Front Panel Components

Drive configuration may vary by model.
Table 1-1 Front Panel Components
1 Microphone Connector
2 Headphone Connector
3 USB (Universal Serial Bus) Ports
4 Hard Drive Activity Light
5 Power On Light
NOTE
1 Some models are configured with a diskette drive in the external 3.5-inch drive bay. Other models have a bezel blank
covering this bay.
2 Some models are configured with a bezel blank covering this bay.
2 Chapter 1 Product Features
An optical drive is a CD-ROM, CD-R/RW, DVD-ROM , DVD+R/RW, or CD-RW/DVD Combo drive.
6 Dual-State Power Button
7 3.5-inch Media Card Reader (optional)
8 Optical Drive Activity Light
9 5.25-inch Optical Drive
10 Optical Drive Eject Button
1
2
