Albasca MK-5500 Configuration Manual

2d imager barcode scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MK-5500
2D Imager Barcode Scanner
Configuration Guide
V1.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK-5500 and is the answer not in the manual?

Questions and answers

Related Manuals for Albasca MK-5500

Summary of Contents for Albasca MK-5500

  • Page 1 MK-5500 2D Imager Barcode Scanner Configuration Guide V1.4...

  • Page 2: Table Of Contents

    Table of Contents Getting Started ............................... 3 About This Guide ..........................3 Barcode Scanning ..........................3 Communication Interfaces ..........................4 Factory Defaults ..........................3 TTL-232 Cable Select ......................... 4 TTL-232 Interface ..........................5 Baud Rate ............................6 Data Bit & Parity Check& Stop Bit ....................7 USB Interface ............................
  • Page 3 General Settings ..........................20 1D Symbologies ..........................21 5.2.1 Code 128 ............................21 5.2.2 EAN-8 .............................. 22 5.2.3 EAN-13 ............................23 5.2.4 UPC-E .............................. 26 5.2.5 UPC-A .............................. 29 5.2.6 Interleaved 2 of 5 ..........................31 5.2.7 Matrix 2 of 5 ........................... 32 5.2.8 Industrial 2 of 5 ..........................

  • Page 4: Getting Started

    MK-5500 2D BARCODER READER features fast scanning and decoding accuracy. Barcodes rotated at any angle can still be read with ease. When scanning a barcode, simply center the aiming beam or pattern projected by the MK-5500 2D BARCODER READER over the barcode. 1.3 Factory Defaults Scanning the following barcode can restore the engine to the factory defaults.

  • Page 5: Communication Interfaces

    2. Communication Interfaces The MK-5500 2D BARCODER READER provides a TTL-232 interface and a USB interface to communicate with the host device. The host device can receive scanned data and send commands to control the engine or to access/alter the configuration information of the engine via the TTL-232 or USB interface.

  • Page 6: Ttl-232 Interface

    2.2 TTL-232 Interface Serial communication interface is usually used when connecting the MK-5500 to a host device (like PC, POS). However, to ensure smooth communication and accuracy of data, you need to set communication parameters (including baud rate, parity check, data bit and stop bit) to match the host device.

  • Page 7: Baud Rate

    2.3 Baud Rate Baud rate is the number of bits of data transmitted per second. Set the baud rate to match the Host requirements. 2400 4800 9600 19200 38400 57600 115200...

  • Page 8: Data Bit & Parity Check& Stop Bit

    2.4 Data Bit & Parity Check& Stop Bit None Parity /8 Data Bits/1 Stop Bit None Parity /7 Data Bits/1 Stop Bit None Parity /7 Data Bits/2 Stop Bits Even Parity /8 Data Bits/1 Stop Bit Even Parity /7 Data Bits/1 Stop Bit Even Parity /7 Data Bits/2 Stop Bits Odd Parity /8 Data Bits/1 Stop Bit Odd Parity /7 Data Bits/1 Stop Bit...

  • Page 9: Usb Interface

    Reset 2.6 USB HID-KBW When you connect the MK-5500 to the Host via a USB connection, you can enable the USB HID-KBW feature by scanning the barcode below. Then MK-5500 transmission will be simulated as USB keyboard input. The Host receives keystrokes on the virtual keyboard. It works on a Plug and Play basis and no driver is required.

  • Page 10: Usb Country Keyboard Types

    2.7 USB Country Keyboard Types Keyboard layouts vary from country to country. The default setting is 1-U.S. keyboard. 1 - U.S. 2 – UK 3 - Denmark 4 - France 5 - Finland 6 - Turkey_F 7 - Italy 8 - Norway 9 - Albania 10 - Belgium...
  • Page 11 11 – Bosnia 12 – Brazil 13 – Croatia 14 – Czech 15 –Dutch 16 – Estonia 17 – Germany 18 – Greek 19 – Hungary 20 – Irish 21 – Latvia 22-Lithunnia...
  • Page 12 23 – Macedonia 24 – Spain 25 – Poland 26 –Portugal 27 –Romania 28 –Russia 29 – Japan...

  • Page 13: Convert Case

    2.8 Convert Case Scan the appropriate barcode below to convert barcode data to your desired case. No Case Conversion Convert All to Upper Case Convert All to Lower Case Example: When the Convert All to Lower Case feature is enabled, barcode data “AbC” is transmitted as “abc”.

  • Page 14: 2.9 General Configuration

    3. General Configuration 3.1 Trigger Mode If the Trigger Mode is enabled, you could activate the scanner by providing an external hardware trigger, or using a serial trigger command. When in manual trigger mode, the scanner scans until a barcode is read, or until the hardware trigger is released.

  • Page 15: Video Reverse

    3.3 Video Reverse 3.4 Beeper - Good Read 3.5 Beeper Tone - Good Read Middle High...

  • Page 16: Beeper Duration - Good Read

    3.6 Beeper Duration - Good Read Normal Short 3.7 Beeper Number - Good Read...

  • Page 17: Barcode Scanning Delay

    3.8 Barcode Scanning Delay No Delay Delay 500MS Delay 2000ms...

  • Page 18: 3.8 Data Formatting

    Data Formatting 4.1 General Configuration Add CR Add LF Add CRLF Add TAB...

