Albasca MK-5800BT Configuration Manual

Bluetooth area imager
Hide thumbs Also See for MK-5800BT:
Table of Contents

Advertisement

Quick Links

Download this manual
MK-5800BT
Bluetooth Area Imager Barcode Scanner
Configuration Guide
V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK-5800BT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Albasca MK-5800BT

Summary of Contents for Albasca MK-5800BT

  • Page 1 MK-5800BT Bluetooth Area Imager Barcode Scanner Configuration Guide V1.1...

  • Page 2: Table Of Contents

    Table of Contents Getting Started ..............................3 About This Guide ..........................3 Factory Defaults ..........................3 Pairing Cradle ..........................4 Pairing Smart Phone Table PC......................5 Communication Interfaces ..........................6 USB HID-KB ............................6 USB COM Port Emulation ....................... . 6 USB Country Keyboard Types ......................7 Convert Case ...........................
  • Page 3 General Settings ..........................18 5.1.1 Restore Symbology Default Setting ..................... 18 5.1.2 Optimize Performance for Retail Use Case ..................18 5.1.3 Enable/Disable All Symbologies ......................18 1D Symbologies ..........................19 5.2.1 Code 128 .............................. 19 5.2.2 EAN-8 ..............................20 5.2.3 EAN-13 ..............................22 5.2.4 UPC-E ..............................

  • Page 4: Getting Started

    Getting Started 1.1 About This Guide This guide provides programming instructions for the MK-5800BT 2D Barcoder Reader. Users can configure the MK-5800BT 2D Barcoder Reader by scanning the programming barcodes included in this manual. 1.2 Factory Defaults Scanning the following barcode can restore the MK-5800BT to the factory defaults.

  • Page 5: Pairing Cradle

    1.3 Pairing Cradle 1. Scan "setting configuration" 2. Scan "open SPP " 3. Scan "disconnect previous pairing" Scan "Cradle bottom BT address barcode" 5. Scan "Repairing" 6. Scan "Save BT SPP setting" 7. Scan " End BT SPP setting " Apple device needs enable transmission, other need to disable.

  • Page 6: Pairing Smart Phone Table Pc

    1.4 Pairing Smart Phone , Table PC 1. Scan "setting configuration” 2. Scan " Open HID connection " 3. Scan " Disconnection previous pairing " 4. Scan " BT visible setting " 5. Scan " Save BT HID configuration " 6.

  • Page 7: Communication Interfaces

    Cradle Communication Interfaces 2.1 Cradle USB HID -KB USB HID-KB (Default) 2.2 Cradle USB COM Port Emulation USB COM Port Emulation...

  • Page 8: Usb Country Keyboard Types

    2.3 USB Country Keyboard Types Keyboard layouts vary from country to country. The default setting is 1-U.S. keyboard. Germany France Italy Spain Japan Czech Denmark Belgium Finland Hungary Dutch Finlan...

  • Page 9: Convert Case

    2.4 Convert Case Scan the appropriate barcode below to convert barcode data to your desired case. No Case Conversion (Default) Convert All To Upper Case Convert All To Lower Case Example: When the Convert All to Lower Case feature is enabled, barcode data “AbC” is transmitted as “abc”.

  • Page 10: General Configuration

    General Configuration 3.1 Trigger Mode Manual Trigger Mode – Normal (Default) Manual Trigger Mode – Cellphone...

  • Page 11: Presentation Mode

    3.2 Presentation Mode This set the scanner to work in Continue mode. Presentation Mode – Normal Presentation Mode - Cellphone Presentation Mode – Continue Scan 3.3 Inverse color OFF (Default) Only Inverse ON Inverse And Normal Both ON...

  • Page 12: Seeep Time

    3.4 Sleep time 5 min 10 min 30 min Always On...

  • Page 13: Good Read Beeper

    3.5 Good Read Beeper ON (Default) 3.6 Good Read Beeper Tone Middle High (Default)

  • Page 14: Good Read Beeper Duration

    3.7 Good Read Beeper Duration Normal (Default) Short 3.8 Good Read Beeper Number 1 (Default)

  • Page 15: Barcode Scanning Delay

    3.9 Barcode Scanning Delay No Delay (Default) Delay 500 MS Delay 2000 MS...

  • Page 16: Data Formatting

    Data Formatting 4.1 General Configuration Add CR Add LF Add CRLF Add TAB...

  • Page 17: Add Prefix

    4.2 Add Prefix Set Custom Prefix Save Not Save To set a customer prefix, scan the “Set Custom Prefix” barcode and the numeric barcodes which representing the hexadecimal values of a desired prefix, and then scan the “Save” barcode. Refer to Appendix 2: ASCII Table for hexadecimal values of characters.

