Instruction Manual
DisplayPort to DVI Dual Link Active Converter – USB Powered
DP2DVID
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x DP2DVID adapter
• 1 x Installation Guide
System Requirements
• DisplayPort enabled computer system/video card
• Available USB port
• DVI-D (digital) enabled display device (i.e. monitor,
projector, HDTV, etc)
Installation
1. With the computer system powered off, plug the
DisplayPort connector from the DP2DVID adapter into
the computer's video card.
2. Connect the USB connector from the DP2DVID
adapter into a USB port on the computer system.
3. Connect a DVI-D (digital) cable from the DP2DVID
adapter to your display.
NOTE: For 2560x1600 operation, a dual link DVI-D cable
must be used.
4. Power on the monitor followed by the computer
system.No software/driver installation is required.
For the most up-to-date information, please visit: www.startech.com
Specifications
Connectors
Maximum Video Resolution
Support
Cable Length
Dimensions
Weight
*actual product may vary from photos
1 x DisplayPort male
1 x USB type A male
1 x DVI-D female
2560x1600
USB: 18"
DisplayPort: 14.5"
105.5mm x 58.0mm x 22.0mm
175g
Manual Revision: 02/10/2012
