Vantage Point Products SSB30 Assembly Instructions

SSB30 Adjustable Speaker Stand
Assembly Instructions
Preview all steps before beginning. Should any portion of these instructions be unclear, contact us direct at 800-582-9595 for assistance. Do not attempt to
assemble this Vantage Point Speaker Stand if you have any doubts as to its proper assembly and installation. CAUTION - Do not exceed maximum weight
indicated. Use with heavier than the maximum weight indicated may result in instability causing possible injury. Use of this product for any other purpose unless
specified by Vantage Point Products is not recommended. Think safety first!
∆ INDICATES TO NOTE CAUTION WHICH IF NEGLECTED MAY RESULT IN AN IMPROPER OR UNSTABLE ASSEMBLY.
(J)
(K)
(I)
(F)
(H)
(B)
(C)
(D)
(C)
(B)
(I)
(K)
(J)
Vantage Point Products Corp. • P.O. Box 2485, Santa Fe Springs, CA 90670 U.S.A.
USA Tel: 1.800.582.9595 • Canada Tel: 905.607.9994 • Europe Tel: 31.72.581.6056
A
B
(E)
C
D
E
F
G
H
I
J
K
(A)
(G)
• Web Site: www.vanptc.com • Email: cons-serv@vanptc.com

PARTS LIST

Cast Iron Speaker Base
Riser Skirt Upper/Lower
Riser Spacer
Aluminum Riser
Speaker Plate
Rubber Stem Bumper
Adhesive Backed Rubber Foot Pad
#10 x 5/8" Pan Head Screw
#8-16 x 1/2" Pan Head Self Threading Screw
1/4"-20 x 1-3/4" Pan Head Machine Screw
1/4"-20 x 3-3/4" Pan Head Machine Screw
24"
Maximum Speaker Weight: 25 lbs.
30"
2
4
12
2
2
8
6
8
12
4
4
SSB30 rev3-12-07