  • Page 18: Add Suffix

    4.3 Add Suffix Set Custom Suffix Save Not Save To set a customer suffix, scan the “Set Custom Suffix” barcode and the numeric barcodes which representing the hexadecimal values of a desired suffix, and then scan the “Save” barcode. Refer to Appendix 2: ASCII Table for hexadecimal values of characters.

  • Page 19: Symbologies

    Symbologies 5.1 General Settings 5.1.1 Restore Symbology Default Setting Symbologies Enable: Code 128, Code 39, UPC, EAN, Interleaved 2 of 5, Code 93, Coda Bar, GS1-128, DataMatrix, PDF417, QR, Maxi Code, Aztec. Restore Symbology Default 5.1.2 Optimize Performance for Retail Use Case Make for optimize scan performance in most retail barcode scan use case.

  • Page 20: Symbologies

    5.2 1D Symbologies 5.2.1 Code 128 Enable/Disable Code 128 Enable Code 128 (Default) Disable Code 128 Message Length Message length can be set to the maximum value or minimum value. The value between the maximum and the minimum is valid. The maximum value and minimum value can be set using “Programming Command”.

  • Page 21: Ean-8

    5.2.2 EAN-8 Enable/Disable EAN-8 Enable EAN-8 (Default) Disable EAN-8 Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the accuracy of the data. Transmit EAN-8 Check Digit (Default) Do Not Transmit EAN-8 Check Digit Add-On Code An EAN-8 barcode can be augmented with a two-digit or five-digit add-on code to form a new one.
  • Page 22 Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code (Default) Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code (Default) Add-On Code Required EAN-8 Add-On Code Required EAN-8 Add-On Code Not Required (Default) ENA/JAN-8 Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space.

  • Page 23: Ean-13

    Disable ENA/JAN-8 Addenda Separator UPC 5.2.3 EAN-13 Enable/Disable EAN-13 Enable EAN-13 (Default) Disable EAN-13 Transmit Check Digit Transmit EAN-13 Check Digit (Default) Do Not Transmit EAN-13 Check Digit Add-On Code Enable 2-Digit Add-On Code Disable 2 Digit Add On Code (Default)
  • Page 24 Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code (Default) Add-On Code Required EAN-13 Add-On Code Required EAN-13 Add-On Code Not Required (Default) ENA/JAN-13 Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space.

  • Page 25: Upc-E

    ISBN Translate When enable this feature and is scanned, ENA-13 Book land symbols are translated into their equivalent ISBN number format. Enable ISBN Translate Disable ISBN Translate (Default) 5.2.4 UPC-E Enable/Disable UPC-E0/E1 Enable UPC-E0 (Default) Disable UPC-E0 Enable UPC-E1 Disable UPC-E1 (Default)
  • Page 26 UPC-E0 Check Digit Enable UPC-E0 Check Digit (Default) Disable UPC-E0 Check Digit UPC-E0 Expand UPC-E0 expand expands the UPC-E code to the 12 digits, UPC-A format. Enable UPC-E0 Expand Disable UPC-E0 Expand (Default) UPC-E0 Addenda Required When required is scanned, the scanner will only read UPC-E barcodes that have addenda. Enable UPC-E0 Required Disable UPC-E0 Required (Default) UPC-E0 Addenda Separator...
  • Page 27 UPC-E0 Number System The number system digit of UPC symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will be not transmitted. Enable UPC-E0 Number System (Default) Disable UPC-E0 Number System UPC-E0 Addenda Enable 2 Digit Addenda Disable 2 Digit Addenda (Default)

  • Page 28: Upc-A

    5.2.5 UPC-A Enable/Disable UPC-A Enable UPC-A (Default) Disable UPC-A UPC-A Check Digit Enable UPC-A Check Digit (Default) Disable UPC-A Check Digit UPC-A Addenda Required When required is scanned, the scanner will only read UPC-E barcodes that have addenda. Enable UPC-A Required Disable UPC-A Required (Default)
  • Page 29 UPC-A Addenda Separator Enable UPC-A Separator (Default) Disable UPC-A Separator UPC-A: Number System The number system digit of UPC symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will be not transmitted. Enable UPC-A Number System (Default) Disable UPC-A Number System UPC-A: Addenda...

  • Page 30: Interleaved 2 Of 5

    5.2.6 Interleaved 2 Of 5 Enable/Disable Interleaved 2 Of 5 Enable Interleaved 2 Of 5 (Default) Disable Interleaved 2 Of 5 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid.

  • Page 31: Matrix 2 Of 5

    5.2.7 Matrix 2 Of 5 Enable/Disable Matrix 2 Of 5 Enable Matrix 2 Of 5 Disable Matrix 2 Of 5 (Default) Message Length Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum.

