Winix 5500-2 User Manual

MODEL PART DIAGRAM
FRONT
Control Panel
Front Panel
PACKAGE CONTENTS
(1) Pre-Filter
Unit
(1) Washable
(1) True HEPA Filter
WHERE TO USE
Allow 12 ~ 18 in. of space between TVs, radios, and other
electronics
Electromagnetic interference from certain electronics may
cause product malfunction.
Place indoors away from direct sunlight
Direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
12~18 in 12~18 in
Flimsy or slanted surfaces may result in abnormal noise and
12~18 in 12~18 in
vibrations.
Allow at least 12 ~ 18 in. from walls for maximum air flow
4-STAGE AIR PURIFICATION
01 Pre-Filter 02 Washable AOC™ Carbon Filter
REMOTE CONTROL
Operates in a 20 foot radius:
• (A) Power: Turns the unit on
A
or off.
• (B) Auto: Enables Auto Mode.
D B
• (C) Fan Speed: Enables
manual operation of the fan
speeds.
C
• (D) Turbo: Enters Manual
Mode and directly sets the
fan speed to Turbo.
How to replace your remote's battery:
1. Flip over your remote and
open battery tray.
1.A • 1.A : Pinch the lever in
while,
1.B
• 1.B : Pulling the battery
tray out.
2.A
2. Insert battery into the
battery tray as shown.
• 2.A : Make sure the
polarities [+] [-] match
3.A
when placing in the tray.
3. Close the battery tray.
• 3.A : Reinsert battery
tray into remote until
you hear a "click" sound.
Keep all used batteries (CR2025) in safe place.
INITIAL OPERATION
1. Remove the front panel by grasping its upper
edge and gently pulling forward.
2. Remove the Pre-Filter, then the plastic bag
of filters behind it.
3. Remove filters from protective plastic bag.
4. Install the filters until they fit securely in
place.
03. True HEPA Filter (back)
02. Washable AOC™ Carbon Filter (middle)
01. Pre-Filter (front)
5. After filters are installed, close the front
panel.
6. Insert the power cord into an electrical
outlet.
BACK
Remote
AOC™ Carbon Filter
Control
Remote Control and User Manual will be
located on the top insert after the box is opened.
Air Purification means it
removes inanimate particles
03 True HEPA Filter
W A R N I N G
• Incorrect battery usage may cause battery
fluid leakage and/or damage.
• When not using remote for extended periods
of time, remove the battery.
• Avoid dropping or damaging the remote.
• WARNING: Chemical Burn Hazard. Keep
batteries away from children.
• This product contains a lithium button/coin
cell battery. If a new or used lithium button/
coin cell battery is swallowed or enters the
body, it can cause severe internal burns and
can lead to death in as little as 2 hours.
• Always completely secure the battery
compartment.
• If the battery compartment does not close
securely, stop using the product, remove the
batteries, and keep it away from children.
• If you think batteries might have been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• The batteries should be disposed of
properly, including keeping them away from
children. Even used batteries may cause
injury.
Latch
03
02
01
Latch
CONTROL PANEL
Handle
Air Outlet
Vent
09
01. Auto Indicator
Indicates whether Auto Mode is enabled or
disabled.
Power Plug
02. Sleep Indicator
Indicates whether Sleep Mode is enabled or
disabled.
User
03. PlasmaWave
Manual
Indicates whether PlasmaWave
disabled.
04. Fan Speed Indicator
Indicates the current fan speed.
05. Timer Indicator
If timer has been set, the LED light indicates the
set time of operation.
06. Filter Replacement Indicator
LED light indicates when it is time to change the
filter.
07. Light Sensor
Detects the amount of ambient light in the
environment.
08. Smart Sensor
Detects the amount of odorous gas in the
environment. When in Auto mode, the fan speed
adjusts according to the detected amount of gas.
09. Power Button
Turns the unit on or off.
