W P
HITE APER
(cont' d)
. .
.25 - .27 mm variable aperture grille pitch
. .
Offers 85Hz refresh rates at resolutions up to 1600 x 1200.
. .
. .
TCO 95 certified
. .
Plug and Play and Microsoft PC97 Compliant
. .
. .
. .
The Compaq P1610 monitor
. .
16:10 aspect ratio
. .
. .
24" screen (22.5" viewable image size)
. .
Delivers maximum image area to increase productivity for intensive applications like
. .
CAD/CAM, 3D design, prepress, animation, and financial modeling.
. .
. .
Trinitron Technology
. .
.25 - .28 mm variable aperture grille pitch
. .
. .
Supports 1920 x 1200 resolution at a refresh rate of 76 Hz.
. .
Expert user controls - Allows high-end users to control advanced geometry and color
. .
adjustments, so they can get the best performance from their monitors.
. .
. .
Plug and Play and Microsoft PC97 Compliant
. .
TCO 95 certified
. .
. .
. .
The Compaq TFT500 Flat Panel Monitor provides an unprecedented combination of size and
. .
performance for the flat panel revolution.
. .
. .
15.1" (38.3 cm) viewable Active Matrix Display
. .
Wide viewing angle: 120 degrees horizontal and 80 degrees vertical
. .
. .
1024 x 768 resolution
. .
USB Hub with 3 downstream ports for connecting USB peripherals
. .
. .
TCO-95 compliant
. .
low power requirements (<40 watts)
. .
. .
Light weight (20 lbs.)
. .
detachable base
. .
. .
Optional Desk Arm Mount
. .
Wall mountable.
. .
. .
. .
The Compaq TFT450
. .
Space-Saving and Lightweight Weighs 13.5 pounds (with base) with a 2.8" thick panel.
. .
. .
Thin Film Transistor ( TFT) active matrix screen.
. .
Brightness of 185 nits offers a brighter picture than a standard CRT monitor.
. .
. . Wide Angle Viewing
. .
Arm Mount: frees up to 100% of desk space while increasing mobility. Wall Mount:
. .
hangs on a wall like a painting. Standard Mount: offers small footprint and
. .
. . compatibility with Compaq's Multimedia Sound System.
. .
DisplayAssistant
. .
TCO 92 Compliant
. .
. .
AssetControl
. .
Fault Management
. .
Plug and Play and Microsoft PC97 certified
. .
. .
. .
. .
16X M
A X I M U M
. .
. .
The Compaq Professional Workstation 6000, models 266 MHz and 300 MHz include a 5.25",
. .
. .
half-height auto-slot load 16X Maximum CD-ROM Drive using the new Constant Angular
. .
Velocity (CAV) technology. Previous CD-ROMs included a tray or caddy to hold the CD. This
. .
. .
CD-ROM uses a slot-load mechanism, similar to car stereos, where the CD slides directly into
. .
the slot in the CD-ROM drive. Additionally, previous CD-ROM technology used Constant
. .
. . Linear Velocity (CLV) technology which allowed the disc to rotate at a faster rate while reading
. .
the inner tracks and a slower rate when reading the outer tracks. Conversely, the CAV
. .
technology, used in the new products, spins the disc at a fixed rate and the data transfer rate
. .
. .
increases as it moves toward the outer tracks. This is the same technology that is used for hard
. .
IDE CD-ROM
- 15 -