  • Page 19: Add Prefix

    4.2 Add Prefix Set Custom Prefix Save Not Save To set a customer prefix, scan the “Set Custom Prefix” barcode and the numeric barcodes which representing the hexadecimal values of a desired prefix, and then scan the “Save” barcode. Refer to Appendix 4: ASCII Table for hexadecimal values of characters.

  • Page 20: Add Suffix

    4.3 Add Suffix Set Custom Suffix Save Not Save To set a customer suffix, scan the “Set Custom Suffix” barcode and the numeric barcodes which representing the hexadecimal values of a desired suffix, and then scan the “Save” barcode. Refer to Appendix 4: ASCII Table for hexadecimal values of characters.

  • Page 21: 4.4 Symbologies

    Symbologies 5.1 General Settings Enable/Disable All Symbologies If the Disable All Symbologies feature is enabled, the engine will not be able to read any non- programming barcodes except the programming barcodes. Enable All Symbologies Disable All Symbologies...

  • Page 22: Symbologies

    5.2 1D Symbologies Code 128 5.2.1 Restore Factory Defaults Restore the Factory Defaults of Code 128 Enable/Disable Code 128 Enable Code 128 Disable Code 128 Message Length Message length can be set to the maximum value or minimum value. The value between the maximum and the minimum is valid.

  • Page 23: Ean-8

    5.2.2 EAN-8 Restore Factory Defaults Restore the Factory Defaults of EAN-8 Enable/Disable EAN-8 Enable EAN-8 Disable EAN-8 Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the accuracy of the data. Transmit EAN-8 Check Digit Do Not Transmit EAN-8 Check Digit Add-On Code...
  • Page 24 Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Add-On Code Required EAN-8 Add-On Code Required EAN-8 Add-On Code Not Required ENA/JAN-8 Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space.

  • Page 25: Ean-13

    5.2.3 EAN-13 Restore Factory Defaults Restore the Factory Defaults of EAN-13 Enable/Disable EAN-13 Enable EAN-13 Disable EAN-13 Transmit Check Digit Transmit EAN-13 Check Digit Do Not Transmit EAN-13 Check Digit Add-On Code Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code...
  • Page 26 Add-On Code Required EAN-13 Add-On Code Required EAN-13 Add-On Code Not Required ENA/JAN-13 Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space. Enable ENA/JAN-13 Addenda Separator Disable ENA/JAN-13 Addenda Separator ISBN Translate When enable this feature and is scanned, ENA13 Book land symbols are translated into their equivalent ISBN...

  • Page 27: Upc-E

    5.2.4 UPC-E Restore Factory Defaults Restore the Factory Defaults of UPC-E Enable/Disable UPC-E0/E1 Enable UPC-E0 Disable UPC-E0 Enable UPC-E1 Disable UPC-E1 UPCE0 Check Digit Enable UPC-E0 Check Digit Disable UPC-E0 Check Digit...
  • Page 28 UPCE0 Expand UPCE0 expand expands the UPCE code to the 12 digits, UPC-A format. Enable UPC-E0 Expand Disable UPC-E0 Expand UPCE0 Addenda Required When required is scanned, the scanner will only read UPC-E barcodes that have addenda. Enable UPC-E0 Required Disable UPC-E0 Required UPCE0 Addenda Separator Enable UPC-E0 Separator...
  • Page 29 UPCE0 Addenda Enable 2 Digit Addenda Disable 2 Digit Addenda Enable 5 Digit Addenda Disable 5 Digit Addenda...

  • Page 30: Upc-A

    5.2.5 UPC-A Restore Factory Defaults Restore the Factory Defaults of UPC-A Enable/Disable UPC-A Enable UPC-A Disable UPC-A UPC-A Check Digit Enable UPC-A Check Digit Disable UPC-A Check Digit UPC-A Addenda Required When required is scanned, the scanner will only read UPC-E barcodes that have addenda. Enable UPC-A Required Disable UPC-A Required...
  • Page 31 UPC-A Addenda Separator Enable UPC-A Separator Disable UPC-A Separator UPC-A: Number System The number system digit of UPC symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will be not transmitted. Enable UPC-A Number System Disable UPC-A Number System UPC-A: Addenda...

  • Page 32: Interleaved 2 Of 5

    5.2.6 Interleaved 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid.

  • Page 33: Matrix 2 Of 5

    5.2.7 Matrix 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Matrix 2 of 5 Enable/Disable Matrix 2 of 5 Enable Matrix 2 of 5 Disable Matrix 2 of 5 Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum.

  • Page 34: Industrial 2 Of 5

    5.2.8 Industrial 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Industrial 2 of 5 Enable/Disable Industrial 2 of 5 Enable Industrial 2 of 5 Disable Industrial 2 of 5 Message Length Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum.