During the first 30 seconds of powering up, the
Air Quality Indicator will cycle through Blue,
Amber and Red colors. Smart Sensor takes
approximately 4minutes to detect the air quality in
the environment before normal operation begins.
10. Mode Button
Press to cycle through to set the mode of operation
(Auto, Sleep). The unit will default to Auto with
04 PlasmaWave
®
®
PlasmaWave enabled when first powered on.
MAINTENANCE
When to Replace Filters
Filter
Pre-Filter
Washable AOC™ Carbon Filter
True HEPA Filter
• When the Check Filter Indicator LED is on, it is time to replace the True HEPA Filter and Washable
AOC™ Carbon Filter.
• Intervals between filter replacement may vary depending on environment.
* Filter performance may decrease after each wash and depending on contamination level prior to washing.
REPLACING FILTERS
CLEANING CARE
Cleaning the Filters:
Use a vacuum cleaner or soft brush to clean the
Pre-Filter
• If it is excessively soiled, rinse in room
temperature water.
• Do not use detergent or soap.
• Allow the filter to dry for 24 hours or more before
using.
• Intervals between filter cleaning may vary
depending on the air quality in the environment.
To clean the Washable AOC™ Carbon Filter, remove
from unit and rinse under lightly running room
temperature water.
• Do not use detergent or soap. Allow the filter to
dry for 24 hours or mote before using. Do not use
hot water over 104°F.
N O T I C E
• When cleaning the unit, always unplug the
power cord first and then wait until the unit
has cooled down.
03
01 02 04
12
10 11 13
• Auto Mode:
- Auto Mode automatically adjusts fan speeds
• Sleep Mode:
®
Indicator - Fan speed will automatically set to minimum
® is enabled or
- When Sleep Mode is active, PlasmaWave
11. PlasmaWave
Enables or disables PlasmaWave
"When the unit is running, you may hear a chirping
or buzzing sound. The sound is from large
particles passing through PlasmaWave
normal and does not signify product failure."
Press the PlasmaWave
to enable or disable this feature.
12. Air Quality Indicator
Color coded LED light indicates one of three levels
of Air Quality: Red (poor), Amber (fair), and Blue
(good).
13. Fan Speed Button
Enables manual operation of the unit's fan speeds.
• Press to cycle through and set the desired fan
speed (Low, Medium, High, Turbo).
14. Timer Button
Press to cycle through and set desired length of
operation (1hr, 4hr, 8hr, [NO TIMER]).
15. Filter Reset Button
After replacing the filter, turn on the unit and then
use a thin object, such as a paper clip, to press the
Filter Reset Button for 5 seconds.
Indicator Light When to Service
none Clean once every 14 days
* Clean once every 3 months
Can NOT be WASHED
Resetting Filter Life:
After replacing your True HEPA Filter, place the Pre-Filter
back in and close the Front Panel. While the unit is on, hold
the Filter Reset Button for at least 5 seconds until you hear
the beep. After the beep, the Filter Replacement Indicator
will disappear. Your Winix True HEPA is now reset.
Cleaning the Exterior & Interior:
1. Open the front panel and clean the interior
2.
3. Wipe the unit down with a clean, dry cloth.
* For optimal performance, clean every 1 - 2 months.
• Never disassemble, repair, or modify the unit yourself.
• Do not use flammable sprays or liquid detergents.
• Do not allow children to clean or maintain the unit.
• Before cleaning or maintaining, ensure unit is
unplugged.
05 06 07
08
14 15
according to your indoor air quality. The fan
speed will adjust to low when air quality is
good, medium when fair, and to high when
poor.
speed (lower than 'Low') which will be nearly
silent.
will be disabled, but it can be turned back on.
® Button
®
.
® , it is
® button when the unit is on
When to Replace
Permanent
Last Approx. 12 months
with a vacuum cleaner.
• A hand vacuum or hose attachment will work
best.
Dampen a cloth with room temperature water and
wipe down the interior and exterior of the unit.
• Ensure no moisture remains before plugging
the unit back in.
®