  • Page 32: Industrial 2 Of 5

    5.2.8 Industrial 2 Of 5 Enable/Disable Industrial 2 Of 5 Enable Industrial 2 Of 5 Disable Industrial 2 Of 5 (Default) Message Length Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum.

  • Page 33: Code 39

    5.2.9 Code 39 Enable/Disable Code 39 Enable Code 39 (Default) Disable Code 39 Transmit Start/Stop Character Transmit Start/Stop Character Do Not Transmit Start/Stop Character (Default) Code 39 Check Character No Check Char (Default) Validate And Transmit Validate No Transmit...
  • Page 34 Code 39 Append This function allows the scanner to append several Code 39 barcode data together before transmitting to host. When the scanner encounters a Code 39 barcode with append character (ex. Space character), it buffers the data until it reads a Code 39 barcode which does not have append character. Then the data is transmitted in the order that the barcodes were read.

  • Page 35: Coda Bar

    5.2.10 Coda Bar Enable/Disable Coda Bar Enable Coda Bar (Default) Disable Coda Bar Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail.

  • Page 36: Code 93

    Coda bar Check Character No Check Char (Default) Validate And Transmit Validate No Transmit 5.2.11 Code 93 Enable/Disable Code 93 Enable Code 93 (Default) Disable Code 93 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid.

  • Page 37: Gs1-128

    Code 93 Append This function allows the scanner to append several Code 93 barcode data together before transmitting to host. When the scanner encounters a Code 93 barcode with append character (ex. Space character), it buffers the data until it reads a Code 93 barcode which does not have append character. Then the data is transmitted in the order that the barcodes were read.

  • Page 38: Msi

    The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail. GS1-128 max length command: 020B03. The parameter of this command can be set from min to 80. GS1-128 min length command: 020B02. The parameter of this command can be set from 0 to max. Example: Set the Barcode Message length of the minimum value is 10;...
  • Page 39 MSI Check Character Validate Type10 Transmit Validate Type10 Then Type11 Char Transmit Validate Type10 Then Type11 Char NO Transmit Validate Type10 No Transmit Validate 2 Type10 No Transmit (Default) Validate 2 Type10 Char Transmit Validate 2 Type10 Char No Transmit Disable MSI Check...

  • Page 40: Code 11

    5.2.14 Code 11 Enable/Disable Code 11 Disable Code 11 (Default) Enable Code 11 Code11 Check Digit(s) One Check Digit Two Check Digits (Default)

  • Page 41: Symbologies

    5.3 2D Symbologies 5.3.1 PDF 417 Enable/Disable PDF 417 Enable PDF 417 (Default) Disable PDF 417 Enable/Disable Micro PDF 417 Enable Micro PDF 417 Disable Micro PDF 417 (Default) Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum.

  • Page 42: Qr Code

    5.3.2 QR Code Enable/Disable QR Code Enable QR Code (Default) Disable QR Code Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail.

  • Page 43: Data Matrix

    5.3.3 Data Matrix Enable/Disable Data Matrix Enable Data Matrix (Default) Disable Data Matrix Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail.

  • Page 44: Maxi Code

    5.3.4 Maxi code Enable/Disable Maxi code Enable Maxi Code Disable Maxi Code (Default) Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail.

  • Page 45: Aztec

    5.3.5 Aztec Enable/Disable Aztec Enable Aztec (Default) Disable Aztec Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail.

  • Page 46: Hanxin

    5.3.6 Hanxin Enable/Disable Hanxin Enable Hanxin Disable Hanxin (Default) Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command. Please check the programming command guide for the detail.

  • Page 47: Postal Symbologies

    5.4 Postal Symbologies 5.4.1 China Postal Code Enable/Disable China Postal Code Enable China Postal Code Disable China Postal Code (Default) 5.4.2 Telepen Enable/Disable Telepen Enable China Telepen Disable China Telepen (Default)

  • Page 48: Appendix

    Appendix 6.1 Appendix 1: ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3)
  • Page 49 Char (Space) (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Right / Closing Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) < (Less Than) (Equal Sign) >...
  • Page 50 Char (AT Symbol) (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket) (Caret / Circumflex) (Underscore)

  • Page 51: Appendix 2: Kb Wedge Character Table

    endix 2: KB wedge character Table Char Char Char L-Ctrl L-Shift L-Alt L-GUI R-Ctrl R-Shift R-Alt R-GUI Caps Lock Print Screen Scroll Lock Pause Insert Delete Home Page Up Page Down Left Arrow Right Arrow Up Arrow Down Arrow Num Lock(keypad) 1(keypad) 2(keypad) 3(keypad)

  • Page 52: Appendix 3: Digit Barcodes

    6.3 Appendix 3: Digit Barcodes...