  • Page 35: Code 39

    5.2.9 Code 39 Restore Factory Defaults Restore the Factory Defaults of Code 39 Enable/Disable Code 39 Enable Code 39 Disable Code 39 Transmit Start/Stop Character Transmit Start/Stop Character Do not Transmit Start/Stop Character Code 39 Check Character No Check Char Validate and Transmit Validate no Transmit...
  • Page 36 Code 39 Append This function allows the scanner to append several Code 39 barcode data together before transmitting to host. When the scanner encounters a Code 39 barcode with append character (ex. Space character), it buffers the data until it reads a Code 39 barcode which does not have append character. Then the data is transmitted in the order that the barcodes were read.

  • Page 37: Coda Bar

    5.2.10 Coda bar Restore Factory Defaults Restore the Factory Defaults of Coda bar Enable/Disable Codabar Enable Coda bar Disable Coda bar Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid.
  • Page 38 Transmit Start/Stop Character Transmit Start/Stop Character Do not Transmit Start/Stop Character Coda bar Check Character No Check Char Validate and Transmit Validate no Transmit...

  • Page 39: Code 93

    5.2.11 Code 93 Restore Factory Defaults Restore the Factory Defaults of Code 93 Enable/Disable Code 93 Enable Code 93 Disable Code 93 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid.
  • Page 40 Code 93 Append This function allows the scanner to append several Code 93 barcode data together before transmitting to host. When the scanner encounters a Code 93 barcode with append character (ex. Space character), it buffers the data until it reads a Code 93 barcode which does not have append character. Then the data is transmitted in the order that the barcodes were read.

  • Page 41: Gs1-128

    5.2.12 GS1-128 Restore Factory Defaults Restore the Factory Defaults of GS1-128 Enable/Disable GS1-128 Enable GS1-128 Disable GS1-128 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command.

  • Page 42: Msi

    5.2.13 MSI Restore Factory Defaults Restore the Factory Defaults of MSI Enable/Disable MSI Enable MSI Disable MSI Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.
  • Page 43 MSI Check Character ValidateType10Transmit ValidateType10 ThenType11CharTransmit ValidateType10 ThenType11CharNoTransmit ValidateType10NoTransmit Validate2Type10NoTransmit Validate2Type10CharTransmit Validate2Type10CharNoTransmit DisableMSICheck...

  • Page 44: Symbologies

    5.3 2D Symbologies 5.3.1 PDF 417 Restore Factory Defaults Restore the Factory Defaults of PDF 417 Enable/Disable PDF 417 Enable PDF 417 Disable PDF 417 Enable/Disable Micro PDF 417 Enable Micro PDF 417 Disable Micro PDF 417 Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum.
  • Page 45 Example: Set the Barcode Message length of the minimum value is 10; the maximum value is 25. Programming command Max: 021F0625 Min: 021F0510.

  • Page 46: Qr Code

    5.3.2 QR Code Restore Factory Defaults Restore the Factory Defaults of QR Code Enable/Disable QR Code Enable QR Code Disable QR C Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum is valid.
  • Page 47 QR Code Append This function allows the scanner to append several QR barcode data together before transmitting to host. When the scanner encounters a QR barcode with append character (ex. Space character), it buffers the data until it reads a QR barcode which does not have append character. Then the data is transmitted in the order that the barcodes were read.

  • Page 48: Data Matrix

    5.3.3 Data Matrix Restore Factory Defaults Restore the Factory Defaults of Data Matrix Enable/Disable Data Matrix Enable Data Matrix Disable Data Matrix Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum.

  • Page 49: Maxi Code

    5.3.4 Maxi code Restore Factory Defaults Restore the Factory Defaults of Maxi code Enable/Disable Maxi code Enable Maxi code Disable Maxi code Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum.

  • Page 50: Aztec

    5.3.5 Aztec Restore Factory Defaults Restore the Factory Defaults of Aztec Enable/Disable Aztec Enable Aztec Disable Aztec Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.

  • Page 51: Hanxin

    5.3.6 Hanxin Restore Factory Defaults Restore the Factory Defaults of Hanxin Enable/Disable Hanxin Enable Hanxin Disable Hanxin Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.

  • Page 52: Postal Symbologies

    Postal Symbologies 5.4.1 China Postal Code Restore Factory Defaults Restore the Factory Defaults of China Postal Code Enable/Disable China Postal Code Enable China Postal Code Disable China Postal Code...

  • Page 53: Telepen

    5.4.2 Telepen Restore Factory Defaults Restore the Factory Defaults of Telepen Enable/Disable Telepen Enable China Telepen Disable China Telepen...

  • Page 54: 5.4.2 Appendix

    Appendix 6.1 Appendix 1: ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3)
  • Page 55 Char (Space) (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Right / Closing Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) < (Less Than) (Equal Sign) >...
  • Page 56 Char (AT Symbol) (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket) (Caret / Circumflex) (Underscore)
  • Page 57 Char (Grave Accent) (Left/ Opening Brace) (Vertical Bar) (Right/Closing Brace) (Tilde) (Delete)

  • Page 58: Appendix 4: Digit Barcodes

    6.2 Appendix 2: Digit Barcodes...
