WV-U1142A, WV-U1132A
Model No.
WV-U2142LA
About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for instal-
lation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use" and "Detail
specifications".
• Operating Instructions (in the following manual website): Explains how to perform the settings
and how to operate this camera.
https://i-pro.com/global/en/surveillance/documentation_database
"<Control No.: C****>" used in these documents should be used to search for information on our
support website (https://i-pro.com/global/en/surveillance/training_support/support/technical_
information) and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Basic Information
Network Camera
WV-U1130A
WV-U2142LA
WV-U2132LA
WV-U1142A
Advertisement
Related Manuals for i-PRO WV-U1142A
Summary of Contents for i-PRO WV-U1142A
- Page 1 Basic Information Network Camera WV-U1142A, WV-U1132A Model No. WV-U1130A WV-U2142LA WV-U2132LA WV-U1142A WV-U2142LA About the user manuals Product documentation is composed of the following documents. • Installation Guide (accessory): Provides information about “Precautions”, “Precautions for instal- lation” and the installation method.
-
Page 2: Table Of Contents
Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 About notations ..........................4 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Troubleshooting ..........................8 Detail specifications ........................9... -
Page 3: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 4: About Notations
The following notations are used when describing the functions limited for specified models. The functions without the notations are supported by all models. The functions with this notation are available when using the model WV-U1142A. U1142 The functions with this notation are available when using the model WV-U1132A. -
Page 5: Network Security
Network security As you will use this unit connected to a network, your attention is called to the following security risks. A Leakage or theft of information through this unit B Use of this unit for illegal operations by persons with malicious intent C Interference with or stoppage of this unit by persons with malicious intent It is your responsibility to take precautions such as those described below to protect yourself against the above network security risks. -
Page 6: Precautions For Use
Precautions for use When the product is accessible from the Periodically images on the screen appear to Internet be distorted To prevent unauthorized access, note the following. When the camera is installed in a location where it • Leave user authentication turned on. is subject to small vibrations (for example, when it •... - Page 7 Cleaning the lens Router Use a lens cleaning paper (used to clean camera When connecting this product to the Internet, lenses or lenses of spectacles). When using sol- use a broadband router with the port forward- vent, use an alcohols solvent and do not use a ing function (NAT, IP masquerade).
-
Page 8: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages •... -
Page 9: Detail Specifications
Approx. 150 g {0.33 lbs} Finish: U1142 U1132 U1130 Main body : ABS/PC resin, i-PRO white U2142 U2132 Main body : ABS resin, i-PRO white Dome cover : Acrylic resin, Clear *1 Refer to our support website <Control No.: C0106> for further information about Power source... - Page 10 Camera • Image sensor: U2142 Approx. 1/2.7 type CMOS image sensor U1142 U2132 Approx. 1/3 type CMOS image sensor U1132 U1130 Effective pixels: U2142 U1142 Approx. 5.2 megapixels U2132 U1132 U1130 Approx. 2.4 megapixels Scanning area: U2142 U1142 5.38 mm (H)×3.02 mm (V) {7/32 inches (H) × 1/8 inches (V)} U2132 U1132 U1130...
- Page 11 Fog compensation: On/ Off The level can be set in the range of 0 to 8. (only when Intelligent Auto / auto contrast adjust: Off) Light control mode setting: ELC/ Indoor scene (50 Hz)/ Indoor scene (60 Hz) Maximum shutter: [30 fps mode] Max.1/10000s, Max.
- Page 12 Lens • Zoom ratio: Optical zoom U1142 U1132 U2142 U2132 2.5x (Motorized zoom / Motorized focus) U1130 1x Optical zoom Extra optical zoom U1142 U2142 max 10.0x (2.5x – 3.3x when resolution is 1920x1080) (2.5x – 10.0x when resolution is 640x360) U1132 U2132 max 7.5x...
- Page 13 Angular field of view: U1142 [16:9 mode*] *[4:3 mode] is not supported. Horizontal: 44° (TELE) – 103° (WIDE) Vertical: 25° (TELE) – 57° (WIDE) U1132 [16:9 mode] Horizontal: 44° (TELE) – 102° (WIDE) Vertical: 24° (TELE) – 56° (WIDE) [4:3 mode] Horizontal: 36°...
- Page 14 DORI * U2132 Detect (25 ppm / 8 ppf) 98.5 m {323.1 ft} (TELE) 36.2 m {118.7 ft} (WIDE) – Observe (62.5 ppm / 19 ppf) 39.4 m {129.2 ft} (TELE) 14.5 m {47.5 ft} (WIDE) – Recognize (125 ppm / 38 ppf) 19.7 m {64.6 ft} (TELE) 7.2 m {23.7 ft} (WIDE) –...
- Page 15 • Network Network: 10BASE-T/100BASE-TX, RJ45 connector Resolution: U1142 U2142 H.265/ H.264* [16:9 mode*] *[4:3 mode] is not supported. JPEG (MJPEG) 2560×1440/ 1920×1080/ 640×360/ 320×180 U1132 U2132 U1130 [16:9 mode] 1920×1080/ 1280×720/ 640×360/ 320×180 [4:3 mode] 1600×1200/ 1280×960/ VGA/ QVGA Image compression method* Transmission priority: H.265/ H.264* Constant bit rate/ VBR/ Frame rate/ Best effort...
- Page 16 Smart coding: GOP(Group of pictures) control On(Frame rate control) */ On(Advanced) */ On(Mid)/ On(Low)/ Off *On(Frame rate control) and On(Advanced) are only available with H.265. AUTO VIQS On/ Off Bandwidth control: Unlimited/ 64 kbps/ 128 kbps/ 256 kbps/ 384 kbps/ 512 kbps/ 768 kbps/ 1024 kbps/ 2048 kbps/ 4096 kbps/ 6144 kbps/ 8192 kbps/ 10240 kbps/ 15360 kbps/ 20480 kbps/ 25600 kbps/ Protocol:...
- Page 17 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Fukuoka, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 N0821-1042 PGQP3233YA...
