Using the Broadcom NetXtreme™
Gigabit Ethernet Plus Network Controller
November 2, 2009
Table of Contents:
Introduction ........................................................................................................ 2
DASH Overview .................................................................................................. 2
A New Management Standard ........................................................................ 3
Key Features ................................................................................................... 3
Management Profiles ...................................................................................... 3
Enabling DASH Support ....................................................................................... 7
Supported Platforms ........................................................................................ 7
System BIOS ........................................................................................... 8
Software Drivers ..................................................................................... 8
Deploying Software Updates ................................................................... 8
System BIOS Enablement ................................................................................. 9
Setting the BIOS Administrator Password ................................................. 9
Setting the Primary Management Controller ............................................. 9
Setting the Management Mode .............................................................. 10
Management Controller Enablement .............................................................. 10
Enabling the Administrator account ....................................................... 10
Using Active Directory ........................................................................... 11
Activating DASH Functionality ............................................................... 11
Using DASH Functions ....................................................................................... 11
HP Client Management Web View ..................................................................... 13
Connecting to the HP Client Management Web View ...................................... 14
Troubleshooting ................................................................................................ 16
Upgrading Management Software ................................................................. 16
PCIe Add-in Card Issues ................................................................................ 16
Power-On Password ..................................................................................... 16
Advertisement
Table of Contents
Related Manuals for Compaq 6005 - Pro Microtower PC
Summary of Contents for Compaq 6005 - Pro Microtower PC
-
Page 1: Table Of Contents
Using the Broadcom NetXtreme™ Gigabit Ethernet Plus Network Controller November 2, 2009 Table of Contents: Introduction ......................2 DASH Overview ....................2 A New Management Standard ................ 3 Key Features ....................3 Management Profiles ..................3 Enabling DASH Support ..................7 Supported Platforms .................. -
Page 2: Introduction
Feature List ....................17 USB Cable and Headers ................18 Appendix B: Enabling Management Functionality with Computer Setup ....19 HP Compaq dc5850 Business PC ..............19 HP Compaq dc7900 Business PC ..............21 HP Z800 Workstation ..................22 Appendix C: Enabling Management Functionality with BMCC and BACS ..... 23 DASH Enablement .................. -
Page 3: A New Management Standard
A New Management Standard Development of the DASH specifications is based on a history of preceding technologies and specifications. DASH has been designed to solve many of the pitfalls and constraints of previous management standards by leveraging well- proven technologies from the Service Oriented Architecture domain, advancements in security standards, and extensive modeling of management components, configuration data and relationships first introduced in the server management domain. - Page 4 Functionality DASH 1.0 DASH 1.1 WS-Management -- CIM Binding Specification 1.0.0 Required Required WS-CIM Mapping Specification 1.0.0 Required Required Profile Registration Profile 1.0.0 Required Required Role Based Authorization Profile 1.0.0 Required Required Simple Identity Management Profile 1.0.0 Required Required Boot Control Profile 1.0.0 Optional Optional CPU Profile 1.0.0...
- Page 5 HP and Broadcom have provided multiple software releases of the DASH components to assist in enabling the community. We are committed to the continued development of new manageability enablement functionality as profiles mature within the DMTF. Software and firmware updates are routinely released and can be downloaded from www.hp.com/#support.
- Page 6 TruManage™ Version Functionality System Memory Profile 1.0.0 1.0.0 1.0.0 Battery Profile BIOS Management Profile 1.0.0 1.0.0 1.0.0 DHCP Client Profile DNS Client Profile Ethernet Port Profile 1.0.0 1.0.0 1.0.0 Host LAN Network Port Profile IP Interface Profile KVM Redirection Profile Media Redirection Profile Opaque Management Data Profile 1.0.0...
-
Page 7: Enabling Dash Support
The Broadcom NetXtreme™ Gigabit Ethernet Plus is the default network controller option for the following platforms: HP Compaq 6005 Pro Business PC Although the Broadcom NetXtreme™ Gigabit Ethernet Plus discrete PCI Express add-in card is available as an option for HP business class desktops and... -
Page 8: System Bios
HP Z400 Workstation 786G3 1.14 The HP Compaq dc5800 Business PC does not support DASH functionality. However, the Broadcom NetXtreme™ Gigabit Ethernet Plus controller will perform as an ASF management device in the platform. A BIOS update may be required to enable this support. -
Page 9: System Bios Enablement
HP System Software Manager Information on how to use HP System Software Manager to deploy software updates can be found at: http://www.hp.com/go/ssm/ System BIOS Enablement In order to use DASH as our management protocol, we need to ensure that the system BIOS is prepared to communicate system management and health data with the Broadcom NetXtreme™... -
Page 10: Setting The Management Mode
system, we must inform the system BIOS which device will act as the primary management controller. Only one network controller can act as the management interface for the platform. This allows the system BIOS to communicate system information and health status directly with the device. Using Windows®... -
Page 11: Using Active Directory
WMIconfig.jse –remote:remotePC –user:Administrator –password:<password> account "?Name='Administrator'" .password=NewPassword .enabledstate=2 Using Active Directory The DASH management device may be configured to use a Microsoft Active Directory infrastructure for authentication purposes. This alleviates the burden of managing passwords on each individual DASH device directly. To setup third-party authentication using Active Directory we need to enable support and set the Active Directory password. - Page 12 Symantec Real-Time Systems Manager out-of-band device discovery Most consoles integrate DASH functionality into the routine operations you already perform. Once your management console has discovered the DASH capability of your computer systems, operations such as scheduled remote patch management will use DASH technology to remotely boot or wake the systems using DASH, perform the desired operation and reset the systems to their previous power state.
