka personskada eller dödsfall..
  • Page 20 För stor överskjutning på monterade skivor gör att säker driftshastighet blir lägre, skivorna “piskar” och axlar böjs. Vid användning av turbinslipmaskiner skall överskjutningen hållas så liten som möjligt. Den medföljande säkerhetshandledningen för Sioux-slipskivor innehåller information om rotationshastighet och överhäng. “Piskande” skivor och böjda axlar kan förorsaka kroppsskada. Formslipmaskiner kan ge upphov till oförutsedda rörelser.
  • Page 21 När universal twist-kopplingar (klokopplingar) används, ska låsstift vara installerade och man ska använda säkerhetskablar som förhindrar piskskador vid slangbrott slang-till-verktyg och slang-till-slang. Om du använder tillbehör med detta verktyg som ej tillhandahålls eller specificeras av Sioux Tools kan dessa fungera oberäkneligt. Använd endast tillbehör som tillhandahålls eller specificeras av Sioux Tools.
  • Page 22 PARTS LIST FOR SAG03S SERIES ANGLE DIE GRINDERS SERIAL “E” *Order Quantity As Required FURNISH CATALOG, SERIAL, AND MODEL NUMBER WHEN ORDERING PARTS 11 12 Assembly Requirements Fig. Torque / Specification Threadlocker SPECIAL NOTES BEVEL FACING NONE NONE OUTWARD 60-100 IN-LB...
  • Page 23 PARTS LIST FOR SAG03X SERIES ANGLE DIE GRINDERS SERIAL “E” *Order Quantity As Required FURNISH CATALOG, SERIAL, AND MODEL NUMBER WHEN ORDERING PARTS 25 26 Assembly Requirements Fig. Torque / Specification Threadlocker SPECIAL NOTES BEVEL FACING NONE NONE OUTWARD 60-100 IN-LB LOCTITE 277 PINION ONLY 40-50 FT-LB...
  • Page 24 NOTES Form ZCE860D Date 2022May20/A...
  • Page 25: Eu-Konformitätserklärung

    UK DECLARATION OF CONFORMITY EU DECLARATION OF CONFORMITY EU-KONFORMITÄTSERKLÄRUNG This declaration of conformity is issued under the sole Diese Konformitätserklärung wird unter der alleinigen This declaration of conformity is issued under the sole responsibility of the manufacturer: Verantwortung des Herstellers herausgegeben: responsibility of the manufacturer: Snap-on Tools Company Snap-on Tools Company...
  • Page 26: Dichiarazione Di Conformità Eu

    DECLARACIÓN DE CONFORMIDAD DE LA UE DICHIARAZIONE DI CONFORMITÀ EU DÉCLARATION DE CONFORMITÉ POUR L’UNION EUROPÉENNE Esta declaración de conformidad se emite bajo la La presente dichiarazione di conformità è stata responsabilidad exclusiva del fabricante: rilasciata ad esclusiva responsabilità del produttore: Cette déclaration de conformité...
  • Page 27: Eu-Verklaring Van Overeenstemming

    EU-VERKLARING VAN OVEREENSTEMMING EU-FÖRSÄKRAN OM ÖVERENSSTÄMMELSE Voor de afgifte van deze verklaring van Denna försäkran om överensstämmelse utfärdas på overeenstemming is uitsluitend de fabrikant tillverkarens eget ansvar: verantwoordelijk: Snap-on Tools Company Snap-on Tools Company 2801 80th Street 2801 80th Street Kenosha, WI 53141-1410, U.S.A.
  • Page 28 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. WARNUNG Der durch Elektrosanden, -sägen, -schleifen und -bohren sowie durch andere Bauarbeiten anfallende Staub enthält Chemikalien, die nachweislich Krebs sowie Geburts- bzw.
  • Page 29 This pdf incorporates the following model numbers: SAG03S12, SAG03S20, SAG03X12, SAG03X20...
