About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for
installation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use" and "Detail
specifications".
• Operating Instructions (in the following manual website): Explains how to perform the settings
and how to operate this camera.
https://i-pro.com/global/en/surveillance/documentation_database
"<Control No.: C****>" used in these documents should be used to search for information on our sup-
port website (https://i-pro.com/global/en/surveillance/training_support/support/technical_information)
and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Model No.
WV-U2540LA
Basic Information
Network Camera
WV-U2540LA
WV-U2530LA
WV-U2140LA
WV-U2130LA
WV-U2140LA
Advertisement
Related Manuals for i-PRO WV-U2540LA
Summary of Contents for i-PRO WV-U2540LA
- Page 1 "<Control No.: C****>" used in these documents should be used to search for information on our sup- port website (https://i-pro.com/global/en/surveillance/training_support/support/technical_information) and will guide you to the right information. • microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.
-
Page 2: Table Of Contents
Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 About notations ..........................4 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Troubleshooting ..........................9 Detail specifications ........................10... -
Page 3: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 4: About Notations
The following notations are used when describing the functions limited for specified models. The functions without the notations are supported by all models. U2540 The functions with this notation are available when using the model WV-U2540LA. U2530 The functions with this notation are available when using the model WV-U2530LA. -
Page 5: Network Security
Network security As you will use this unit connected to a network, your attention is called to the following security risks. A Leakage or theft of information through this unit B Use of this unit for illegal operations by persons with malicious intent C Interference with or stoppage of this unit by persons with malicious intent It is your responsibility to take precautions such as those described below to protect yourself against the above network security risks. -
Page 6: Precautions For Use
Precautions for use When the product is accessible from the About the automatic status detection Internet function To prevent unauthorized access, note the When this product malfunctions due to exoge- following. nous noise, etc. for 30 seconds or more, the •... - Page 7 About the CMOS image sensor AVC Patent Portfolio License • When continuously shooting a bright light THIS PRODUCT IS LICENSED UNDER THE source such as a spotlight, the color filter AVC PATENT PORTFOLIO LICENSE FOR THE of the CMOS image sensor may become PERSONAL USE OF A CONSUMER OR deteriorated and this may cause discolor- OTHER USES IN WHICH IT DOES NOT...
- Page 8 Router When connecting this product to the Internet, use a broadband router with the port forward- ing function (NAT, IP masquerade). Refer to the Operating Instructions for further information about the port forwarding function. Time & date setting It is necessary to set the time & date before putting this product into operation.
-
Page 9: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages •... -
Page 10: Detail Specifications
Approx. 270 g {0.60 lbs} Approx. 250 g {0.55 lbs} Mass: Finish: Main body: Main body: Aluminum die cast, i-PRO white Aluminum die cast, i-PRO white Polycarbonate resin, i-PRO white Polycarbonate resin, i-PRO white Outer fixing screws: Dome cover: Stainless steel... - Page 11 • Camera Image sensor: Approx. 1/2.7 type CMOS image sensor U2540 U2140 Approx. 1/3 type CMOS image sensor U2530 U2130 Effective pixels: Approx. 5.2 megapixels U2540 U2140 Approx. 2.4 megapixels U2530 U2130 Scanning area: U2540 U2140 5.38 mm (H)×3.02 mm (V) {7/32 inches (H) × 1/8 inches (V)} U2530 U2130 5.28 mm (H)×2.97 mm (V) {7/32 inches (H) ×...
- Page 12 Back light compensation (BLC)/ BLC/ HLC/ Off High light compensation (HLC): (only when Super Dynamic / Intelligent auto: Off) Fog compensation: On/Off The level can be set in the range of 0 to 8. (only when Intelligent Auto / auto contrast adjust: Off) Light control mode setting: ELC/ Indoor scene (50 Hz)/ Indoor scene (60 Hz) Maximum shutter:...
- Page 13 • Lens Zoom ratio: Optical zoom Extra optical zoom U2540 U2140 max 4.0 x (1.0x – 1.3 x when resolution is 1920x1080) (1.0x – 4.0 x when resolution is 640x360) U2530 U2130 max 3.0 x (1.0x – 1.5x when resolution is 1280x720) (1.0x –...
- Page 14 • Network Network: 10BASE-T/100BASE-TX, RJ45 connector Resolution: U2540 U2140 H.265/ H.264 [16:9 mode*] *[4:3 mode] is not supported. JPEG (MJPEG) 2560×1440/ 1920×1080/ 640×360/ 320×180 U2530 U2130 [16:9 mode] 1920×1080/ 1280×720/ 640×360/ 320×180 [4:3 mode] 1600×1200/ 1280×960/ VGA/ QVGA Image compression method* H.265/ H.264 Transmission priority: Constant bit rate/ VBR/ Frame rate/ Best effort...
- Page 15 Smart coding: GOP(Group of pictures) control On(Frame rate control) */ On(Advanced) */ On(Mid)/ On(Low)/ Off *On(Frame rate control) and On(Advanced) are only available with H.265. AUTO VIQS On/Off Bandwidth control: Unlimited/ 64 kbps/ 128 kbps/ 256 kbps/ 384 kbps/ 512 kbps/ 768 kbps/ 1024 kbps/ 2048 kbps/ 4096 kbps/ 6144 kbps/ 8192 kbps/ 10240 kbps/ 15360 kbps/ 20480 kbps/ 25600 kbps/ Protocol:...
- Page 16 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Fukuoka, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 N0821-1042 PGQP3234YA...