-
Page 13: Hp Client Management Web View
HP Client Automation Standard device management with DASH HP Client Management Web View In addition to managing the DASH-enabled PC through a management console, HP provides a convenient method to access out-of-band management functions through a web browser. The HP Client management Web View is a web browser-based interface for limited remote system management. -
Page 14: Connecting To The Hp Client Management Web View
Connecting to the HP Client Management Web View The following steps outline connecting to the out-of-band management service from the embedded web server included on the Broadcom NetXtreme™ Ethernet Gigabit Plus controller. This interface provides an alternative control mechanism for utilizing the DASH functionality without requiring a DASH enabled management console. - Page 15 Logon screen Enter the user name and password to use for authentication. If you have not created any additional accounts, you can connect with either of the predefined accounts of “Administrator” or “Operator”. Once your access has been authenticated, you will have access to a management portal similar to the figure below: Web management portal...
-
Page 16: Troubleshooting
Troubleshooting Upgrading Management Software The installation of management agent is required to support various DASH functions, such as gracefully shutting down the system, and is installed on factory system image. When building a custom image, management agent and CIM options can be selected during Broadcom Advance Control Suite (BACS) installation. -
Page 17: Appendix A: Broadcom Netxtreme™ Gigabit Ethernet Plus Network Controller
Appendix A: Broadcom NetXtreme™ Gigabit Ethernet Plus Network Controller The Broadcom NetXtreme™ Gigabit Ethernet Plus is the successor to the Broadcom NetXtreme™ Gigabit Ethernet network adapter. In addition to the standard network adapter functionality, the Broadcom NetXtreme™ Gigabit Ethernet Plus also features DASH support. -
Page 18: Usb Cable And Headers
Wake-on-LAN (WOL) support meeting the ACPI requirements Statistics for SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (802.3z, Clause System Management Bus (SMBus) interface supporting Desktop and mobile Architecture for System Hardware (DASH) v1.1 or Alert Standard Format (ASF) v2.0 Centralized Power Management Unit (CPMU) ... -
Page 19: Appendix B: Enabling Management Functionality With Computer Setup
The current management mode (ASF, AMT, or DASH) can be identified via Computer Setup > File > System Information. HP Compaq dc5850 Business PC By default, the embedded Broadcom Ethernet controller is primary management controller. The Broadcom NetXtreme™ Gigabit Ethernet Plus must be changed to... - Page 20 Management devices in the HP Compaq dc5850 Business PC Once the Broadcom NetXtreme™ Gigabit Ethernet Plus is made the primary management controller and the system is rebooted, the Management Mode will change to DASH. Management Mode (DASH highlighted) in the HP Compaq dc5850 Business PC...
-
Page 21: Hp Compaq Dc7900 Business Pc
DASH to be enabled. Management controller in the HP Compaq dc7900 Business PC The HP Compaq dc7900 Business PC is an Intel Q45-based system which has an integrated management controller (often referred to as the Management Engine or ME) within the chipset for management control. -
Page 22: Hp Z800 Workstation
Management Mode (DASH highlighted) in the HP Compaq dc7900 Business PC The following chart shows the correlation between the management controller and management mode for the HP Compaq dc7900. Correlation between management controller and management modes Primary Management Controller Management Modes Supported Intel®... -
Page 23: Appendix C: Enabling Management Functionality With Bmcc And Bacs
Management controller in the HP Z800 Workstation Appendix C: Enabling Management Functionality with BMCC and BACS Manageability features such as DASH and ASF are disabled by default on the Broadcom NetXtreme™ Gigabit Ethernet Plus network adapter. This section provides information on additional configuration tools available for setting up DASH functionality on the Broadcom NetXtreme™... - Page 24 Download the Broadcom NetXtreme™ Gigabit Drivers for Multiple Operating Systems Softpaq from www.hp.com. Install the Softpaq. Open a Command Prompt as Administrator. Go to the directory where the Broadcom application is installed. Execute the command: bmcc enable. The following steps will enable DASH with BACS: Execute BACS.
-
Page 25: Setting The Initial Administrator Account
Enable DASH and click the Apply button. Enabling DASH Setting the Initial Administrator Account Setting up an Administrator account for DASH requires the use of the Broadcom NetXtreme™ Gigabit Drivers for Multiple Operating Systems Softpaq. This is available at www.hp.com. Execute the Softpaq, and then open a Command Prompt as Administrator. - Page 26 Management Firmware Configuration options Enter U for User Account Management Enter 2 to access User Accounts Enter 1 to select Administrator Account Management options Enter 2 to change the account status from Offline = True to Offline = False. Enter 4=XXXX where XXXX is the new Administrator password. By default, the password is blank.
- Page 27 Management options Enter 0 twice to navigate back to the main menu. Enter Q to Save and Exit. Save and exit After saving to NVRAM and exiting, the Administrator account along with the password has been created. © 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
